Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-PZ1D
9595
R703 1-216-818-11 METAL CHIP 560 5% 1/10W
R704 1-216-818-11 METAL CHIP 560 5% 1/10W
R705 1-216-818-11 METAL CHIP 560 5% 1/10W
R706 1-216-818-11 METAL CHIP 560 5% 1/10W
R707 1-216-818-11 METAL CHIP 560 5% 1/10W
R708 1-216-818-11 METAL CHIP 560 5% 1/10W
R709 1-216-818-11 METAL CHIP 560 5% 1/10W
R710 1-216-818-11 METAL CHIP 560 5% 1/10W
R801 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R802 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R803 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R804 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R805 1-216-809-11 METAL CHIP 100 5% 1/10W
R806 1-216-809-11 METAL CHIP 100 5% 1/10W
R807 1-216-809-11 METAL CHIP 100 5% 1/10W
R808 1-216-809-11 METAL CHIP 100 5% 1/10W
R811 1-216-841-11 METAL CHIP 47K 5% 1/10W
R812 1-216-845-11 METAL CHIP 100K 5% 1/10W
R813 1-216-837-11 METAL CHIP 22K 5% 1/10W
R814 1-216-837-11 METAL CHIP 22K 5% 1/10W
R817 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
R818 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R819 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R820 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R821 1-216-813-11 METAL CHIP 220 5% 1/10W
R822 1-216-815-11 METAL CHIP 330 5% 1/10W
R823 1-216-817-11 METAL CHIP 470 5% 1/10W
R824 1-216-819-11 METAL CHIP 680 5% 1/10W
R825 1-216-821-11 METAL CHIP 1K 5% 1/10W
R831 1-216-813-11 METAL CHIP 220 5% 1/10W
R832 1-216-815-11 METAL CHIP 330 5% 1/10W
R833 1-216-817-11 METAL CHIP 470 5% 1/10W
R834 1-216-819-11 METAL CHIP 680 5% 1/10W
R835 1-216-821-11 METAL CHIP 1K 5% 1/10W
R841 1-216-813-11 METAL CHIP 220 5% 1/10W
R842 1-216-815-11 METAL CHIP 330 5% 1/10W
R843 1-216-817-11 METAL CHIP 470 5% 1/10W
R844 1-216-819-11 METAL CHIP 680 5% 1/10W
R851 1-216-821-11 METAL CHIP 1K 5% 1/10W
R852 1-216-821-11 METAL CHIP 1K 5% 1/10W
R853 1-216-809-11 METAL CHIP 100 5% 1/10W
R854 1-218-285-11 METAL CHIP 75 5% 1/10W
R855 1-216-820-11 METAL CHIP 820 5% 1/10W
R856 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R857 1-216-833-11 METAL CHIP 10K 5% 1/10W
R858 1-216-845-11 METAL CHIP 100K 5% 1/10W
R865 1-216-807-11 METAL CHIP 68 5% 1/10W
R866 1-216-821-11 METAL CHIP 1K 5% 1/10W
< ROTARY ENCODER/SWITCH >
S811 1-480-109-11 ENCODER, ROTARY (MASTER VOLUME)
S812 1-771-410-21 SWITCH, TACTILE (\/1)
S821 1-771-410-21 SWITCH, TACTILE (DISC SKIP/EXCHANGE)
S822 1-771-410-21 SWITCH, TACTILE (OPEN/CLOSE Z)
S823 1-771-410-21 SWITCH, TACTILE (DISC 3)
S824 1-771-410-21 SWITCH, TACTILE (DISC 2)
S825 1-771-410-21 SWITCH, TACTILE (DISC 1)
S831 1-771-410-21 SWITCH, TACTILE (SUBWOOFER)
S832 1-771-410-21 SWITCH, TACTILE (EQ BAND/MEMORY)
S833 1-771-410-21 SWITCH, TACTILE (SOUND FIELD)
S834 1-771-410-21 SWITCH, TACTILE (OPTIONS)
S835 1-771-410-21 SWITCH, TACTILE (PRESET EQ)
S841 1-786-289-11 SWITCH, DETECTION (OPERATION DIAL)
S844 1-771-410-21 SWITCH, TACTILE (REC TO USB)
************************************************************
JUNC BOARD
***********
< CONNECTOR >
CN410 1-564-706-11 PIN, CONNECTOR (SMALL TYPE) 4P
< RESISTOR >
R490 1-216-809-11 METAL CHIP 100 5% 1/10W
R491 1-216-809-11 METAL CHIP 100 5% 1/10W
R492 1-218-285-11 METAL CHIP 75 5% 1/10W
< VARISTOR >
VDR490 1-803-974-21 VARISTOR, CHIP (1608)
VDR491 1-803-974-21 VARISTOR, CHIP (1608)
************************************************************
A-1814-057-A LCD CTRL BOARD, COMPLETE
************************
< CAPACITOR >
C001 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C002 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C003 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C004 1-126-964-11 ELECT 10uF 20% 50V
C005 1-126-382-11 ELECT 100uF 20% 16V
C006 1-126-382-11 ELECT 100uF 20% 16V
C007 1-126-382-11 ELECT 100uF 20% 16V
C008 1-162-916-11 CERAMIC CHIP 12PF 5% 50V
C009 1-162-916-11 CERAMIC CHIP 12PF 5% 50V
C010 1-162-916-11 CERAMIC CHIP 12PF 5% 50V
C011 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
C012 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C016 1-126-382-11 ELECT 100uF 20% 16V
C017 1-126-791-11 ELECT 10uF 20% 35V
C018 1-126-791-11 ELECT 10uF 20% 35V
C019 1-126-382-11 ELECT 100uF 20% 16V
C021 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C022 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C023 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C024 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C025 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C026 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C027 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C028 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C029 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C032 1-162-916-11 CERAMIC CHIP 12PF 5% 50V
C033 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C035 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C036 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C037 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C038 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C040 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C041 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C042 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C043 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
FRONT LCD CTRLJUNC
