Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R706 1-249-417-11 CARBON 1K 5% 1/4W
R707 1-249-417-11 CARBON 1K 5% 1/4W
R708 1-249-427-11 CARBON 6.8K 5% 1/4W
R709 1-249-429-11 CARBON 10K 5% 1/4W
R710 1-249-441-11 CARBON 100K 5% 1/4W
R731 1-249-429-11 CARBON 10K 5% 1/4W
R732 1-249-429-11 CARBON 10K 5% 1/4W
R733 1-216-073-00 METAL CHIP 10K 5% 1/10W
R734 1-249-425-11 CARBON 4.7K 5% 1/4W
R735 1-249-425-11 CARBON 4.7K 5% 1/4W
R738 1-216-095-00 METAL CHIP 82K 5% 1/10W
R739 1-249-439-11 CARBON 68K 5% 1/4W
R752 1-249-421-11 CARBON 2.2K 5% 1/4W
R754 1-249-417-11 CARBON 1K 5% 1/4W
R755 1-216-101-00 METAL CHIP 150K 5% 1/10W
R756 1-249-417-11 CARBON 1K 5% 1/4W
R757 1-249-417-11 CARBON 1K 5% 1/4W
R758 1-249-427-11 CARBON 6.8K 5% 1/4W
R759 1-249-429-11 CARBON 10K 5% 1/4W
R760 1-249-441-11 CARBON 100K 5% 1/4W
R912 1-249-389-11 CARBON 4.7 5% 1/4W
(AEP, G, IT, UK)
R913 1-249-389-11 CARBON 4.7 5% 1/4W
(AEP, G, IT, UK)
R914 1-249-393-11 CARBON 10 5% 1/4W
(AEP, G, IT, UK)
R915 1-249-417-11 CARBON 1K 5% 1/4W
R962 1-249-389-11 CARBON 4.7 5% 1/4W
(AEP, G, IT, UK)
R963 1-249-389-11 CARBON 4.7 5% 1/4W
(AEP, G, IT, UK)
R964 1-249-393-11 CARBON 10 5% 1/4W
(AEP, G, IT, UK)
R965 1-249-417-11 CARBON 1K 5% 1/4W
R972 1-249-437-11 CARBON 47K 5% 1/4W
R974 1-249-441-11 CARBON 100K 5% 1/4W
R975 1-216-085-00 METAL CHIP 33K 5% 1/10W
R976 1-249-397-11 CARBON 22 5% 1/4W
R977 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R978 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
! R979 1-215-889-00 METAL OXIDE 330 5% 2W F
R1002 1-249-425-11 CARBON 4.7K 5% 1/4W
R1003 1-216-295-00 CONDUCTOR, CHIP (2012)
R1006 1-249-425-11 CARBON 4.7K 5% 1/4W
R1009 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R1056 1-249-425-11 CARBON 4.7K 5% 1/4W
R1059 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R1201 1-249-417-11 CARBON 1K 5% 1/4W
MAIN PANEL
The components identified by mark ! or
dotted line with mark ! are critical for
safety.
Replace only with part number specified.
R1202 1-216-081-00 METAL CHIP 22K 5% 1/10W
R1204 1-216-081-00 METAL CHIP 22K 5% 1/10W
R1205 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R1207 1-216-121-00 METAL GLAZE 1M 5% 1/10W
R1251 1-249-417-11 CARBON 1K 5% 1/4W
<VARIABLE RESISTOR>
RV401 1-241-785-11 RES, ADJ, CARBON 10K
RV451 1-241-785-11 RES, ADJ, CARBON 10K
<RELAY>
RY901 1-515-921-11 RELAY (12V)
<TERMINAL>
TB901 1-694-091-11 TERMINAL BOARD (SPEAKER)
TB902 1-537-897-11 TERMINAL BOARD,PUSH (ANTENNA) 2P
(WOOFER)
<VIBRATOR>
X101 1-579-175-11 VIBRATOR, CERAMIC (10MHz)
X102 1-567-098-41 VIBRATOR, CRYSTAL (32kHz)
************************************************************
* A-4390-032-A PANEL BOARD, COMPLETE (AEP, G, IT)
* A-4390-040-A PANEL BOARD, COMPLETE (UK)
* A-4390-046-A PANEL BOARD, COMPLETE (E3, EA, HK)
* A-4390-052-A PANEL BOARD, COMPLETE (MY, SP)
* A-4390-053-A PANEL BOARD, COMPLETE (MX)
* A-4390-634-A PANEL BOARD, COMPLETE (E2, AR, AUS)
**********************
* 4-977-399-11 HOUSE, LAMP
* 4-977-400-11 HOLDER (FL)
7-682-548-04 SCREW +BVTT 3X8 (S)
<CAPACITOR>
C501 1-124-584-00 ELECT 100uF 20% 10V
C502 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C503 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C504 1-136-165-00 FILM 0.1uF 5% 50V
C505 1-136-165-00 FILM 0.1uF 5% 50V
C506 1-126-948-11 ELECT 100uF 20% 35V
C507 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C508 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C509 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C510 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C511 1-126-157-11 ELECT 10uF 20% 16V
C512 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
(E2, E3, MY, SP, EA, HK, AR)
