Page #80 background imageLoading...
Page #80 background image
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
80
HCD-RV7/RV8
S775 1-786-348-21 SWITCH, KEY BOARD (B)
S776 1-762-875-21 SWITCH, KEYBOARD (ENTER)
S777 1-762-875-21 SWITCH, KEYBOARD (MOVIE EQ)
S778 1-762-875-21 SWITCH, KEYBOARD (CINEMA SPACE)
**************************************************************
A-4728-462-A PANEL BOARD, COMPLETE
**********************
4-231-581-01 HOLDER (FL)
< CAPACITOR >
C608 1-124-261-00 ELECT 10uF 20% 50V
C609 1-162-303-11 CERAMIC 0.0033uF 30% 16V
C610 1-124-261-00 ELECT 10uF 20% 50V
C611 1-126-964-11 ELECT 10uF 20% 50V
C612 1-162-306-11 CERAMIC 0.01uF 30% 16V
C613 1-124-260-00 ELECT 6.8uF 20% 50V
C618 1-162-306-11 CERAMIC 0.01uF 30% 16V
C619 1-126-785-11 ELECT 47uF 20% 10V
C620 1-162-306-11 CERAMIC 0.01uF 30% 16V
C622 1-126-163-11 ELECT 4.7uF 20% 50V
C623 1-162-294-31 CERAMIC 0.001uF 10% 50V
C624 1-162-306-11 CERAMIC 0.01uF 30% 16V
C625 1-162-306-11 CERAMIC 0.01uF 30% 16V
C626 1-162-306-11 CERAMIC 0.01uF 30% 16V
C627 1-162-306-11 CERAMIC 0.01uF 30% 16V
C628 1-162-306-11 CERAMIC 0.01uF 30% 16V
C629 1-162-306-11 CERAMIC 0.01uF 30% 16V
C651 1-164-159-11 CERAMIC 0.1uF 50V
C652 1-126-964-11 ELECT 10uF 20% 50V
C653 1-126-964-11 ELECT 10uF 20% 50V
C710 1-162-306-11 CERAMIC 0.01uF 30% 16V
C711 1-162-306-11 CERAMIC 0.01uF 30% 16V
C712 1-162-306-11 CERAMIC 0.01uF 30% 16V
< CONNECTOR >
CN601 1-793-767-11 CONNECTOR, BOARD TO BOARD 30P
< DIODE >
D604 8-719-057-97 LED SEL5923A-TP15 (TUNER/BAND)
D605 8-719-057-97 LED SEL5923A-TP15 (CD)
D606 8-719-057-97 LED SEL5923A-TP15 (TAPE A/B)
D607 8-719-057-97 LED SEL5923A-TP15 (MD (VIDEO))
D608 8-719-057-97 LED SEL5923A-TP15 (GAME)
D610 8-719-109-85 DIODE RD5.1ESB2
D612 8-719-024-99 DIODE 11ES2-NTA2B
D614 8-719-024-99 DIODE 11ES2-NTA2B
D794 8-719-058-04 LED SEL5923A-TP15 (I/1)
D795 8-719-063-93 LED SLR325VC-N-T32 (REC PAUSE/START)
< FERRITE BEAD >
FB603 1-412-473-21 FERRITE 0uH
< FLUORESCENT INDICATOR TUBE >
FL601 1-518-791-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC601 6-801-767-01 IC MB90M407PF-G-119-BND
IC602 8-759-570-21 IC BA3830F-E2
< TRANSISTOR >
Q601 8-729-116-02 TRANSISTOR BA1A4M-TP
Q602 8-729-116-02 TRANSISTOR BA1A4M-TP
Q603 8-729-116-02 TRANSISTOR BA1A4M-TP
Q604 8-729-116-02 TRANSISTOR BA1A4M-TP
Q605 8-729-116-02 TRANSISTOR BA1A4M-TP
Q794 8-729-116-02 TRANSISTOR BA1A4M-TP
Q795 8-729-116-02 TRANSISTOR BA1A4M-TP
< RESISTOR >
R601 1-249-440-11 CARBON 82K 5% 1/4W
R606 1-247-889-00 CARBON 270K 5% 1/4W
R607 1-247-889-00 CARBON 270K 5% 1/4W
R611 1-249-437-11 CARBON 47K 5% 1/4W
R612 1-249-433-11 CARBON 22K 5% 1/4W
R613 1-249-434-11 CARBON 27K 5% 1/4W
R614 1-249-435-11 CARBON 33K 5% 1/4W
R618 1-249-429-11 CARBON 10K 5% 1/4W
R626 1-249-411-11 CARBON 330 5% 1/4W
R627 1-249-411-11 CARBON 330 5% 1/4W
R628 1-249-411-11 CARBON 330 5% 1/4W
R629 1-249-411-11 CARBON 330 5% 1/4W
R630 1-249-411-11 CARBON 330 5% 1/4W
R645 1-249-429-11 CARBON 10K 5% 1/4W
R646 1-247-807-31 CARBON 100 5% 1/4W
R647 1-247-807-31 CARBON 100 5% 1/4W
R652 1-249-429-11 CARBON 10K 5% 1/4W
R653 1-249-429-11 CARBON 10K 5% 1/4W
R654 1-247-807-31 CARBON 100 5% 1/4W
R655 1-247-807-31 CARBON 100 5% 1/4W
R656 1-247-807-31 CARBON 100 5% 1/4W
R657 1-249-431-11 CARBON 15K 5% 1/4W
R658 1-249-431-11 CARBON 15K 5% 1/4W
R659 1-249-431-11 CARBON 15K 5% 1/4W
R660 1-247-903-00 CARBON 1M 5% 1/4W
R661 1-249-429-11 CARBON 10K 5% 1/4W
R662 1-249-429-11 CARBON 10K 5% 1/4W
R663 1-249-429-11 CARBON 10K 5% 1/4W
R680 1-249-411-11 CARBON 330 5% 1/4W
R681 1-249-415-11 CARBON 680 5% 1/4W
R682 1-249-433-11 CARBON 22K 5% 1/4W
R749 1-249-410-11 CARBON 270 5% 1/4W
R751 1-249-413-11 CARBON 470 5% 1/4W
R779 1-249-413-11 CARBON 470 5% 1/4W
R780 1-249-415-11 CARBON 680 5% 1/4W
R781 1-249-417-11 CARBON 1K 5% 1/4W
R782 1-249-419-11 CARBON 1.5K 5% 1/4W
R783 1-249-419-11 CARBON 1.5K 5% 1/4W
R784 1-249-421-11 CARBON 2.2K 5% 1/4W
R785 1-247-843-11 CARBON 3.3K 5% 1/4W
R786 1-249-425-11 CARBON 4.7K 5% 1/4W
R787 1-249-427-11 CARBON 6.8K 5% 1/4W
R795 1-249-407-11 CARBON 150 5% 1/4W
PAD SWITCH PANEL
