Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
78
HCD-RV7/RV8
R535 1-216-817-11 METAL CHIP 470 5% 1/10W
R536 1-216-809-11 METAL CHIP 100 5% 1/10W
R537 1-216-817-11 METAL CHIP 470 5% 1/10W
R540 1-216-809-11 METAL CHIP 100 5% 1/10W
R541 1-216-833-11 METAL CHIP 10K 5% 1/10W
R543 1-216-809-11 METAL CHIP 100 5% 1/10W
R544 1-216-809-11 METAL CHIP 100 5% 1/10W
R545 1-216-809-11 METAL CHIP 100 5% 1/10W
R546 1-216-833-11 METAL CHIP 10K 5% 1/10W
R547 1-216-833-11 METAL CHIP 10K 5% 1/10W
R548 1-216-833-11 METAL CHIP 10K 5% 1/10W
R549 1-216-809-11 METAL CHIP 100 5% 1/10W
R556 1-216-809-11 METAL CHIP 100 5% 1/10W
R557 1-216-809-11 METAL CHIP 100 5% 1/10W
R573 1-216-833-11 METAL CHIP 10K 5% 1/10W
R574 1-216-833-11 METAL CHIP 10K 5% 1/10W
R575 1-216-833-11 METAL CHIP 10K 5% 1/10W
R579 1-216-833-11 METAL CHIP 10K 5% 1/10W
R580 1-216-833-11 METAL CHIP 10K 5% 1/10W
R583 1-216-809-11 METAL CHIP 100 5% 1/10W
R584 1-216-809-11 METAL CHIP 100 5% 1/10W
R585 1-216-833-11 METAL CHIP 10K 5% 1/10W
R588 1-216-833-11 METAL CHIP 10K 5% 1/10W
R589 1-216-809-11 METAL CHIP 100 5% 1/10W
R590 1-216-809-11 METAL CHIP 100 5% 1/10W
R591 1-216-809-11 METAL CHIP 100 5% 1/10W
R592 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
(HCD-RV8)
R592 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(HCD-RV7)
R593 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(HCD-RV7: EA/HCD-RV8: EA)
R594 1-216-821-11 METAL CHIP 1K 5% 1/10W
(HCD-RV8)
R597 1-216-809-11 METAL CHIP 100 5% 1/10W
(HCD-RV8)
R601 1-216-813-11 METAL CHIP 220 5% 1/10W
R602 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R603 1-216-841-11 METAL CHIP 47K 5% 1/10W
R604 1-216-841-11 METAL CHIP 47K 5% 1/10W
R701 1-216-821-11 METAL CHIP 1K 5% 1/10W
R702 1-216-845-11 METAL CHIP 100K 5% 1/10W
R703 1-216-809-11 METAL CHIP 100 5% 1/10W
R751 1-216-821-11 METAL CHIP 1K 5% 1/10W
R752 1-216-845-11 METAL CHIP 100K 5% 1/10W
R753 1-216-809-11 METAL CHIP 100 5% 1/10W
R781 1-216-809-11 METAL CHIP 100 5% 1/10W
R782 1-216-845-11 METAL CHIP 100K 5% 1/10W
R783 1-218-285-11 RES-CHIP 75 5% 1/10W
R803 1-249-410-11 CARBON 270 5% 1/4W
(HCD-RV8)
R814 1-216-821-11 METAL CHIP 1K 5% 1/10W
R816 1-216-806-11 RES-CHIP 56 5% 1/10W
0R819 1-215-891-11 METAL OXIDE 680 5% 2W F
R825 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
(HCD-RV8)
R861 1-216-821-11 METAL CHIP 1K 5% 1/10W
R862 1-216-833-11 METAL CHIP 10K 5% 1/10W
R863 1-216-845-11 METAL CHIP 100K 5% 1/10W
R864 1-216-821-11 METAL CHIP 1K 5% 1/10W
R865 1-216-845-11 METAL CHIP 100K 5% 1/10W
R866 1-216-806-11 RES-CHIP 56 5% 1/10W
0R869 1-215-891-11 METAL OXIDE 680 5% 2W F
R891 1-216-833-11 METAL CHIP 10K 5% 1/10W
R892 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R893 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R901 1-216-821-11 METAL CHIP 1K 5% 1/10W
(HCD-RV8)
R902 1-216-834-11 METAL CHIP 12K 5% 1/10W
(HCD-RV8)
R903 1-216-845-11 METAL CHIP 100K 5% 1/10W
(HCD-RV8)
R904 1-218-867-11 RES-CHIP 6.8K 5% 1/10W
(HCD-RV8)
R905 1-218-867-11 RES-CHIP 6.8K 5% 1/10W
(HCD-RV8)
R906 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(HCD-RV8)
R907 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
(HCD-RV8)
R908 1-216-839-11 METAL CHIP 33K 5% 1/10W
(HCD-RV8)
R912 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(HCD-RV8)
R913 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(HCD-RV8)
R914 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(HCD-RV8)
R915 1-216-857-11 METAL CHIP 1M 5% 1/10W
(HCD-RV8)
R916 1-218-867-11 RES-CHIP 6.8K 5% 1/10W
(HCD-RV8)
R917 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R918 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R919 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
0R921 1-215-861-00 METAL OXIDE 47 5% 1W F
R997 1-216-833-11 METAL CHIP 10K 5% 1/10W
(HCD-RV8)
R998 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(HCD-RV8)
R999 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(HCD-RV8)
< VARIABLE RESISTOR >
RV301 1-238-019-11 RES, ADJ, CARBON 47K
RV304 1-241-768-11 RES, ADJ, CARBON 220K
RV351 1-238-019-11 RES, ADJ, CARBON 47K
RV354 1-241-768-11 RES, ADJ, CARBON 220K
< RELAY >
RY801 1-755-372-11 RELAY (HCD-RV8)
< TRANSFORMER >
T301 1-423-980-11 TRANSFORMER, BIAS OSCILLATION
< TERMINAL >
TM801 1-694-885-12 TERMINAL BOARD, PUSH (ANTENNA) 2P
(SUB WOOFER OUT) (HCD-RV8)
MAIN
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
