Sony HCD-RX80 - Page 76

– 100 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
* CN102 1-568-836-11 SOCKET, CONNECTOR 17P
* CN201 1-568-834-11 SOCKET, CONNECTOR 15P
* CN202 1-568-862-11 SOCKET, CONNECTOR 19P
* CN203 1-568-946-11 PIN, CONNECTOR 8P
* CN204 1-568-947-11 PIN, CONNECTOR 9P
CN205 1-568-838-11 SOCKET, CONNECTOR 21P
* CN206 1-568-830-11 SOCKET, CONNECTOR 11P
* CN207 1-568-449-11 HOUSING, CONNECTOR(PC BOARD)3P
< DIODE >
D141 8-719-987-63 DIODE 1N4148M
D281 8-719-987-63 DIODE 1N4148M
D291 8-719-987-63 DIODE 1N4148M
D301 8-719-024-99 DIODE 11ES2-NTA2B
D302 8-719-024-99 DIODE 11ES2-NTA2B
D303 8-719-987-63 DIODE 1N4148M
D304 8-719-987-63 DIODE 1N4148M
D305 8-719-987-63 DIODE 1N4148M
D306 8-719-987-63 DIODE 1N4148M
D307 8-719-987-63 DIODE 1N4148M
D902 8-719-024-99 DIODE 11ES2-NTA2B
D903 8-719-024-99 DIODE 11ES2-NTA2B
D904 8-719-024-99 DIODE 11ES2-NTA2B
D905 8-719-024-99 DIODE 11ES2-NTA2B
D906 8-719-024-99 DIODE 11ES2-NTA2B
D907 8-719-024-99 DIODE 11ES2-NTA2B
D908 8-719-024-99 DIODE 11ES2-NTA2B
D909 8-719-024-99 DIODE 11ES2-NTA2B
D910 8-719-011-18 DIODE UZ-33BSC
D911 8-719-010-43 DIODE UZ-5.6BSC
D912 8-719-987-63 DIODE 1N4148M
D913 8-719-024-99 DIODE 11ES2-NTA2B
D914 8-719-024-99 DIODE 11ES2-NTA2B
D915 8-719-001-42 DIODE UZL-11M1
D951 8-719-987-63 DIODE 1N4148M
D952 8-719-987-63 DIODE 1N4148M
< GROUND PLATE >
* EPT101 4-870-539-11 PLATE, GROUND
< FERRITE BEAD >
FB302 1-412-473-21 INDUCTOR 0UH
< IC >
IC102 8-759-000-48 IC MC14052BCP
IC201 8-759-460-02 IC M62427FP-A
IC231 8-759-634-50 IC M5218AL
IC281 8-759-111-68 IC uPC1237HA
IC301 8-759-464-50 IC uPD780018YGF-015-3BA
IC302 8-759-635-63 IC M51943BSL
IC391 8-749-923-04 IC TOTX178
IC901 8-759-288-53 IC LA5617
IC902 8-759-604-86 IC M5F7807L
IC903 8-759-231-53 IC TA7805S
IC904 8-759-604-39 IC M5F78M12
IC1501 8-759-363-21 IC HA12203NT
IC1502 8-759-822-09 IC LB1641
< COIL >
L131 1-420-872-00 COIL, AIR-CORE
L181 1-420-872-00 COIL, AIR-CORE
L301 1-410-509-11 INDUCTOR 10uH
L392 1-410-521-11 INDUCTOR 100uH
L393 1-410-515-11 INDUCTOR 33uH
< JACK >
J101 1-695-188-31 JACK, PIN 4P (VIDEO/MD, IN/OUT)
< TRANSISTOR >
Q101 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q102 8-729-900-63 TRANSISTOR DTA124ES
Q103 8-729-900-36 TRANSISTOR DTC124ES
Q141 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q142 8-729-119-78 TRANSISTOR 2SC403SP-51
Q151 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q202 8-729-119-78 TRANSISTOR 2SC403SP-51
Q203 8-729-119-78 TRANSISTOR 2SC403SP-51
Q204 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q231 8-729-900-63 TRANSISTOR DTA124ES
Q232 8-729-900-63 TRANSISTOR DTA124ES
Q252 8-729-119-78 TRANSISTOR 2SC403SP-51
Q253 8-729-119-78 TRANSISTOR 2SC403SP-51
Q254 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q281 8-729-900-36 TRANSISTOR DTC124ES
Q282 8-729-900-63 TRANSISTOR DTA124ES
Q283 8-729-900-36 TRANSISTOR DTC124ES
Q301 8-729-119-78 TRANSISTOR 2SC403SP-51
Q901 8-729-040-20 TRANSISTOR RT1P137L-TP
Q902 8-729-900-36 TRANSISTOR DTC124ES
Q903 8-729-030-18 TRANSISTOR 2SD2525
Q904 8-729-030-19 TRANSISTOR 2SB1640
Q905 8-729-040-20 TRANSISTOR RT1P137L-TP
Q906 8-729-900-63 TRANSISTOR DTA124ES
Q907 8-729-119-78 TRANSISTOR 2SC403SP-51
Q1531 8-729-801-93 TRANSISTOR 2SD1387
Q1532 8-729-900-80 TRANSISTOR DTC114ES
Q1533 8-729-900-80 TRANSISTOR DTC114ES
Q1534 8-729-119-77 TRANSISTOR 2SA1175-FEK
Q1535 8-729-900-80 TRANSISTOR DTC114ES
MAIN
