– 75 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R139 1-216-033-00 METAL CHIP 220 5% 1/10W
R140 1-216-081-00 METAL CHIP 22K 5% 1/10W
R141 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R142 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R143 1-216-121-00 METAL GLAZE 1M 5% 1/10W
R144 1-216-073-00 METAL CHIP 10K 5% 1/10W
R145 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R146 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R147 1-216-049-00 METAL GLAZE 1K 5% 1/10W
R148 1-216-049-00 METAL GLAZE 1K 5% 1/10W
R149 1-216-049-00 METAL GLAZE 1K 5% 1/10W
R150 1-216-037-00 METAL CHIP 330 5% 1/10W
R151 1-216-037-00 METAL CHIP 330 5% 1/10W
R152 1-216-037-00 METAL CHIP 330 5% 1/10W
R153 1-216-082-00 METAL GLAZE 24K 5% 1/10W
R154 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R156 1-216-085-00 METAL CHIP 33K 5% 1/10W
R157 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R158 1-216-001-00 METAL CHIP 10 5% 1/10W
<VARIABLE RESISTOR>
RV101 1-223-587-11
RES, ADJ, CARBON
22K
RV102 1-223-587-11
RES, ADJ, CARBON
22K
RV103 1-223-587-11
RES, ADJ, CARBON
22K
<SWITCH>
S101 1-572-085-11 SWITCH, LEAF (LIMIT SW)
<VIBRATOR>
X101 1-579-280-11 VIBRATOR, CRYSTAL (16.9344MHz)
************************************************************
* 1-650-669-11 LEAF SWITCH BOARD
*****************
<CONNECTOR>
* CN1001 1-568-854-11 SOCKET, CONNECTOR 11P
<TRANSISTOR>
Q1001 8-749-010-90 TRANSISTOR PHOTO REFLECTOR NJL5165KA-H
Q1002 8-749-010-90 TRANSISTOR PHOTO REFLECTOR NJL5165KA-H
<RESISTOR>
R1001 1-249-412-11 CARBON 390 5% 1/4W
R1002 1-249-412-11 CARBON 390 5% 1/4W
R1003 1-249-414-11 CARBON 560 5% 1/4W
R1004 1-247-834-11 CARBON 1.3K 5% 1/4W
R1005 1-247-818-11 CARBON 300 5% 1/4W
<SWITCH>
S1001 1-692-832-11 SWITCH, PUSH (1 KEY) (A PLAY)
S1002 1-692-832-11 SWITCH, PUSH (1 KEY) (B PLAY)
S1003 1-572-248-11 SWITCH, LEAF (A HALF)
S1004 1-571-281-21 SWITCH, LEAF (A CrO2)
S1005 1-571-281-21 SWITCH, LEAF (REC A)
S1006 1-572-248-11 SWITCH, LEAF (B HALF)
S1008 1-571-281-21 SWITCH, LEAF (B CrO2)
S1009 1-571-281-21 SWITCH, LEAF (REC B)
************************************************************
* 1-650-836-11 LOADING BOARD
**************
<CONNECTOR>
* CN291 1-568-943-11 PIN, CONNECTOR 5P
<SWITCH>
S291 1-572-086-11 SWITCH, LEAF (LOAD OUT)
S292 1-572-086-11 SWITCH, LEAF (LOAD IN)
************************************************************
* A-4390-037-A MAIN BOARD, COMPLETE (AEP)
* A-4390-038-A MAIN BOARD, COMPLETE (G)
* A-4390-039-A MAIN BOARD, COMPLETE (IT)
* A-4390-044-A MAIN BOARD, COMPLETE (UK)
* A-4390-050-A MAIN BOARD, COMPLETE (E3, HK)
* A-4390-057-A MAIN BOARD, COMPLETE (MY, SP)
* A-4390-062-A MAIN BOARD, COMPLETE (MX)
* A-4390-635-A MAIN BOARD, COMPLETE (E2, AR)
* A-4390-636-A MAIN BOARD, COMPLETE (EA)
* A-4390-638-A MAIN BOARD, COMPLETE (AUS)
*********************
<CAPACITOR>
C101 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
C102 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C103 1-163-019-00 CERAMIC CHIP 0.0068uF 10% 50V
C104 1-163-989-11 CERAMIC CHIP 0.033uF 10% 25V
C105 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C106 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C107 1-164-336-11 CERAMIC CHIP 0.33uF 25V
C108 1-126-964-11 ELECT 10uF 20% 50V
C109 1-163-003-11 CERAMIC CHIP 330PF 10% 50V
C110 1-162-306-11 CERAMIC 0.01uF 30% 16V
C111 1-162-306-11 CERAMIC 0.01uF 30% 16V
C112 1-162-306-11 CERAMIC 0.01uF 30% 16V
C113 1-162-306-11 CERAMIC 0.01uF 30% 16V
C121 1-162-306-11 CERAMIC 0.01uF 30% 16V
LOADING
MAIN
LEAF SWITCHBD
