12
HCD-RV2/RV5/RV6
Pin No. Pin Name I/O Pin Description
56 REAR LINK O Rear link signal output (HCD-RV6 only) ON: “H”, OFF: “L”
57 SUR1 O Surround control signal output to LA2615 (IC304)
58 SUR2 O Surround control signal output to LA2615 (IC304)
59 SUR3 O Surround control signal output to LA2615 (IC304)
60 A TRG O A trigger signal output ON: “H”, OFF: “L”
61 B TRG O B trigger signal output ON: “H”, OFF: “L”
62 VCC — Power supply pin (+3.3 V)
63 NC O Not used. (Open)
64 VSS — Ground pin
65 CAPM CONT O Capstan motor control signal output ON: “H”, OFF: “L”
66 B REC FWD I TCM-B FWD recording switch signal input “L”: active
67 B REC REW I TCM-B REV recording switch signal input “L”: active (HCD-RV5/RV6 only)
68 A HAFE I TCM-A half signal input “L”: active
69 B HAFE I TCM-B half signal input “L”: active
70 A PLAY I TCM-A playing switch signal input “L”: active
71 B PLAY I TCM-B playing switch signal input “L”: active
72 AMS IN I AMS signal input No music: “L”, music: “H”
73 DISPLAY KEY I Display key (S742) signal input “L”: active
74 POWER KEY I Power key (S716) signal input “L”: active
75 BIAS O Bias on/off signal output ON: “H”, OFF: “L”
76 PB A/B O Playback A/B select signal output to HA12237F (IC201) “H”: A, “L”: B
77 TC RELAY O TC relay signal output REC: “L”, Other: “H”
78 PB MUT O Playback mute signal to HA12237F (IC201) ON: “L”, OFF: “H”
79 REC MUT O Recording mute signal to HA12237F (IC201) ON: “L”, OFF: “H”
80 A SHUT IN I Reel pulse signal input
81 B SHUT IN I Reel pulse signal input
82 LINEOUT MUT O Line (MD/VIDEO) mute signal output ON: “L”, OFF: “H”
83 LINE MUT O TA line mute signal output ON: “L”, OFF: “H”
84 STK MUT O STK mute signal output ON: “L”, OFF: “H”
85 PROTECT I Protect signal input ON: “L”, OFF: “H”
86 STB RELAY O Standby relay signal output ON: “H”, OFF: “L”
87 NC O Not used. (Open)
88 FRONT RELAY O Front speaker relay signal output ON: “H”, OFF: “L”
89 SP1/METER-L I HCD-RV2: Meter L signal input HCD-RV5/RV6: Spectrum analyzer signal input
90 SP2/METER-R I HCD-RV2: Meter L signal input HCD-RV5/RV6: Spectrum analyzer signal input
91 SP3 I HCD-RV2: Fixed at “L”. HCD-RV5/RV6: Spectrum analyzer signal input
92 SP4 I HCD-RV2: Fixed at “L”. HCD-RV5/RV6: Spectrum analyzer signal input
93 MODE IN I Model select input
94 SPEC IN I Spec select input
95 VACS IN I VACS signal input
96 AVSS — Ground pin
97 NC I Not used. (Open)
98 V REF — AV reference pin
99 AVCC — Power supply pin (+3.3 V)
100 S IN I Serial data signal input to display control (IC701)
