15
HCD-RV660D/RV990D
2-16. MOTOR (TB) BOARD
2-15. SENSOR BOARD
2
tray
3
belt (table)
5
pulley (table)
8
screw
(+BTTP (M2.6))
9
SENSOR board
7
gear (geneva)
0
CN731
1
floating
screw
(+PTPWH M2.6)
6
floating
screw
(+PTPWH M2.6)
4
floating
screw
(+PTPWH M2.6)
4
Remove the two solderings of motor.
3
MOTOR (TB) board
5
table motor assy (M741)
2
two
screws
(+BTTP (M2.6))
1
