Sony HCD-HDX265 - ELECTRICAL PARTS LIST (CONTINUED); Capacitor, Connector, Diode, IC, and Coil Parts

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
97
HCD-HDX265/HDX266/HDX267W/HDX465/HDX466/HDX665
R893 1-216-805-11 METAL CHIP 47 5% 1/10W
R894 1-216-815-11 METAL CHIP 330 5% 1/10W
R897 1-216-845-11 METAL CHIP 100K 5% 1/10W
R899 1-216-821-11 METAL CHIP 1K 5% 1/10W
R900 1-216-809-11 METAL CHIP 100 5% 1/10W
R901 1-216-809-11 METAL CHIP 100 5% 1/10W
R902 1-216-809-11 METAL CHIP 100 5% 1/10W
R903 1-216-844-11 METAL CHIP 82K 5% 1/10W
R904 1-216-809-11 METAL CHIP 100 5% 1/10W
< SWITCH >
S800 1-771-349-41 SWITCH, KEYBOARD (>)
S801 1-771-349-41 SWITCH, KEYBOARD (x)
S802 1-771-349-41 SWITCH, KEYBOARD (X)
S803 1-771-349-41 SWITCH, KEYBOARD (.)
S804 1-771-349-41 SWITCH, KEYBOARD (FUNCTION)
S805 1-771-349-41 SWITCH, KEYBOARD (DISC 1)
S806 1-771-349-41 SWITCH, KEYBOARD (DISC 2)
S807 1-771-349-41 SWITCH, KEYBOARD (DISC 3)
S808 1-771-349-41 SWITCH, KEYBOARD (DISC 4)
S809 1-771-349-41 SWITCH, KEYBOARD (DISC 5)
S810 1-771-349-41 SWITCH, KEYBOARD (A)
S811 1-771-349-41 SWITCH, KEYBOARD (H)
< TRANSFORMER >
T800 1-443-645-11 TRANSFORMER, DC CONVERTER
************************************************************
A-1221-023-A IO BOARD, COMPLETE
************
< CAPACITOR >
C300 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C301 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C302 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C303 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C311 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C312 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C316 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C317 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C321 1-104-662-91 ELECT 22uF 20% 25V
C322 1-104-662-91 ELECT 22uF 20% 25V
C323 1-104-662-91 ELECT 22uF 20% 25V
C324 1-104-662-91 ELECT 22uF 20% 25V
C328 1-126-916-11 ELECT 1000uF 20% 6.3V
C330 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C331 1-126-916-11 ELECT 1000uF 20% 6.3V
C332 1-126-933-11 ELECT 100uF 20% 16V
C333 1-126-933-11 ELECT 100uF 20% 16V
C334 1-126-916-11 ELECT 1000uF 20% 6.3V
C337 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C338 1-126-933-11 ELECT 100uF 20% 16V
C340 1-104-662-91 ELECT 22uF 20% 25V
C341 1-104-662-91 ELECT 22uF 20% 25V
C343 1-126-964-11 ELECT 10uF 20% 50V
C344 1-126-964-11 ELECT 10uF 20% 50V
C347 1-126-935-11 ELECT 470uF 20% 16V
C348 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C349 1-126-933-11 ELECT 100uF 20% 16V
C350 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C351 1-126-933-11 ELECT 100uF 20% 16V
C352 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C355 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C357 1-126-964-11 ELECT 10uF 20% 50V
C358 1-126-964-11 ELECT 10uF 20% 50V
C359 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C360 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C361 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C371 1-104-662-91 ELECT 22uF 20% 25V
C372 1-104-662-91 ELECT 22uF 20% 25V
C373 1-104-662-91 ELECT 22uF 20% 25V
C374 1-104-662-91 ELECT 22uF 20% 25V
C376 1-104-662-91 ELECT 22uF 20% 25V
C383 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C384 1-126-933-11 ELECT 100uF 20% 16V
C385 1-126-960-11 ELECT 1uF 20% 50V
C386 1-126-960-11 ELECT 1uF 20% 50V
C387 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C388 1-127-573-11 CERAMIC CHIP 1uF 10% 16V
C389 1-126-947-11 ELECT 47uF 20% 35V
C391 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C392 1-126-933-11 ELECT 100uF 20% 16V
< CONNECTOR >
CN301 1-779-277-11 CONNECTOR, FFC (LIF (NON-ZIF)) 9P
CN302 1-564-706-11 PIN, CONNECTOR (SMALL TYPE) 4P
CN304 1-779-279-11 CONNECTOR, FFC (LIF (NON-ZIF)) 11P
CN305 1-568-828-11 CONNECTOR, FFC 9P
CN306 1-779-287-11 CONNECTOR, FFC (LIF (NON-ZIF)) 19P
CN307 1-779-273-11 CONNECTOR, FFC (LIF (NON-ZIF)) 5P
< DIODE >
D300 6-501-193-01 DIODE 1SS355WTE-17
D301 6-501-193-01 DIODE 1SS355WTE-17
D309 8-719-058-24 DIODE RB501V-40TE-17
< IC >
IC301 6-703-622-01 IC MM1508XNRE
IC302 6-710-470-01 IC MM1758AFBE
IC303 8-759-385-76 IC MC14052 BDR2
IC306 8-759-100-96 IC uPC4558G2
IC307 6-703-550-01 IC TA7809LS
< JACK/TERMINAL BOARD >
J300 1-764-593-21 JACK 2P (TV/VIDEO AUDIO IN)
J301 1-780-211-11 TERMINAL BOARD (S TERMINAL+1P)
(MONITOR OUT VIDEO/S VIDEO (DVD ONLY))
J302 1-817-449-11 JACK, PIN 3P
(COMPONENT VIDEO OUT (DVD ONLY))
< COIL >
L300 1-469-525-11 INDUCTOR 10uH
L301 1-469-525-11 INDUCTOR 10uH
L304 1-469-525-11 INDUCTOR 10uH
IOFL
