Sony HCD-PZ1D - SECTION 2 DISASSEMBLY; Sony HCD-PZ1 D Disassembly Flowchart

HCD-PZ1D
9
SECTION 2
DISASSEMBLY
• This set can be disassembled in the order shown below.
2-1. DISASSEMBLY FLOW
2-5. BASE PLATE
(Page 11)
2-6. CAM RING (SHUTTER)
(Page 12)
2-7. TORSION SPRING (A)
(Page 12)
2-8. RING (OPERATING)
(Page 13)
2-22. BACK PANEL
BLOCK
(Page 22)
2-13. RIGHT BOARD,
LEFT BOARD
(Page 16)
2-11. FRONT PANEL BLOCK
(Page 15)
2-12. VOL-LED BOARD
(Page 16)
2-23. MAIN BOARD
(Page 23)
2-25. VIDEO BOARD
(Page 25)
2-24. AMP BOARD
(Page 24)
2-15. LCD CTRL BOARD
(Page 17)
2-19. BU HOLDER BLOCK
(Page 20)
2-20. DMB19 BOARD
(Page 21)
2-21. OPTICAL PICK-UP
(KHM-313CAB)
(Page 21)
2-17. SUB PANEL LCD
BLOCK
(Page 19)
2-18. LCD MODULE
(LCD101)
(Page 19)
2-14. FRONT BOARD
(Page 17)
2-16. MIC BOARD
(Page 18)
2-26. MECHANISM DECK
(CDM74HFV ASSY)
(Page 25)
2-28. SENSOR BOARD
(Page 26)
2-27. DRIVER BOARD,
SW BOARD
(Page 26)
2-29. MOTOR (TB) BOARD
(Page 27)
2-30. MOTOR (LD) BOARD
(Page 27)
2-9. CHASSIS BLOCK
(Page 13)
2-10. LOADING PANEL
(Page 14)
2-4. CORD
(WITH PLUG) (J1)
(Page 11)
SET
2-3. TOP PANEL BLOCK
(Page 10)
2-2. CASE (SIDE L),
CASE (SIDE L)
(Page 10)
