Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-PZ1D
9797
R063 1-216-809-11 METAL CHIP 100 5% 1/10W
R064 1-216-833-11 METAL CHIP 10K 5% 1/10W
R065 1-216-833-11 METAL CHIP 10K 5% 1/10W
R066 1-216-815-11 METAL CHIP 330 5% 1/10W
R067 1-216-841-11 METAL CHIP 47K 5% 1/10W
R068 1-216-850-11 METAL CHIP 270K 5% 1/10W
R069 1-216-839-11 METAL CHIP 33K 5% 1/10W
R070 1-216-849-11 METAL CHIP 220K 5% 1/10W
R071 1-216-849-11 METAL CHIP 220K 5% 1/10W
R073 1-216-295-91 SHORT CHIP 0
R074 1-216-295-91 SHORT CHIP 0
R075 1-216-295-91 SHORT CHIP 0
R076 1-216-295-91 SHORT CHIP 0
R079 1-216-833-11 METAL CHIP 10K 5% 1/10W
R080 1-216-809-11 METAL CHIP 100 5% 1/10W
R081 1-216-797-11 METAL CHIP 10 5% 1/10W
R082 1-216-797-11 METAL CHIP 10 5% 1/10W
R084 1-216-295-91 SHORT CHIP 0
R085 1-216-295-91 SHORT CHIP 0
R086 1-216-295-91 SHORT CHIP 0
R087 1-216-295-91 SHORT CHIP 0
R088 1-216-295-91 SHORT CHIP 0
R089 1-216-295-91 SHORT CHIP 0
R090 1-216-295-91 SHORT CHIP 0
R091 1-216-295-91 SHORT CHIP 0
R092 1-216-295-91 SHORT CHIP 0
R093 1-216-295-91 SHORT CHIP 0
R094 1-216-295-91 SHORT CHIP 0
< VIBRATOR >
X001 1-814-379-11 VIBRATOR, CRYSTAL (27MHz)
************************************************************
LEFT BOARD
**********
< CONNECTOR >
* CN731 1-564-724-11 PIN, CONNECTOR (SMALL TYPE) 8P
< LED >
D735 6-502-401-11 LED 1L434FA22E0TDT01 (DVD)
D736 6-502-401-11 LED 1L434FA22E0TDT01 (USB)
D737 6-502-401-11 LED 1L434FA22E0TDT01 (TUNER/BAND)
D738 6-502-401-11 LED 1L434FA22E0TDT01 (VIDEO/SAT)
< RESISTOR >
R730 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R731 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R732 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R733 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R734 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R735 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R736 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R737 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R738 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
< SWITCH >
S731 1-771-410-21 SWITCH, TACTILE (GROOVE)
S732 1-771-410-21 SWITCH, TACTILE (VIDEO/SAT)
S733 1-771-410-21 SWITCH, TACTILE (TUNER/BAND)
S734 1-771-410-21 SWITCH, TACTILE (USB)
S735 1-771-410-21 SWITCH, TACTILE (DVD)
************************************************************
A-1814-051-A MAIN BOARD, COMPLETE (E2)
A-1814-071-A MAIN BOARD, COMPLETE (E51, AR)
A-1814-073-A MAIN BOARD, COMPLETE (MX)
A-1814-076-A MAIN BOARD, COMPLETE (BR)
********************
7-685-646-71 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
C101 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C102 1-126-964-11 ELECT 10uF 20% 50V
C103 1-126-964-11 ELECT 10uF 20% 50V
C104 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C105 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C106 1-126-934-11 ELECT 220uF 20% 16V
C107 1-126-959-11 ELECT 0.47uF 20% 50V
C108 1-126-964-11 ELECT 10uF 20% 50V
C115 1-126-964-11 ELECT 10uF 20% 50V
C116 1-126-964-11 ELECT 10uF 20% 50V
C121 1-126-964-11 ELECT 10uF 20% 50V
C122 1-126-964-11 ELECT 10uF 20% 50V
C129 1-126-964-11 ELECT 10uF 20% 50V
C130 1-126-964-11 ELECT 10uF 20% 50V
C131 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C132 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C133 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C134 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C135 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C136 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C137 1-126-964-11 ELECT 10uF 20% 50V
C138 1-126-964-11 ELECT 10uF 20% 50V
C139 1-110-563-11 CERAMIC CHIP 0.068uF 10% 16V
C140 1-110-563-11 CERAMIC CHIP 0.068uF 10% 16V
C141 1-126-961-11 ELECT 2.2uF 20% 50V
C142 1-126-961-11 ELECT 2.2uF 20% 50V
C143 1-136-167-00 FILM 0.15uF 5% 50V
C144 1-136-167-00 FILM 0.15uF 5% 50V
C145 1-136-170-00 FILM 0.27uF 5% 50V
C146 1-136-170-00 FILM 0.27uF 5% 50V
C147 1-126-960-11 ELECT 1uF 20% 50V
C148 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C149 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C150 1-114-146-91 CERAMIC CHIP 0.047uF 10% 25V
C151 1-126-964-11 ELECT 10uF 20% 50V
C152 1-126-964-11 ELECT 10uF 20% 50V
C155 1-126-964-11 ELECT 10uF 20% 50V
C156 1-126-964-11 ELECT 10uF 20% 50V
C158 1-126-959-11 ELECT 0.47uF 20% 50V
C160 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C161 1-104-662-91 ELECT 22uF 20% 25V
C162 1-126-961-11 ELECT 2.2uF 20% 50V
C163 1-124-465-00 ELECT 0.47uF 20% 50V
C164 1-126-961-11 ELECT 2.2uF 20% 50V
C165 1-126-957-11 ELECT 0.22uF 20% 50V
C167 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C170 1-137-190-91 FILM 0.22uF 5% 50V
C171 1-126-964-11 ELECT 10uF 20% 50V
C172 1-126-964-11 ELECT 10uF 20% 50V
LCD CTRL MAINLEFT
Ver. 1.1
