– 83 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
C819 1-126-967-11 ELECT 47uF 20% 10V
C831 1-126-936-11 ELECT 3300uF 20% 16V
C843 1-164-159-11 CERAMIC 0.1uF 50V
C844 1-164-159-11 CERAMIC 0.1uF 50V
C845 1-164-159-11 CERAMIC 0.1uF 50V
C848 1-164-159-11 CERAMIC 0.1uF 50V
C849 1-164-159-11 CERAMIC 0.1uF 50V
C850 1-164-159-11 CERAMIC 0.1uF 50V
C939 1-126-964-11 ELECT 10uF 20% 50V
C986 1-126-964-11 ELECT 10uF 20% 50V
<CONNECTOR>
CN801 1-691-766-11 PLUG (MICRO CONNECTOR) 4P
CN803 1-564-524-11 PLUG, CONNECTOR 9P
CN804 1-750-749-11 CONNECTOR, FFC/FPC 17P
CN805 1-564-505-11 PLUG, CONNECTOR 2P
<DIODE>
D801 8-719-302-38 DIODE RBV-602-01
D802 8-719-024-99 DIODE 11ES2-NTA2B
D803 8-719-024-99 DIODE 11ES2-NTA2B
D804 8-719-011-08 DIODE UZ-27BSC
D805 8-719-933-50 DIODE HZS7C2L
D807 8-719-109-98 DIODE RD6.8ES-B3
D808 8-719-933-54 DIODE HZS9A2L
D809 8-719-987-63 DIODE 1N4148M
D810 8-719-987-63 DIODE 1N4148M
D811 8-719-024-99 DIODE 11ES2-NTA2B
D812 8-719-024-99 DIODE 11ES2-NTA2B
D813 8-719-058-67 DIODE FMM-21S
D902 8-719-987-63 DIODE 1N4148M
D903 8-719-016-74 DIODE 1SS352
D904 8-719-016-74 DIODE 1SS352
<IC>
IC802 8-759-604-86 IC M5F7807L
<COIL>
L902 1-420-872-00 COIL, AIR-CORE
<TRANSISTOR>
Q801 8-729-018-59 TRANSISTOR 2SB1375 (LB-SONY)
Q802 8-729-018-60 TRANSISTOR 2SD2012-LC
Q805 8-729-209-60 TRANSISTOR 2SB1375
Q806 8-729-620-05 TRANSISTOR 2SC2603-EF
Q807 8-729-216-22 TRANSISTOR 2SA1162-G
Q808 8-729-216-22 TRANSISTOR 2SA1162-G
Q903 8-729-421-19 TRANSISTOR UN2213
Q904 8-729-421-19 TRANSISTOR UN2213
<RESISTOR>
R803 1-249-417-11 CARBON 1K 5% 1/4W
R804 1-249-417-11 CARBON 1K 5% 1/4W
R805 1-249-415-11 CARBON 680 5% 1/4W
R807 1-249-415-11 CARBON 680 5% 1/4W
! R808 1-213-072-00 FUSIBLE 33 5% 1W F
R809 1-249-419-11 CARBON 1.5K 5% 1/4W
R810 1-249-421-11 CARBON 2.2K 5% 1/4W
! R811 1-217-642-11 FUSIBLE 6.8 5% 1/4W F
! R812 1-217-637-00 FUSIBLE 1 5% 1/4W F
! R813 1-212-938-00 FUSIBLE 1.5 5% 1/2W F
! R816 1-212-861-11 FUSIBLE 15 5% 1/4W F
R942 1-249-429-11 CARBON 10K 5% 1/4W
R943 1-249-435-11 CARBON 33K 5% 1/4W
R944 1-249-429-11 CARBON 10K 5% 1/4W
! R987 1-249-389-11 CARBON 4.7 5% 1/4W F
************************************************************
* A-4303-532-A TCB BOARD, COMPLETE (AEP, UK)
* A-4303-533-A TCB BOARD, COMPLETE (G, IT)
* A-4303-534-A TCB BOARD, COMPLETE (E3, EA, MY, SP, HK)
* A-4303-535-A TCB BOARD, COMPLETE (E2, MX, AR, AUS)
*******************
<CAPACITOR>
C1 1-163-141-00 CERAMIC CHIP 0.001uF 5% 50V
C2 1-126-967-11 ELECT 47uF 20% 16V
C3 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C4 1-163-099-00 CERAMIC CHIP 18PF 5% 50V
(AEP, G, IT, UK)
C5 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C6 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C7 1-101-004-00 CERAMIC 0.01uF 50V
(EXCEPT AEP, G, IT, UK)
C8 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C9 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C10 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C11 1-163-038-00 CERAMIC CHIP 0.1uF 25V
(E3, EA, MY, SP, HK)
C11 1-216-295-00 METAL CHIP 0 5% 1/10W
(G, IT, E2, MX, AR, AUS)
C14 1-163-038-00 CERAMIC CHIP 0.1uF 25V
(E3, EA, MY, SP, HK)
C15 1-136-162-00 CERAMIC 0.056uF 50V
(E3, EA, MY, SP, HK)
C16 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C17 1-163-031-11 CERAMIC CHIP 0.01uF 50V
(E3, EA, MY, SP, HK)
C18 1-163-088-00 CERAMIC CHIP 5PF 50V
(E3, EA, MY, SP, HK)
TCBPS
The components identified by mark ! or
dotted line with mark ! are critical for
safety.
Replace only with part number specified.
