HCD-GT22/GT44/GT55
9
3-4. LID (CD)
3-5. CD MECHANISM DECK (CDM74KF-K6BD91UR-WOD), USB BOARD
1
Turn the gear (loading A)
to the direction of the arrow.
3
four claws
2
4
lid (CD
7
three screws
(BVTP3
×
8)
6
screw (BVTP3
×
8)
6
screw
(BVTP3
×
8)
8
CD mechanism deck
(CDM74KF-K6BD91UR-WOD)
1
flexible flat (13 core) cable
(CN701)
2
flexible flat (27 core) cable
(CN302)
4
connector (CN901)
3
flexible flat (21 core) cable
(MAIN board: CN301/USB board: CN907)
5
connector (CN903)
9
two screws (M2.6)
0
USB board
