Sony HCD-PZ1D - Sony HCD-PZ1 D DMB19 Board Parts

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-PZ1D
9393
< IC >
IC101 6-714-820-01 IC CXD9970R (LE)
IC102 A-1814-066-A
IC MX25L6445EM2I-10G (for SERVICE)
IC103 (Not supplied) IC S-24CS16A0I-J8T1G
IC104 6-714-642-01 IC EM638165 TSA-6G
IC105 6-702-302-01 IC TK11133CSCL-G
IC107 6-702-302-01 IC TK11133CSCL-G
IC111 6-706-838-01 IC MM1661JHBE
IC201 6-704-524-01 IC FAN8036L
IC4601 6-710-554-01 IC PCM1808PWR
IC4602 6-704-819-01 IC CS4335-KSZR
< TRANSISTOR >
Q101 6-550-008-01 FET UM6K1N-TN
Q102 6-550-653-01 TRANSISTOR QST8TR
Q103 8-729-029-06 TRANSISTOR DTC124EUA-T106
< RESISTOR >
R101 1-216-809-11 METAL CHIP 100 5% 1/10W
R102 1-216-864-11 SHORT CHIP 0
R103 1-218-864-11 METAL CHIP 5.1K 0.5% 1/10W
R107 1-216-833-11 METAL CHIP 10K 5% 1/10W
R108 1-216-857-11 METAL CHIP 1M 5% 1/10W
R109 1-216-809-11 METAL CHIP 100 5% 1/10W
R110 1-216-841-11 METAL CHIP 47K 5% 1/10W
R111 1-216-809-11 METAL CHIP 100 5% 1/10W
R112 1-211-977-11 METAL CHIP 22 0.5% 1/10W
R113 1-211-977-11 METAL CHIP 22 0.5% 1/10W
R114 1-216-845-11 METAL CHIP 100K 5% 1/10W
R115 1-211-977-11 METAL CHIP 22 0.5% 1/10W
R116 1-216-821-11 METAL CHIP 1K 5% 1/10W
R117 1-216-841-11 METAL CHIP 47K 5% 1/10W
R118 1-216-801-11 METAL CHIP 22 5% 1/10W
R120 1-216-801-11 METAL CHIP 22 5% 1/10W
R121 1-216-801-11 METAL CHIP 22 5% 1/10W
R122 1-216-833-11 METAL CHIP 10K 5% 1/10W
R123 1-216-809-11 METAL CHIP 100 5% 1/10W
R124 1-216-841-11 METAL CHIP 47K 5% 1/10W
R125 1-216-833-11 METAL CHIP 10K 5% 1/10W
R133 1-216-864-11 SHORT CHIP 0
R135 1-216-833-11 METAL CHIP 10K 5% 1/10W
R136 1-216-835-11 METAL CHIP 15K 5% 1/10W
R142 1-216-845-11 METAL CHIP 100K 5% 1/10W
R151 1-216-833-11 METAL CHIP 10K 5% 1/10W
R154 1-216-295-91 SHORT CHIP 0
R155 1-216-295-91 SHORT CHIP 0
R156 1-216-809-11 METAL CHIP 100 5% 1/10W
R191 1-216-821-11 METAL CHIP 1K 5% 1/10W
R192 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R193 1-216-821-11 METAL CHIP 1K 5% 1/10W
R195 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R197 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R198 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R204 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
R205 1-216-833-11 METAL CHIP 10K 5% 1/10W
R206 1-216-833-11 METAL CHIP 10K 5% 1/10W
R207 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
R208 1-216-839-11 METAL CHIP 33K 5% 1/10W
R209 1-216-839-11 METAL CHIP 33K 5% 1/10W
R210 1-216-841-11 METAL CHIP 47K 5% 1/10W
R212 1-216-833-11 METAL CHIP 10K 5% 1/10W
R213 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R214 1-216-835-11 METAL CHIP 15K 5% 1/10W
R215 1-216-834-11 METAL CHIP 12K 5% 1/10W
R216 1-216-834-11 METAL CHIP 12K 5% 1/10W
R219 1-216-838-11 METAL CHIP 27K 5% 1/10W
R220 1-216-821-11 METAL CHIP 1K 5% 1/10W
R221 1-218-889-11 METAL CHIP 56K 0.5% 1/10W
R223 1-218-895-11 METAL CHIP 100K 0.5% 1/10W
R224 1-216-833-11 METAL CHIP 10K 5% 1/10W
R225 1-218-895-11 METAL CHIP 100K 0.5% 1/10W
R226 1-218-889-11 METAL CHIP 56K 0.5% 1/10W
R230 1-218-893-11 METAL CHIP 82K 0.5% 1/10W
R231 1-218-875-11 METAL CHIP 15K 0.5% 1/10W
R232 1-218-877-11 METAL CHIP 18K 0.5% 1/10W
R233 1-218-883-11 METAL CHIP 33K 0.5% 1/10W
R234 1-216-833-11 METAL CHIP 10K 5% 1/10W
R246 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R247 1-216-821-11 METAL CHIP 1K 5% 1/10W
R256 1-216-833-11 METAL CHIP 10K 5% 1/10W
R521 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1029 1-216-864-11 SHORT CHIP 0
R1032 1-216-864-11 SHORT CHIP 0
R1101 1-218-841-11 METAL CHIP 560 0.5% 1/10W
R1110 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
R1114 1-216-801-11 METAL CHIP 22 5% 1/10W
R1121 1-216-864-11 SHORT CHIP 0
R1123 1-216-864-11 SHORT CHIP 0
R1129 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1150 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R1151 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R1152 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R1168 1-218-835-11 METAL CHIP 330 0.5% 1/10W
R1177 1-216-864-11 SHORT CHIP 0
R1178 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1184 1-216-809-11 METAL CHIP 100 5% 1/10W
R1187 1-216-813-11 METAL CHIP 220 5% 1/10W
R1191 1-216-864-11 SHORT CHIP 0
R1192 1-216-864-11 SHORT CHIP 0
R1193 1-216-864-11 SHORT CHIP 0
R1194 1-216-864-11 SHORT CHIP 0
R1249 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1252 1-216-295-91 SHORT CHIP 0
R1253 1-216-295-91 SHORT CHIP 0
R1255 1-216-295-91 SHORT CHIP 0
R1257 1-216-864-11 SHORT CHIP 0
R1258 1-216-864-11 SHORT CHIP 0
R1259 1-216-864-11 SHORT CHIP 0
R1260 1-216-864-11 SHORT CHIP 0
R1261 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1262 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1263 1-216-864-11 SHORT CHIP 0
R1269 1-216-809-11 METAL CHIP 100 5% 1/10W
R1270 1-216-864-11 SHORT CHIP 0
R1271 1-216-864-11 SHORT CHIP 0
R1276 1-216-864-11 SHORT CHIP 0
R1277 1-216-809-11 METAL CHIP 100 5% 1/10W
R1278 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1279 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1280 1-216-864-11 SHORT CHIP 0
DMB19
Note: IC103 on the DMB19 board cannot exchange with single. When
this part is damaged, exchange the complete mounted board.
