Sony HCD-HDX265 - MAIN BOARD WAVEFORMS; Main Board Waveform Examples

67
HCD-HDX265/HDX266/HDX267W/HDX465/HDX466/HDX665
• Waveforms
– MAIN Board –
1
IC1101 <z,x (R/Cr/Pr)
500 mV/DIV, 20 µ s/DIV
H
0.76 Vp-p
2
IC1101 <z,c (B/Cb/Pb)
500 mV/DIV, 20 µ s/DIV
H
0.67 Vp-p
3
IC1101 <z,b (Y/G)
IC1101 <z,m (CVBS)
500 mV/DIV, 20 µ s/DIV
H
1 Vp-p
6
IC1101 <z.z (Y)
500 mV/DIV, 20 µ s/DIV
H
1 Vp-p
4
500 mV/DIV, 20 µ s/DIV
5
IC1101 <z,. (C)
500 mV/DIV, 20 µ s/DIV
0.9 Vp-p
37 ns
3.3 Vp-p
7
IC1101 <xcv (XTALI)
1 V/DIV, 20 ns/DIV
37 ns
3.3 Vp-p
8
IC1111 6
1 V/DIV, 20 ns/DIV
9
IC501 qd (XOUT)
1 V/DIV, 100 ns/DIV
200 ns
3.4 Vp-p
qa
IC3051 4 (OUT)
1 V/DIV, 20 ns/DIV
20.4 ns
5 Vp-p
qs
IC3010 rk (XFSOIN)
1 V/DIV, 20 ns/DIV
20.4 µ s
4.8 Vp-p
qf
IC3020 rk (XFSOIN)
qd
IC3010 qf (XFSOOUT)
1 V/DIV, 20 ns/DIV
20.4 µ s
4.5 Vp-p
1 V/DIV, 20 ns/DIV
20.4 µ s
3.3 Vp-p
H
1.2 Vp-p
H
