— 76 —
R1242 1-249-429-11 CARBON 10K 5% 1/4W
R1243 1-249-383-11 CARBON 1.5 5% 1/6W F
R1245 1-249-433-11 CARBON 22K 5% 1/4W
R1249 1-249-389-11 CARBON 4.7 5% 1/4W F
(RX30:AEP,UK,G,EE)
R1250 1-249-421-11 CARBON 2.2K 5% 1/4W F
R1251 1-249-417-11 CARBON 1K 5% 1/4W F
R1252 1-249-437-11 CARBON 47K 5% 1/4W
R1253 1-249-413-11 CARBON 470 5% 1/4W F
R1254 1-249-437-11 CARBON 47K 5% 1/4W
R1255 1-260-103-11 CARBON 2.2K 5% 1/2W
R1257 1-260-103-11 CARBON 2.2K 5% 1/2W
! R1260 1-208-602-11 WIREWOUND 0.22 10% 2W F
R1261 1-249-417-11 CARBON 1K 5% 1/4W F
R1262 1-249-431-11 CARBON 15K 5% 1/4W
R1263 1-249-441-11 CARBON 100K 5% 1/4W
R1268 1-260-076-11 CARBON 10 5% 1/2W
R1270 1-249-389-11 CARBON 4.7 5% 1/4W F
(RX30:AEP,UK,G,EE)
R1271 1-249-389-11 CARBON 4.7 5% 1/4W F
(RX30:AEP,UK,G,EE)
R1272 1-249-409-11 CARBON 220 5% 1/4W F
R1273 1-249-409-11 CARBON 220 5% 1/4W F
R1290 1-249-437-11 CARBON 47K 5% 1/4W
R1295 1-249-433-11 CARBON 22K 5% 1/4W
R1299 1-249-389-11 CARBON 4.7 5% 1/4W F
(RX30:AEP,UK,G,EE)
R1303 1-249-427-11 CARBON 6.8K 5% 1/4W F
(GR3/RX30:AEP,UK,G,EE)
R1303 1-249-428-11 CARBON 8.2K 5% 1/4W F
(RX30:US,CND)
R1304 1-249-427-11 CARBON 6.8K 5% 1/4W F
(GR3/RX30:AEP,UK,G,EE)
R1304 1-249-428-11 CARBON 8.2K 5% 1/4W F
(RX30:US,CND)
< VARIABLE RESISTOR >
RV301 1-238-600-11 RES, ADJ, CARBON 10K
RV302 1-238-600-11 RES, ADJ, CARBON 10K
RV303 1-238-600-11 RES, ADJ, CARBON 10K
RV304 1-238-603-11 RES, ADJ, CARBON 100K
RV380 1-238-599-11 RES, ADJ, CARBON 4.7K
RV401 1-238-600-11 RES, ADJ, CARBON 10K
RV402 1-238-600-11 RES, ADJ, CARBON 10K
RV403 1-238-600-11 RES, ADJ, CARBON 10K
RV404 1-238-603-11 RES, ADJ, CARBON 100K
< RELAY >
RY1201 1-515-920-11 RELAY (24V)
< TRANSFORMER >
T350 1-433-349-11 TRANSFORMER, BIAS OSCILLATION
< TERMINAL >
TM1201 1-537-240-31 TERMINAL BOARD (CHECKER PIN)(SPEAKER)
(GR3/RX30:US,CND)
TM1201 1-537-801-11 TERMINAL BOARD (SPEAKER)
(RX30:AEP,UK,G,EE)
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
< VIBRATOR >
X701 1-579-175-11 VIBRATOR, CERAMIC (10MHz)
X702 1-567-098-41 VIBRATOR, CRYSTAL (32kHz)
**************************************************************
* 1-658-578-11 MOTOR (SLIDE) BOARD
*******************
< CAPACITOR >
C801 1-162-306-11 CERAMIC 0.01uF 20% 16V
C804 1-162-306-11 CERAMIC 0.01uF 20% 16V
C805 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
* CN801 1-568-947-11 PIN, CONNECTOR 9P
< DIODE >
D801 8-719-010-43 DIODE UZ-5.6BSC
D804 8-719-987-63 DIODE 1N4148M
D805 8-719-987-63 DIODE 1N4148M
< IC >
IC801 8-759-274-09 IC BA6286N
< MOTOR >
M801 A-4672-004-A MOTOR ASSY (SLIDE)
< RESISTOR >
R801 1-249-401-11 CARBON 47 5% 1/4W F
< SWITCH >
S801 1-762-527-11 SWITCH, ROTARY (OPEN/CLOSE)
**************************************************************
* 1-658-577-11 MOTOR (TURN) BOARD
******************
< CAPACITOR >
C701 1-162-306-11 CERAMIC 0.01uF 20% 16V
C702 1-126-964-11 ELECT 10uF 20% 50V
C705 1-162-306-11 CERAMIC 0.01uF 20% 16V
< CONNECTOR >
CN703 1-750-413-11 CONNECTOR, FFC/FPC 8P
CN704 1-506-469-11 PIN, CONNECTOR 4P
< DIODE >
D701 8-719-010-23 DIODE UZ-3.6BSB
< IC >
IC701 8-759-633-65 IC M54641L
< MOTOR >
M701 A-4672-004-A MOTOR ASSY (TURN)
MAIN
MOTOR (SLIDE)
Les composants identifiés par
une marque ! sont critiques pour
la sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
MOTOR (TURN)
