14
HCD-RV22/RV55
3-9. MAIN BOARD
3-10. AMP BOARD
MAIN board
1
CN907 (10P)
3
CN441
4
MAIN board
2
two
screws
(+BVTP 3
×
8)
6
2
two
screws
(+BVTT 4
×
8)
5
two
screws
(transistor)
3
screw
(+BVTP 3
×
14)
1
CN905 (5P)
8
AMP
board
7
heat sink
4
screw
(+BV (3
−
CR))
