— 78 —
PANEL
SENSOR
R540 1-249-429-11 CARBON 10K 5% 1/4W
R544 1-249-429-11 CARBON 10K 5% 1/4W
R545 1-249-421-11 CARBON 2.2K 5% 1/4W F
R546 1-249-429-11 CARBON 10K 5% 1/4W
R547 1-249-421-11 CARBON 2.2K 5% 1/4W F
R548 1-249-407-11 CARBON 150 5% 1/4W F
R549 1-249-407-11 CARBON 150 5% 1/4W F
R550 1-249-407-11 CARBON 150 5% 1/4W F
R557 1-247-807-31 CARBON 100 5% 1/4W
R558 1-247-807-31 CARBON 100 5% 1/4W
R559 1-247-807-31 CARBON 100 5% 1/4W
R560 1-247-807-31 CARBON 100 5% 1/4W
R561 1-247-807-31 CARBON 100 5% 1/4W
R562 1-247-807-31 CARBON 100 5% 1/4W
R563 1-249-441-11 CARBON 100K 5% 1/4W
R564 1-249-401-11 CARBON 47 5% 1/4W F
R565 1-249-429-11 CARBON 10K 5% 1/4W
R566 1-249-429-11 CARBON 10K 5% 1/4W
R567 1-249-429-11 CARBON 10K 5% 1/4W
R568 1-249-429-11 CARBON 10K 5% 1/4W
R569 1-249-429-11 CARBON 10K 5% 1/4W
R570 1-249-441-11 CARBON 100K 5% 1/4W
R571 1-249-429-11 CARBON 10K 5% 1/4W
R572 1-249-429-11 CARBON 10K 5% 1/4W
R573 1-249-429-11 CARBON 10K 5% 1/4W
R574 1-249-429-11 CARBON 10K 5% 1/4W
R576 1-249-429-11 CARBON 10K 5% 1/4W
R577 1-247-903-00 CARBON 1M 5% 1/4W
R578 1-249-401-11 CARBON 47 5% 1/4W F
R580 1-249-407-11 CARBON 150 5% 1/4W F
R581 1-247-807-31 CARBON 100 5% 1/4W
R582 1-249-407-11 CARBON 150 5% 1/4W F
R585 1-249-421-11 CARBON 2.2K 5% 1/4W F
R586 1-247-807-31 CARBON 100 5% 1/4W
R587 1-247-807-31 CARBON 100 5% 1/4W
R588 1-247-807-31 CARBON 100 5% 1/4W
R605 1-247-807-31 CARBON 100 5% 1/4W
R615 1-247-807-31 CARBON 100 5% 1/4W
R625 1-247-807-31 CARBON 100 5% 1/4W
R631 1-249-417-11 CARBON 1K 5% 1/4W F
R632 1-249-417-11 CARBON 1K 5% 1/4W F
R633 1-249-417-11 CARBON 1K 5% 1/4W F
< SWITCH >
S509 1-762-196-21 SWITCH, TACT (TIMER)
S510 1-762-196-21 SWITCH, TACT (DISPLAY)
S511 1-762-196-21 SWITCH, TACT (MULTI FUNCTION CONTROL (1))
S512 1-762-196-21 SWITCH, TACT (MULTI FUNCTION CONTROL (2))
S513 1-762-196-21 SWITCH, TACT (MULTI FUNCTION CONTROL (3))
S514 1-762-196-21 SWITCH, TACT (MULTI FUNCTION CONTROL (4))
S516 1-762-196-21 SWITCH, TACT (ENTER/NEXT)
S517 1-762-196-21 SWITCH, TACT (DBFB)
S518 1-762-196-21 SWITCH, TACT (CLIP C)
S519 1-762-196-21 SWITCH, TACT (CLIP B)
S520 1-762-196-21 SWITCH, TACT (CLIP A)
S521 1-762-196-21 SWITCH, TACT (CLIP ERASE)
S522 1-762-196-21 SWITCH, TACT (CLIP PLAY)
S523 1-762-196-21 SWITCH, TACT (DOLBY NR)
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
S524 1-762-196-21 SWITCH, TACT (MENU 1)
S525 1-762-196-21 SWITCH, TACT (MENU 2)
S526 1-762-196-21 SWITCH, TACT (MENU 3)
S528 1-762-196-21 SWITCH, TACT (P FILE)
S529 1-762-196-21 SWITCH, TACT (EFFECT ON/OFF)
S530 1-762-196-21 SWITCH, TACT (SURROUND)
S531 1-762-196-21 SWITCH, TACT (EQ EDIT)
S532 1-762-196-21 SWITCH, TACT (<, ≠, –)
S533 1-762-196-21 SWITCH, TACT (∧)
S534 1-762-196-21 SWITCH, TACT (>, ±, +)
S535 1-762-196-21 SWITCH, TACT (∨)
S536 1-762-196-21 SWITCH, TACT (TUNER/BAND)
S537 1-762-196-21 SWITCH, TACT (FUNCTION)
S538 1-762-196-21 SWITCH, TACT (GROOVE)
S550 1-467-869-11 ENCODER, ROTARY (VOLUME)
< VIBRATOR >
X501 1-760-489-11 VIBRATOR, CERAMIC (5MHz)
**************************************************************
* 1-658-576-11 SENSOR BOARD
*************
< IC >
IC702 8-749-924-18 PH OTO INTERRUPTER RPI-1391
IC703 8-749-924-30 PH OTO REFLECTOR GP2S28
< RESISTOR >
R701 1-249-416-11 CARBON 820 5% 1/4W F
R702 1-249-407-11 CARBON 150 5% 1/4W F
**************************************************************
* A-4303-514-A TCB BOARD, COMPLETE (AEP,UK)
****************************
* A-4303-515-A TCB BOARD, COMPLETE (G)
***********************
* A-4303-516-A TCB BOARD, COMPLETE (EE)
************************
< CAPACITOR >
C1 1-163-141-00 CERAMIC CHIP 0.001uF 5% 50V
C2 1-126-967-11 ELECT 47uF 20% 16V
C3 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C5 1-163-031-11 CERAMIC CHIP 0,01uF 50V
C6 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C7 1-101-004-00 CERAMIC 0.01uF 50V (EE)
C8 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C9 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C10 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C11 1-216-295-91 CONDUCTOR, CHIP (2012)(G)
C16 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C19 1-163-249-11 CERAMIC CHIP 82PF 5% 50V
(AEP,UK,EE)
C21 1-163-141-00 CERAMIC CHIP 0.001uF 5% 50V
C22 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C23 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
TCB
