70
HCD-RV2/RV5/RV6
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MIC MOTOR PANEL
R690 1-216-821-11 METAL CHIP 1K 5% 1/10W
R691 1-216-821-11 METAL CHIP 1K 5% 1/10W
R692 1-216-821-11 METAL CHIP 1K 5% 1/10W
R693 1-216-821-11 METAL CHIP 1K 5% 1/10W
R694 1-216-833-11 METAL CHIP 10K 5% 1/10W
R695 1-216-821-11 METAL CHIP 1K 5% 1/10W
< ENCAPSULATED COMPONENT >
RB101 1-234-575-11 COMPONENT, ENCAPSULATED
< VARIABLE RESISTOR >
RV101 1-241-765-11 RES, ADJ, CARBON 22K
< RELAY >
RY371 1-755-373-11 RELAY
RY372 1-755-373-11 RELAY (RV6)
< TRANSFORMER >
T101 1-435-792-11 TRANSFORMER, DISCRIMINATOR
< VIBRATOR >
X101 1-760-549-31 VIBRATOR, CRYSTAL (4.5MHz)
X601 1-567-098-41 VIBRATOR, CRYSTAL (32.768kHz)
X602 1-781-107-21 VIBRATOR, CERAMIC (16MHz)
*************************************************************
1-685-098-11 MIC BOARD (RV2)
1-685-106-11 MIC BOARD (RV5)
1-685-114-11 MIC BOARD (RV6)
**********
< CONNECTOR >
* CN704 1-564-719-11 PIN, CONNECTOR (SMALL TYPE) 3P
< JACK >
JK702 1-770-226-11 JACK (LARGE TYPE) (MIC)
*************************************************************
1-675-910-14 MOTOR BOARD
*************
< CAPACITOR >
C721 1-162-306-11 CERAMIC 0.01uF 30% 16V
< CONNECTOR >
CN721 1-770-516-31 CONNECTOR, FFC 8P
< SWITCH >
S701 1-771-822-11 SWITCH, LEVER (SLIDE) (OPEN/CLOSE)
*************************************************************
A-4676-984-A PANEL BOARD, COMPLETE (RV2)
**********************
4-238-613-01 HOLDER (L), FL
4-238-614-01 HOLDER (R), FL
< CAPACITOR >
C701 1-126-964-11 ELECT 10uF 20% 50V
C702 1-126-964-11 ELECT 10uF 20% 50V
C703 1-162-306-11 CERAMIC 0.01uF 30% 16V
C704 1-126-947-11 ELECT 47uF 20% 10V
C705 1-162-294-31 CERAMIC 0.001uF 10% 50V
C706 1-162-294-31 CERAMIC 0.001uF 10% 50V
C707 1-162-294-31 CERAMIC 0.001uF 10% 50V
C710 1-162-282-31 CERAMIC 100PF 10% 50V
C711 1-162-282-31 CERAMIC 100PF 10% 50V
C713 1-162-282-31 CERAMIC 100PF 10% 50V
C716 1-161-494-00 CERAMIC 0.022uF 25V
C718 1-162-306-11 CERAMIC 0.01uF 30% 16V
C719 1-162-219-31 CERAMIC 68PF 5% 50V
C720 1-162-306-11 CERAMIC 0.01uF 30% 16V
C721 1-126-947-11 ELECT 47uF 20% 10V
C722 1-162-282-31 CERAMIC 100PF 10% 50V
C723 1-162-282-31 CERAMIC 100PF 10% 50V
C724 1-162-282-31 CERAMIC 100PF 10% 50V
C725 1-162-282-31 CERAMIC 100PF 10% 50V
C726 1-162-282-31 CERAMIC 100PF 10% 50V
C727 1-162-282-31 CERAMIC 100PF 10% 50V
C728 1-162-282-31 CERAMIC 100PF 10% 50V
C729 1-162-282-31 CERAMIC 100PF 10% 50V
C730 1-162-282-31 CERAMIC 100PF 10% 50V
C731 1-162-282-31 CERAMIC 100PF 10% 50V
C732 1-162-282-31 CERAMIC 100PF 10% 50V
C733 1-162-282-31 CERAMIC 100PF 10% 50V
C734 1-162-306-11 CERAMIC 0.01uF 30% 16V
C735 1-162-306-11 CERAMIC 0.01uF 30% 16V
C736 1-162-294-31 CERAMIC 0.001uF 10% 50V
C737 1-162-294-31 CERAMIC 0.001uF 10% 50V
C738 1-104-665-11 ELECT 100uF 20% 10V
C739 1-104-665-11 ELECT 100uF 20% 10V
C740 1-126-959-11 ELECT 0.47uF 20% 50V
C741 1-126-959-11 ELECT 0.47uF 20% 50V
C742 1-130-493-00 MYLAR 0.068uF 5% 50V
C744 1-162-305-11 CERAMIC 0.0068uF 20% 16V
C745 1-126-960-11 ELECT 1uF 20% 50V
C747 1-136-167-00 FILM 0.15uF 5% 50V
C748 1-126-947-11 ELECT 47uF 20% 16V
C749 1-130-493-00 MYLAR 0.068uF 5% 50V
C750 1-162-294-31 CERAMIC 0.001uF 10% 50V
C751 1-162-294-31 CERAMIC 0.001uF 10% 50V
C752 1-126-960-11 ELECT 1uF 20% 50V
C753 1-110-671-31 CERAMIC 0.047uF 50V
C754 1-162-215-31 CERAMIC 47PF 5% 50V
C755 1-126-957-11 ELECT 0.22uF 20% 50V
C756 1-162-294-31 CERAMIC 0.001uF 10% 50V
C757 1-162-306-11 CERAMIC 0.01uF 30% 16V
C758 1-126-956-11 ELECT 0.1uF 20% 50V
C759 1-162-290-31 CERAMIC 470PF 10% 50V
