Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
83
HCD-RV7/RV8
< SWITCH >
S711 1-771-821-11 SWITCH, PUSH (1KEY)
(OPTICAL PICK-UP UP/DOWN DETECT)
**************************************************************
A-4727-581-A SUB WOOFER BOARD, COMPLETE (HCD-RV8)
****************************
< CAPACITOR >
C1001 1-126-963-11 ELECT 4.7uF 20% 50V
C1002 1-162-286-31 CERAMIC 220PF 10% 50V
C1003 1-136-171-00 FILM 0.33uF 5% 50V
C1004 1-104-665-11 ELECT 100uF 20% 10V
C1005 1-128-560-11 ELECT 22uF 20% 100V
C1006 1-126-968-11 ELECT 100uF 20% 50V
C1007 1-126-967-11 ELECT 47uF 20% 50V
C1008 1-128-560-11 ELECT 22uF 20% 100V
C1009 1-136-165-00 FILM 0.1uF 5% 50V
C1010 1-136-165-00 FILM 0.1uF 5% 50V
C1017 1-126-963-11 ELECT 4.7uF 20% 50V
C1018 1-162-306-11 CERAMIC 0.01uF 30% 16V
C1051 1-126-963-11 ELECT 4.7uF 20% 50V
C1052 1-162-286-31 CERAMIC 220PF 10% 50V
C1053 1-136-153-00 FILM 0.01uF 5% 50V
C1054 1-104-665-11 ELECT 100uF 20% 10V
C1059 1-136-165-00 FILM 0.1uF 5% 50V
C1060 1-136-165-00 FILM 0.1uF 5% 50V
< DIODE >
D1001 8-719-911-19 DIODE 1SS119-25
D1002 8-719-911-19 DIODE 1SS119-25
D1003 8-719-911-19 DIODE 1SS119-25
D1052 8-719-911-19 DIODE 1SS119-25
< IC >
IC502 8-749-016-96 IC STK402-120S
< TRANSISTOR >
Q1001 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q1002 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q1003 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q1004 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q1054 8-729-119-79 TRANSISTOR 2SC2785-FEK
< RESISTOR >
R1001 1-249-417-11 CARBON 1K 5% 1/4W
R1002 1-249-437-11 CARBON 47K 5% 1/4W
R1003 1-249-419-11 CARBON 1.5K 5% 1/4W
R1004 1-249-437-11 CARBON 47K 5% 1/4W
R1005 1-249-429-11 CARBON 10K 5% 1/4W
0R1006 1-202-972-61 FUSIBLE 1 5% 1/4W F
R1007 1-249-433-11 CARBON 22K 5% 1/4W
R1008 1-249-435-11 CARBON 33K 5% 1/4W
0R1009 1-212-881-11 FUSIBLE 100 5% 1/4W F
R1010 1-249-437-11 CARBON 47K 5% 1/4W
R1011 1-249-441-11 CARBON 100K 5% 1/4W
R1012 1-249-421-11 CARBON 2.2K 5% 1/4W
R1013 1-249-433-11 CARBON 22K 5% 1/4W
SENSOR (CD) SUB WOOFER SUB-TRANS
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
R1014 1-249-429-11 CARBON 10K 5% 1/4W
R1015 1-249-429-11 CARBON 10K 5% 1/4W
R1016 1-249-431-11 CARBON 15K 5% 1/4W
R1017 1-249-417-11 CARBON 1K 5% 1/4W
0R1018 1-244-164-11 METAL 0.22 10% 5W F
0R1019 1-244-164-11 METAL 0.22 10% 5W F
R1020 1-249-441-11 CARBON 100K 5% 1/4W
R1021 1-260-076-11 CARBON 10 5% 1/2W
0R1022 1-212-881-11 FUSIBLE 100 5% 1/4W F
R1023 1-249-437-11 CARBON 47K 5% 1/4W
R1051 1-249-417-11 CARBON 1K 5% 1/4W
R1052 1-249-437-11 CARBON 47K 5% 1/4W
R1053 1-249-419-11 CARBON 1.5K 5% 1/4W
R1054 1-249-437-11 CARBON 47K 5% 1/4W
R1066 1-249-431-11 CARBON 15K 5% 1/4W
R1067 1-249-417-11 CARBON 1K 5% 1/4W
0R1068 1-244-164-11 METAL 0.22 10% 5W F
0R1069 1-244-164-11 METAL 0.22 10% 5W F
R1070 1-249-441-11 CARBON 100K 5% 1/4W
R1071 1-260-076-11 CARBON 10 5% 1/2W
**************************************************************
A-4727-568-A SUB-TRANS BOARD, COMPLETE
(HCD-RV7: E, SP, MY/HCD-RV8: E, SP, MY)
A-4728-130-A SUB-TRANS BOARD, COMPLETE
(HCD-RV7: TH)
A-4729-924-A SUB-TRANS BOARD, COMPLETE
(HCD-RV7: EA/HCD-RV8: EA)
***************************
< CAPACITOR >
0C971 1-113-925-11 CERAMIC 0.01uF 20% 250V
C973 1-126-933-11 ELECT 100uF 20% 16V
C975 1-126-768-11 ELECT 2200uF 20% 16V
C976 1-164-159-11 CERAMIC 0.1uF 50V
C977 1-164-159-11 CERAMIC 0.1uF 50V
C978 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
* CN974 1-564-321-21 PIN, CONNECTOR (3.96mm PITCH) 2P
CN976 1-506-468-11 PIN, CONNECTOR 3P
< DIODE >
D971 8-719-911-19 DIODE 1SS119-25
D972 8-719-024-99 DIODE 11ES2-NTA2B
D973 8-719-024-99 DIODE 11ES2-NTA2B
D974 8-719-024-99 DIODE 11ES2-NTA2B
D975 8-719-024-99 DIODE 11ES2-NTA2B
< IC >
IC971 6-701-760-01 IC uPC3504AHF
< TRANSISTOR >
Q971 8-729-119-79 TRANSISTOR 2SC2785-FEK
< RESISTOR >
R974 1-249-441-11 CARBON 100K 5% 1/4W
R975 1-249-429-11 CARBON 10K 5% 1/4W
