Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
81
HCD-RV7/RV8
R801 1-249-409-11 CARBON 220 5% 1/4W
R817 1-249-417-11 CARBON 1K 5% 1/4W
R818 1-249-417-11 CARBON 1K 5% 1/4W
R819 1-249-412-11 CARBON 390 5% 1/4W
R820 1-249-415-11 CARBON 680 5% 1/4W
R821 1-249-415-11 CARBON 680 5% 1/4W
R822 1-249-415-11 CARBON 680 5% 1/4W
R823 1-249-415-11 CARBON 680 5% 1/4W
R824 1-249-415-11 CARBON 680 5% 1/4W
R825 1-249-412-11 CARBON 390 5% 1/4W
< SWITCH >
S749 1-762-875-21 SWITCH, KEYBOARD (I/1 )
S751 1-762-875-21 SWITCH, KEYBOARD (REC PAUSE/START)
S779 1-762-875-21 SWITCH, KEYBOARD (CD SYNC HI-DUB)
S780 1-762-875-21 SWITCH, KEYBOARD
(SURROUND SPEAKER MODE)
S781 1-762-875-21 SWITCH, KEYBOARD (KARAOKE PON)
S782 1-762-875-21 SWITCH, KEYBOARD (GAME MIXING)
S783 1-762-875-21 SWITCH, KEYBOARD (GAME)
S784 1-762-875-21 SWITCH, KEYBOARD (MD (VIDEO))
S785 1-762-875-21 SWITCH, KEYBOARD (TAPE A/B)
S786 1-762-875-21 SWITCH, KEYBOARD (TUNER/BAND)
S787 1-762-875-21 SWITCH, KEYBOARD (CD)
< VIBRATOR >
X601 1-577-358-21 VIBRATOR, CERAMIC (4MHz)
**************************************************************
A-4730-027-A POWER BOARD, COMPLETE (HCD-RV7)
A-4730-029-A POWER BOARD, COMPLETE (HCD-RV8)
***********************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACITOR >
C501 1-126-963-11 ELECT 4.7uF 20% 50V
C502 1-162-290-31 CERAMIC 470PF 10% 50V
C503 1-162-286-31 CERAMIC 220PF 10% 50V
C504 1-104-665-11 ELECT 100uF 20% 10V
C507 1-136-495-11 FILM 0.068uF 5% 50V
C508 1-136-495-11 FILM 0.068uF 5% 50V
C509 1-128-560-11 ELECT 22uF 20% 100V
C512 1-162-306-11 CERAMIC 0.01uF 20% 16V
C513 1-162-306-11 CERAMIC 0.01uF 30% 16V
C514 1-104-665-11 ELECT 100uF 20% 10V
C515 1-126-961-11 ELECT 2.2uF 20% 50V
C516 1-104-665-11 ELECT 100uF 20% 10V
C517 1-126-964-11 ELECT 10uF 20% 50V
C523 1-162-306-11 CERAMIC 0.01uF 30% 16V
C524 1-162-306-11 CERAMIC 0.01uF 30% 16V
C525 1-162-306-11 CERAMIC 0.01uF 30% 16V
C526 1-126-964-11 ELECT 10uF 20% 50V
C541 1-136-165-00 FILM 0.1uF 5% 50V
C542 1-127-811-11 ELECT 3300uF 20% 50V
C544 1-130-777-00 MYLAR 0.1uF 5% 100V
C545 1-130-777-00 MYLAR 0.1uF 5% 100V
C546 1-137-843-11 ELECT 2200uF 20% 100V
C551 1-126-963-11 ELECT 4.7uF 20% 50V
C552 1-162-290-31 CERAMIC 470PF 10% 50V
C553 1-162-286-31 CERAMIC 220PF 10% 50V
C554 1-104-665-11 ELECT 100uF 20% 10V
C557 1-136-495-11 FILM 0.068uF 5% 50V
C558 1-136-495-11 FILM 0.068uF 5% 50V
C559 1-128-560-11 ELECT 22uF 20% 100V
C581 1-126-965-11 ELECT 22uF 20% 50V
C591 1-136-165-00 FILM 0.1uF 5% 50V
C592 1-127-811-11 ELECT 3300uF 20% 50V
C596 1-137-843-11 ELECT 2200uF 20% 100V
C942 1-126-964-11 ELECT 10uF 20% 50V
C943 1-126-968-11 ELECT 100uF 20% 50V
< CONNECTOR >
CN502 1-778-981-21 CONNECTOR, BOARD TO BOARD 13P
CN503 1-778-981-21 CONNECTOR, BOARD TO BOARD 13P
* CN1072 1-564-511-11 PLUG, CONNECTOR 8P (HCD-RV8)
< DIODE >
D501 8-719-911-19 DIODE 1SS119-25
D502 8-719-911-19 DIODE 1SS119-25
D503 8-719-947-70 DIODE MTZJ-T-72-18C
D504 8-719-947-70 DIODE MTZJ-T-72-18C
D506 8-719-911-19 DIODE 1SS119-25
D507 8-719-911-19 DIODE 1SS119-25
D508 8-719-911-19 DIODE 1SS119-25
D509 8-719-911-19 DIODE 1SS119-25
D510 8-719-911-19 DIODE 1SS119-25
D511 8-719-911-19 DIODE 1SS119-25
D541 8-719-060-53 DIODE RBV-2506 (HCD-RV8)
D541 8-719-510-68 DIODE D5SBA204101 (HCD-RV7)
D543 8-719-500-60 DIODE D5SBA20
D551 8-719-911-19 DIODE 1SS119-25
D581 8-719-911-19 DIODE 1SS119-25
D941 8-719-150-92 DIODE RD33EB3T
< GROUND TERMINAL >
* EP501 1-537-738-21 TERMINAL, EARTH
* EP502 1-537-738-21 TERMINAL, EARTH
< IC >
IC501 8-749-017-06 IC STK412-150
< TRANSISTOR >
Q501 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q502 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q503 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q504 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q505 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q506 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q507 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q508 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q509 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q510 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q511 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q512 8-729-900-36 TRANSISTOR DTC124ES
PANEL POWER
