79
HCD-RV2/RV5/RV6
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R582 1-249-435-11 CARBON 33K 5% 1/4W
R591 1-260-344-51 CARBON 22K 5% 1/2W
0R592 1-219-591-11 FUSIBLE 0.1 5% 1/2W F
0R593 1-219-119-81 FUSIBLE 0.1 5% 1/4W F
*************************************************************
1-685-097-11 REMOTE BOARD (RV2)
1-685-105-11 REMOTE BOARD (RV5)
1-685-113-11 REMOTE BOARD (RV6)
**************
< CONNECTOR >
CN702 1-816-423-11 SOCKET, CONNECTOR 3P
< IC >
RM701 8-759-826-34 IC NJL74H400A
*************************************************************
1-685-103-11 SENSOR BOARD (RV5)
1-685-111-11 SENSOR BOARD (RV6)
**************
< THERMISTOR >
TH501 1-807-796-11 THERMISTOR (RV5/RV6)
*************************************************************
1-675-911-14 SENSOR (CD) BOARD
******************
< CAPACITOR >
C712 1-164-159-21 CERAMIC 0.1uF 50V
< PHOTO INTERRUPTER >
IC711 8-749-016-76 PHOTO INTERRUPTER RPI-321
< RESISTOR >
R711 1-247-876-11 CARBON 75K 5% 1/4W
R712 1-249-409-11 CARBON 220 5% 1/4W
R713 1-249-429-11 CARBON 10K 5% 1/4W
< SWITCH >
S711 1-771-821-11 SWITCH, PUSH (1 KEY) (UP/DOWN)
*************************************************************
1-685-094-11 SUB TRANS BOARD (RV2)
****************
< CAPACITOR >
0C901 1-113-925-11 CERAMIC 0.01uF 20% 250V
C902 1-126-768-11 ELECT 2200uF 20% 16V
C903 1-126-933-11 ELECT 100uF 20% 16V
< CONNECTOR >
* CN2 1-564-321-21 PIN, CONNECTOR (3.96mm PITCH) 2P (TH)
CN2 1-568-106-11 PIN, CONNECTOR (3.96mm PITCH) 4P
(E3,EA,MY,SP)
CN901 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
* CN903 1-564-705-11 PIN, CONNECTOR (SMALL TYPE) 3P
< DIODE >
D901 8-719-991-33 DIODE 1SS133T-77
D902 8-719-200-82 DIODE 11ES2
D903 8-719-200-82 DIODE 11ES2
D904 8-719-200-82 DIODE 11ES2
D905 8-719-200-82 DIODE 11ES2
< IC >
IC901 6-701-760-01 IC uPC3504AHF
< TRANSISTOR >
Q901 8-729-119-78 TRANSISTOR 2SC2785-HFE
< RESISTOR >
R902 1-249-429-11 CARBON 10K 5% 1/4W
< RELAY >
0RY901 1-755-276-11 RELAY, POWER
< TRANSFORMER >
0T901 1-435-828-11 TRANSFORMER, POWER
*************************************************************
1-685-102-11 SUB TRANS BOARD (RV5)
****************
< CAPACITOR >
0C901 1-113-925-11 CERAMIC 0.01uF 20% 250V
C902 1-126-768-11 ELECT 2200uF 20% 16V
C903 1-126-933-11 ELECT 100uF 20% 16V
< CONNECTOR >
* CN2 1-564-321-21 PIN, CONNECTOR (3.96mm PITCH) 2P (TH)
CN2 1-568-106-11 PIN, CONNECTOR (3.96mm PITCH) 4P
(E3,EA,JE,MY,SP)
CN901 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
* CN903 1-564-705-11 PIN, CONNECTOR (SMALL TYPE) 3P
< DIODE >
D901 8-719-991-33 DIODE 1SS133T-77
D902 8-719-200-82 DIODE 11ES2
D903 8-719-200-82 DIODE 11ES2
D904 8-719-200-82 DIODE 11ES2
D905 8-719-200-82 DIODE 11ES2
< IC >
IC901 6-701-760-01 IC uPC3504AHF
< TRANSISTOR >
Q901 8-729-119-78 TRANSISTOR 2SC2785-HFE
< RESISTOR >
R902 1-249-429-11 CARBON 10K 5% 1/4W
< RELAY >
0RY901 1-755-276-11 RELAY, POWER
SENSOR SENSOR (CD) SUB TRANSPOWER AMP REMOTE
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
