– 72 –
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used on
the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
The components identified by mark
! or dotted line with mark ! are criti-
cal for safety.
Replace only with part number speci-
fied.
When indicating parts by reference
number, please include the board.
• Abbreviation
G : German IT : Italian
E2 : Tuner Sections SW BAND do not exist.
E3 : Tuner Sections SW BAND exist.
MY : Malaysia SP : Singapore MX : Mexican
EA : Saudi Arabia HK : Hong Kong AR : Argentine
AUS : Australian
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
5* A-4390-033-A AMP BOARD, COMPLETE (AEP, G, IT)
* A-4390-041-A AMP BOARD, COMPLETE (UK)
* A-4390-047-A AMP BOARD, COMPLETE
(E2, E3, EA, HK, AR, AUS)
* A-4390-054-A AMP BOARD, COMPLETE (MY,SP)
* A-4390-059-A AMP BOARD, COMPLETE (MX)
********************
* 3-923-762-11 HOLDER (TR)
<CAPACITOR>
C901 1-124-925-11 ELECT 2.2uF 20% 100V
C902 1-126-947-11 ELECT 47uF 20% 35V
C903 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C904 1-126-951-11 ELECT 470uF 20% 35V
C905 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C906 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C941 1-128-136-11 ELECT 2200uF 20% 35V
C942 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C944 1-126-947-11 ELECT 47uF 20% 35V
C945 1-126-947-11 ELECT 47uF 20% 35V
C950 1-162-306-11 CERAMIC 0.01uF 30% 16V
C951 1-124-925-11 ELECT 2.2uF 20% 100V
C952 1-126-947-11 ELECT 47uF 20% 35V
C953 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C954 1-126-971-11 ELECT 470uF 20% 35V
C981 1-124-925-11 ELECT 2.2uF 20% 100V
C983 1-126-965-11 ELECT 22uF 20% 50V
C984 1-162-191-31 CERAMIC 2.2PF 10% 50V
C985 1-126-964-11 ELECT 10uF 20% 50V
C987 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C988 1-163-038-00 CERAMIC CHIP 0.1uF 25V
<IC>
IC801 8-759-231-58 IC TA7812S
IC901 8-759-069-56 IC LM3875-Q
IC902 8-759-168-24 IC TA8216H
<TRANSISTOR>
Q804 8-729-209-15 TRANSISTOR 2SD2012
<RESISTOR>
R901 1-249-435-11 CARBON 33K 5% 1/4W
R902 1-249-435-11 CARBON 33K 5% 1/4W
R903 1-216-295-00 CONDUCTOR, CHIP (2012)
R905 1-216-308-00 METAL CHIP 4.7 5% 1/10W
R951 1-216-085-00 METAL CHIP 33K 5% 1/10W
R952 1-216-085-00 METAL CHIP 33K 5% 1/10W
R953 1-216-295-00 CONDUCTOR, CHIP (2012)
R955 1-216-308-00 METAL CHIP 4.7 5% 1/10W
R981 1-249-417-11 CARBON 1K 5% 1/4W
R982 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R983 1-216-081-00 METAL CHIP 22K 5% 1/10W
R984 1-216-037-00 METAL CHIP 330 5% 1/10W
R985 1-249-433-11 CARBON 22K 5% 1/4W
! R986 1-249-389-11 CARBON 4.7 5% 1/4W F
************************************************************
A-2007-131-A AUDIO BOARD, COMPLETE
(including MOTOR BOARD)
*********************
<CAPACITOR>
C301 1-162-289-31 CERAMIC 390PF 10% 50V
C302 1-126-968-11 ELECT 100uF 20% 6.3V
C303 1-162-282-31 CERAMIC 100PF 10% 50V
C304 1-130-483-00 MYLAR 0.01uF 5% 50V
C305 1-107-715-11 ELECT 22uF 20% 16V
C311 1-162-289-31 CERAMIC 390PF 10% 50V
C313 1-162-282-31 CERAMIC 100PF 10% 50V
C314 1-130-487-00 MYLAR 0.022uF 5% 50V
C315 1-126-233-11 ELECT 22uF 20% 50V
C331 1-137-427-11 FILM 120PF 5% 50V
C332 1-162-288-31 CERAMIC 330PF 10% 50V
C333 1-162-209-31 CERAMIC 27PF 5% 50V
C401 1-162-289-31 CERAMIC 390PF 10% 50V
C402 1-126-968-11 ELECT 100uF 20% 6.3V
C403 1-162-282-31 CERAMIC 100PF 10% 50V
C404 1-130-483-00 MYLAR 0.01uF 5% 50V
C405 1-107-715-11 ELECT 22uF 20% 16V
SECTION 8
ELECTRICAL PARTS LIST
AMP
AUDIO (including MOTOR)
