86 TABLE L — Not used (Open)
87 LOAD OUT O Loading motor (M903) Load out output
88 LOAD IN O Loading motor (M903) Load in output
89 DF-LATCH O Latch output to digital filter (PCM1710U)
90 XLT O Serial data latch output to DSP (CDX2507AQ)
91 FOCUS. SW O High-region gain down output to focus servo (CXA1782BQ)
92 HIGH DUBB — Not used (Pull up)
93 TEST 1 I Test land (Pull up)
94 OUT. SW I CD Tray output detection input “L”: OUT
95 IN. SW I CD Tray input detection input
96 UP. SW — Not used (connected to ground)
97 PANEL. SW — Not used (connected to ground)
98 CLOSE. SW — Not used (connected to ground)
99 OPEN. SW — Not used (connected to ground)
100 VDD — Power supply (+5 V)
