Sony HCD-HDX265 - ELECTRICAL PARTS LIST (CONTINUED); EN Board and LED Board Parts

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
95
HCD-HDX265/HDX266/HDX267W/HDX465/HDX466/HDX665
EN BOARD
********
< CAPACITOR >
C910 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C911 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
< SWITCH >
S910 1-418-725-51 ENCODER, ROTARY (12 TYPE) (VOLUME)
************************************************************
ENCODER BOARD (Included in RELAY board)
**************
************************************************************
A-1221-014-A FL BOARD, COMPLETE
******************
< CAPACITOR >
C800 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C801 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C803 1-162-995-11 CERAMIC CHIP 0.022uF 50V
C804 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C810 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C811 1-126-786-11 ELECT 47uF 20% 16V
C813 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V
C814 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C815 1-110-563-11 CERAMIC CHIP 0.068uF 10% 16V
C816 1-162-925-11 CERAMIC CHIP 68PF 5% 50V
C817 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C818 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C820 1-126-791-11 ELECT 10uF 20% 35V
C821 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C822 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C824 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C825 1-126-382-11 ELECT 100uF 20% 16V
C826 1-126-786-11 ELECT 47uF 20% 16V
C827 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C828 1-126-791-11 ELECT 10uF 20% 35V
C829 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C830 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C831 1-124-222-91 ELECT 22uF 20% 6.3V
C832 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C833 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C836 1-126-382-11 ELECT 100uF 20% 16V
C838 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C840 1-163-037-11 CERAMIC CHIP 0.022uF 10% 50V
C842 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C843 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C844 1-119-943-11 ELECT 47uF 20% 50V
C846 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C850 1-126-791-11 ELECT 10uF 20% 35V
C851 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C866 1-115-866-11 ELECT 4.7uF 20% 35V
C868 1-126-791-11 ELECT 10uF 20% 35V
< CONNECTOR >
CN803 1-779-560-21 CONNECTOR, FFC (LIF (NON-ZIF)) 23P
CN804 1-779-978-11 PIN, CONNECTOR 3P
CN805 1-564-718-11 PIN, CONNECTOR (SMALL TYPE) 2P
< DIODE >
D800 6-501-579-01 DIODE MC2837
D801 6-501-579-01 DIODE MC2837
D806 6-501-193-01 DIODE 1SS355WTE-17
D807 6-501-193-01 DIODE 1SS355WTE-17
D808 6-501-193-01 DIODE 1SS355WTE-17
D809 8-719-056-13 LED SML79423C-TP15 (DISC 1)
D810 6-501-193-01 DIODE 1SS355WTE-17
D811 6-501-193-01 DIODE 1SS355WTE-17
D812 8-719-056-13 LED SML79423C-TP15 (DISC 2)
D813 6-501-193-01 DIODE 1SS355WTE-17
D814 6-501-193-01 DIODE 1SS355WTE-17
D815 6-501-169-01 DIODE UDZW-TE17-6.2B
D816 8-719-056-13 LED SML79423C-TP15 (DISC 3)
D817 8-719-056-13 LED SML79423C-TP15 (DISC 4)
D818 8-719-056-13 LED SML79423C-TP15 (DISC 5)
< FERRITE BEAD >
FB802 1-500-236-22 BEAD, FERRITE (CHIP) (1608)
FB803 1-500-236-22 BEAD, FERRITE (CHIP) (1608)
FB804 1-500-236-22 BEAD, FERRITE (CHIP) (1608)
FB806 1-500-236-22 BEAD, FERRITE (CHIP) (1608)
FB807 1-500-236-22 BEAD, FERRITE (CHIP) (1608)
< IC >
IC800 8-759-100-96 IC uPC4558G2
IC801 8-759-100-96 IC uPC4558G2
IC802 6-704-046-01 IC BU2099FV
IC803 6-600-349-21 IC NJL23H400A
IC804 8-759-643-83 IC uPD16315GB-3BS
< JACK >
J800 1-819-878-31 JACK (PHONES)
J801 1-819-878-31 JACK (AUDIO IN/A.CAL MIC)
< JUMPER RESISTOR >
JR801 1-216-296-11 SHORT CHIP 0
JR802 1-216-296-11 SHORT CHIP 0
JR803 1-216-296-11 SHORT CHIP 0
JR804 1-216-296-11 SHORT CHIP 0
JR805 1-216-296-11 SHORT CHIP 0
JR806 1-216-296-11 SHORT CHIP 0
JR807 1-216-296-11 SHORT CHIP 0
JR808 1-216-296-11 SHORT CHIP 0
JR809 1-216-296-11 SHORT CHIP 0
JR810 1-216-296-11 SHORT CHIP 0
JR811 1-216-296-11 SHORT CHIP 0
JR812 1-216-296-11 SHORT CHIP 0
JR813 1-216-296-11 SHORT CHIP 0
JR814 1-216-296-11 SHORT CHIP 0
JR815 1-216-296-11 SHORT CHIP 0
JR817 1-216-296-11 SHORT CHIP 0
JR818 1-216-296-11 SHORT CHIP 0
EN ENCODER FL
