Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
79
HCD-RV7/RV8
< VIBRATOR >
X501 1-567-098-41 VIBRATOR, CRYSTAL (32.768kHz)
X502 1-781-107-21 VIBRATOR, CERAMIC (16MHz)
**************************************************************
1-683-539-11 MAIN TRANS BOARD
*****************
1-533-233-11 HOLDER, FUSE
< CAPACITOR >
C941 1-128-576-11 ELECT 100uF 20% 63V
< CONNECTOR >
CN973 1-568-106-11 PIN, CONNECTOR (3.96mm PITCH) 4P
CN997 1-564-528-11 PLUG, CONNECTOR 13P
< DIODE >
D977 8-719-024-99 DIODE 11ES2-NTA2B
< RESISTOR >
0R941 1-217-637-00 FUSIBLE 1 5% 1/4W F
0R951 1-219-119-81 FUSIBLE 0.1 5% 1/4W F
0R952 1-219-120-11 FUSIBLE 0.15 5% 1/4W F
**************************************************************
1-675-910-14 MOTOR BOARD
*************
< CAPACITOR >
C721 1-162-306-11 CERAMIC 0.01uF 30% 16V
< CONNECTOR >
CN721 1-770-516-31 CONNECTOR, FFC 8P
CN722 1-785-330-11 PIN, CONNECTOR (LIGHT ANGLE) 4P
< SWITCH >
S701 1-771-822-11 SWITCH, LEVER (SLIDE)
(DISC TRAY OPEN/CLOSE DETECT)
**************************************************************
A-4728-459-A PAD SWITCH BOARD, COMPLETE
***************************
< CAPACITOR >
C614 1-162-294-31 CERAMIC 0.001uF 10% 50V
C615 1-124-589-11 ELECT 47uF 20% 16V
< CONNECTOR >
CN606 1-573-105-11 CONNECTOR, PC BOARD 4P
< DIODE >
D613 8-719-911-19 DIODE 1SS119-25
< IC >
IC603 8-759-826-34 IC NJL74H400A
(REMOTE CONTROL RECEIVER)
< RESISTOR >
R625 1-249-401-11 CARBON 47 5% 1/4W
R750 1-249-410-11 CARBON 270 5% 1/4W
R752 1-249-415-11 CARBON 680 5% 1/4W
R753 1-249-417-11 CARBON 1K 5% 1/4W
R754 1-249-419-11 CARBON 1.5K 5% 1/4W
R755 1-249-419-11 CARBON 1.5K 5% 1/4W
R756 1-249-421-11 CARBON 2.2K 5% 1/4W
R757 1-247-843-11 CARBON 3.3K 5% 1/4W
R758 1-249-425-11 CARBON 4.7K 5% 1/4W
R759 1-249-427-11 CARBON 6.8K 5% 1/4W
R760 1-249-429-11 CARBON 10K 5% 1/4W
R761 1-249-431-11 CARBON 15K 5% 1/4W
R762 1-249-433-11 CARBON 22K 5% 1/4W
R765 1-249-413-11 CARBON 470 5% 1/4W
R766 1-249-415-11 CARBON 680 5% 1/4W
R767 1-249-417-11 CARBON 1K 5% 1/4W
R768 1-249-419-11 CARBON 1.5K 5% 1/4W
R769 1-249-419-11 CARBON 1.5K 5% 1/4W
R770 1-249-421-11 CARBON 2.2K 5% 1/4W
R771 1-247-843-11 CARBON 3.3K 5% 1/4W
R772 1-249-425-11 CARBON 4.7K 5% 1/4W
R773 1-249-427-11 CARBON 6.8K 5% 1/4W
R774 1-249-429-11 CARBON 10K 5% 1/4W
R775 1-249-431-11 CARBON 15K 5% 1/4W
R776 1-249-433-11 CARBON 22K 5% 1/4W
R777 1-249-435-11 CARBON 33K 5% 1/4W
R778 1-249-439-11 CARBON 68K 5% 1/4W
< SWITCH >
S750 1-762-875-21 SWITCH, KEYBOARD (DISPLAY)
S752 1-762-875-21 SWITCH, KEYBOARD (P FILE)
S753 1-762-875-21 SWITCH, KEYBOARD (PICTURE EFFECT)
S754 1-786-348-21 SWITCH, KEY BOARD (v)
S755 1-786-348-21 SWITCH, KEY BOARD (V)
S756 1-762-875-21 SWITCH, KEYBOARD (.)
S757 1-762-875-21 SWITCH, KEYBOARD (– m)
S758 1-762-875-21 SWITCH, KEYBOARD (X)
S759 1-762-875-21 SWITCH, KEYBOARD (hH)
S760 1-762-875-21 SWITCH, KEYBOARD (x)
S761 1-762-875-21 SWITCH, KEYBOARD (M +)
S762 1-762-875-21 SWITCH, KEYBOARD (> )
S765 1-762-875-21 SWITCH, KEYBOARD (DIMMER)
S766 1-762-875-21 SWITCH, KEYBOARD (DIRECTION, EDIT)
S767 1-762-875-21 SWITCH, KEYBOARD (FM MODE, REPEAT)
S768 1-762-875-21 SWITCH, KEYBOARD (SPECTRUM)
S769 1-762-875-21 SWITCH, KEYBOARD
(TUNER MEMORY, PLAY MODE)
S770 1-762-875-21 SWITCH, KEYBOARD (MUSIC EQ)
S771 1-762-875-21 SWITCH, KEYBOARD (GROOVE)
S772 1-762-875-21 SWITCH, KEYBOARD (GAME EQ)
S773 1-762-875-21 SWITCH, KEYBOARD (EFFECT ON/OFF)
S774 1-786-348-21 SWITCH, KEY BOARD (b)
MAIN MAIN TRANS MOTOR PAD SWITCH
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
