– 9 –
TAPE MECHANISM SECTION
1
three screws
(BVTP 2.6
×
8)
1
two screws
(BVTP 2.6
×
8)
3
tape mechanism
section
2
Open the cassette
lid ass’y.
CASSETTE LID ASS’Y
1
two springs
2
two screws
(BVTP2.6
×
8)
4
bracket (FR)
5
cassette lid ass’y
3
bracket (FL)
