Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
82
HCD-RV7/RV8
Q513 8-729-900-36 TRANSISTOR DTC124ES
Q551 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q581 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q831 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q941 8-729-209-60 TRANSISTOR 2SB1375
< RESISTOR >
R501 1-249-417-11 CARBON 1K 5% 1/4W
R502 1-249-438-11 CARBON 56K 5% 1/4W
R503 1-249-407-11 CARBON 150 5% 1/4W
R504 1-249-438-11 CARBON 56K 5% 1/4W
R505 1-249-417-11 CARBON 1K 5% 1/4W
R506 1-249-433-11 CARBON 22K 5% 1/4W
R507 1-249-441-11 CARBON 100K 5% 1/4W
0R508 1-245-234-11 METAL 0.1 10% 5W F
R509 1-260-076-11 CARBON 10 5% 1/2W
0R510 1-245-234-11 METAL 0.1 10% 5W F
0R511 1-212-881-11 FUSIBLE 100 5% 1/4W F
0R512 1-202-972-61 FUSIBLE 1 5% 1/4W F
R513 1-249-435-11 CARBON 33K 5% 1/4W
R514 1-249-421-11 CARBON 2.2K 5% 1/4W
R515 1-249-433-11 CARBON 22K 5% 1/4W
R516 1-249-429-11 CARBON 10K 5% 1/4W
R517 1-249-429-11 CARBON 10K 5% 1/4W
R518 1-249-435-11 CARBON 33K 5% 1/4W
R519 1-249-439-11 CARBON 68K 5% 1/4W
0R520 1-215-872-11 METAL OXIDE 3.3K 5% 1W F
R521 1-249-441-11 CARBON 100K 5% 1/4W
R522 1-249-441-11 CARBON 100K 5% 1/4W
R523 1-249-440-11 CARBON 82K 5% 1/4W
0R524 1-215-872-11 METAL OXIDE 3.3K 5% 1W F
R525 1-249-437-11 CARBON 47K 5% 1/4W
(HCD-RV8)
R526 1-249-438-11 CARBON 56K 5% 1/4W
(HCD-RV8)
R527 1-249-438-11 CARBON 56K 5% 1/4W
R528 1-249-437-11 CARBON 47K 5% 1/4W
R529 1-249-433-11 CARBON 22K 5% 1/4W
R530 1-249-433-11 CARBON 22K 5% 1/4W
R531 1-249-409-11 CARBON 220 5% 1/4W
R532 1-247-897-11 CARBON 560K 5% 1/4W
R533 1-249-437-11 CARBON 47K 5% 1/4W
R537 1-249-429-11 CARBON 10K 5% 1/4W
R538 1-249-437-11 CARBON 47K 5% 1/4W
0R539 1-215-889-00 METAL OXIDE 330 5% 2W F
(HCD-RV7)
0R539 1-215-891-11 METAL OXIDE 680 5% 2W F
(HCD-RV8)
0R540 1-215-889-00 METAL OXIDE 330 5% 2W F
(HCD-RV7)
0R540 1-215-891-11 METAL OXIDE 680 5% 2W F
(HCD-RV8)
R541 1-249-441-11 CARBON 100K 5% 1/4W
R542 1-249-441-11 CARBON 100K 5% 1/4W
R543 1-249-439-11 CARBON 68K 5% 1/4W
R544 1-249-429-11 CARBON 10K 5% 1/4W
R545 1-249-425-11 CARBON 4.7K 5% 1/4W
R546 1-249-433-11 CARBON 22K 5% 1/4W
R547 1-249-437-11 CARBON 47K 5% 1/4W
R548 1-249-437-11 CARBON 47K 5% 1/4W
R551 1-249-417-11 CARBON 1K 5% 1/4W
R552 1-249-438-11 CARBON 56K 5% 1/4W
R553 1-249-407-11 CARBON 150 5% 1/4W
R554 1-249-438-11 CARBON 56K 5% 1/4W
R555 1-249-417-11 CARBON 1K 5% 1/4W
R556 1-249-433-11 CARBON 22K 5% 1/4W
R557 1-249-441-11 CARBON 100K 5% 1/4W
0R558 1-245-234-11 METAL 0.1 10% 5W F
R559 1-260-076-11 CARBON 10 5% 1/2W
0R560 1-245-234-11 METAL 0.1 10% 5W F
0R561 1-212-881-11 FUSIBLE 100 5% 1/4W F
R564 1-249-425-11 CARBON 4.7K 5% 1/4W
R565 1-249-425-11 CARBON 4.7K 5% 1/4W
R581 1-249-435-11 CARBON 33K 5% 1/4W
R582 1-249-435-11 CARBON 33K 5% 1/4W
R591 1-249-441-11 CARBON 100K 5% 1/4W
R592 1-249-441-11 CARBON 100K 5% 1/4W
R942 1-249-428-11 CARBON 8.2K 5% 1/4W
R943 1-249-417-11 CARBON 1K 5% 1/4W
R945 1-249-428-11 CARBON 8.2K 5% 1/4W
< RELAY >
RY501 1-515-920-11 RELAY
RY502 1-515-920-11 RELAY
< TERMINAL >
TM501 1-694-877-11 TERMINAL BOARD (8P)
(FRONT/SURROUND SPEAKER)
**************************************************************
1-683-542-11 SENSOR BOARD
**************
< CONNECTOR >
CN701 1-785-328-11 PIN, CONNECTOR (LIGHT ANGLE) 2P
< THERMISTOR >
TH701 1-807-796-11 THERMISTOR
**************************************************************
1-675-911-14 SENSOR (CD) BOARD
******************
< CAPACITOR >
C712 1-164-159-11 CERAMIC 0.1uF 50V
< PHOTO INTERRUPTER >
IC711 8-749-014-38 PHOTO INTERRUPTER SG-264
< RESISTOR >
R711 1-247-876-11 CARBON 75K 5% 1/4W
R712 1-249-409-11 CARBON 220 5% 1/4W
R713 1-249-429-11 CARBON 10K 5% 1/4W
POWER SENSOR SENSOR (CD)
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
