64
HCD-RV2/RV5/RV6
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
C326 1-130-491-00 MYLAR 0.047uF 5% 50V
C327 1-130-476-00 MYLAR 0.0027uF 5% 50V
C328 1-130-476-00 MYLAR 0.0027uF 5% 50V
C331 1-130-491-00 MYLAR 0.047uF 5% 50V
C332 1-136-167-00 FILM 0.15uF 5% 50V
C333 1-136-167-00 FILM 0.15uF 5% 50V
C334 1-136-167-00 FILM 0.15uF 5% 50V
C335 1-165-128-11 CERAMIC CHIP 0.22uF 16V
(RV5/RV6)
C336 1-126-964-11 ELECT 10uF 20% 50V
C337 1-136-167-00 FILM 0.15uF 5% 50V
C338 1-126-957-11 ELECT 0.22uF 20% 50V
C339 1-164-373-11 CERAMIC CHIP 0.033uF 25V
(RV5/RV6)
C340 1-165-128-11 CERAMIC CHIP 0.22uF 16V
(RV5/RV6)
C341 1-164-005-11 CERAMIC CHIP 0.47uF 25V
(RV5/RV6)
C342 1-165-128-11 CERAMIC CHIP 0.22uF 16V
(RV5/RV6)
C343 1-126-947-11 ELECT 47uF 20% 16V
C344 1-165-128-11 CERAMIC CHIP 0.22uF 16V
(RV5/RV6)
C345 1-165-128-11 CERAMIC CHIP 0.22uF 16V
(RV5/RV6)
C346 1-126-933-11 ELECT 100uF 20% 16V
C347 1-126-964-11 ELECT 10uF 20% 50V
C348 1-126-964-11 ELECT 10uF 20% 50V
C349 1-126-964-11 ELECT 10uF 20% 50V
(RV2)
C350 1-126-964-11 ELECT 10uF 20% 50V
(RV2)
C351 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
(RV5/RV6)
C352 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
(RV5/RV6)
C353 1-164-733-11 CERAMIC CHIP 820PF 10% 50V
(RV5/RV6)
C354 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
(RV5/RV6)
C355 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(RV5/RV6)
C356 1-164-361-11 CERAMIC CHIP 0.047uF 16V
(RV5/RV6)
C357 1-104-665-11 ELECT 100uF 20% 10V
C358 1-126-963-11 ELECT 4.7uF 20% 50V
(RV5/RV6)
C359 1-126-963-11 ELECT 4.7uF 20% 50V
(RV5/RV6)
C360 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C361 1-164-005-11 CERAMIC CHIP 0.47uF 25V
C362 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C363 1-107-717-11 ELECT 47uF 20% 50V
C364 1-109-953-11 ELECT 2.2uF 20% 50V
C365 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(RV5/RV6)
C366 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(RV5/RV6)
C367 1-126-963-11 ELECT 4.7uF 20% 50V
(RV5/RV6)
C368 1-126-963-11 ELECT 4.7uF 20% 50V
(RV5/RV6)
C369 1-126-963-11 ELECT 4.7uF 20% 50V
(RV5/RV6)
C370 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(RV5/RV6)
C371 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C372 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C375 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C376 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C377 1-126-963-11 ELECT 4.7uF 20% 50V
(RV5/RV6)
C378 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(RV5/RV6)
C379 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(RV5/RV6)
C380 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(RV5/RV6)
C381 1-104-665-11 ELECT 100uF 20% 10V
C382 1-126-961-11 ELECT 2.2uF 20% 50V
C383 1-126-961-11 ELECT 2.2uF 20% 50V
C384 1-126-963-11 ELECT 4.7uF 20% 50V
(RV5/RV6)
C387 1-126-961-11 ELECT 2.2uF 20% 50V
(RV2)
C388 1-126-961-11 ELECT 2.2uF 20% 50V
(RV2)
C389 1-162-941-11 CERAMIC CHIP 10PF 0.5PF 50V
(RV2)
C390 1-162-941-11 CERAMIC CHIP 10PF 0.5PF 50V
(RV2)
C391 1-126-961-11 ELECT 2.2uF 20% 50V
(RV2)
C392 1-126-961-11 ELECT 2.2uF 20% 50V
(RV2)
C393 1-126-933-11 ELECT 100uF 20% 16V
(RV2)
C394 1-164-361-11 CERAMIC CHIP 0.047uF 16V
C395 1-165-128-11 CERAMIC CHIP 0.22uF 16V
(RV2)
C396 1-165-128-11 CERAMIC CHIP 0.22uF 16V
(RV2)
C421 1-126-959-11 ELECT 0.47uF 20% 50V
C451 1-126-964-11 ELECT 10uF 20% 50V
C452 1-126-964-11 ELECT 10uF 20% 50V
C601 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C602 1-126-964-11 ELECT 10uF 20% 50V
C603 1-104-665-11 ELECT 100uF 20% 10V
C605 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C607 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
C608 1-162-917-11 CERAMIC CHIP 15PF 5% 50V
C610 1-126-964-11 ELECT 10uF 20% 50V
C611 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C612 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C613 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C644 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C645 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C646 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C647 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C648 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C656 1-164-156-11 CERAMIC CHIP 0.1uF 25V
