– 101 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
< RESISTOR >
R121 1-249-424-11 CARBON 3.9K 5% 1/4W
R122 1-247-887-00 CARBON 220K 5% 1/4W
R123 1-249-426-11 CARBON 5.6K 5% 1/4W
R124 1-249-429-11 CARBON 10K 5% 1/4W
R125 1-249-441-11 CARBON 100K 5% 1/4W
R126 1-249-417-11 CARBON 1K 5% 1/4W
R127 1-249-441-11 CARBON 100K 5% 1/4W
R131 1-260-076-11 CARBON 10 5% 1/2W
R132 1-260-076-11 CARBON 10 5% 1/2W
R133 1-260-091-11 CARBON 220 5% 1/2W
R134 1-260-091-11 CARBON 220 5% 1/2W
R140 1-249-429-11 CARBON 10K 5% 1/4W
R141 1-249-437-11 CARBON 47K 5% 1/4W
R142 1-249-429-11 CARBON 10K 5% 1/4W
! R147 1-216-455-11 METAL OXIDE 560 5% 2W F
R171 1-249-424-11 CARBON 3.9K 5% 1/4W
R172 1-247-887-00 CARBON 220K 5% 1/4W
R173 1-249-426-11 CARBON 5.6K 5% 1/4W
R174 1-249-429-11 CARBON 10K 5% 1/4W
R176 1-249-417-11 CARBON 1K 5% 1/4W
R177 1-249-441-11 CARBON 100K 5% 1/4W
R181 1-260-076-11 CARBON 10 5% 1/2W
R182 1-260-076-11 CARBON 10 5% 1/2W
R183 1-260-091-11 CARBON 220 5% 1/2W
R184 1-260-091-11 CARBON 220 5% 1/2W
R201 1-249-429-11 CARBON 10K 5% 1/4W
R202 1-249-433-11 CARBON 22K 5% 1/4W
R203 1-249-441-11 CARBON 100K 5% 1/4W
R205 1-249-433-11 CARBON 22K 5% 1/4W
R206 1-249-421-11 CARBON 2.2K 5% 1/4W
R207 1-249-431-11 CARBON 15K 5% 1/4W
R209 1-249-441-11 CARBON 100K 5% 1/4W
R210 1-247-903-00 CARBON 1M 5% 1/4W
R212 1-249-419-11 CARBON 1.5K 5% 1/4W
R213 1-249-433-11 CARBON 22K 5% 1/4W
R214 1-247-887-00 CARBON 220K 5% 1/4W
R215 1-247-903-00 CARBON 1M 5% 1/4W
R216 1-249-429-11 CARBON 10K 5% 1/4W
R217 1-249-437-11 CARBON 47K 5% 1/4W
R221 1-249-425-11 CARBON 4.7K 5% 1/4W
R222 1-249-425-11 CARBON 4.7K 5% 1/4W
R226 1-249-421-11 CARBON 2.2K 5% 1/4W
R227 1-249-441-11 CARBON 100K 5% 1/4W
R228 1-249-429-11 CARBON 10K 5% 1/4W
R231 1-249-437-11 CARBON 47K 5% 1/4W
R232 1-249-437-11 CARBON 47K 5% 1/4W
R234 1-247-886-11 CARBON 200K 5% 1/4W
R235 1-249-421-11 CARBON 2.2K 5% 1/4W
R236 1-249-441-11 CARBON 100K 5% 1/4W
R253 1-249-441-11 CARBON 100K 5% 1/4W
R257 1-249-431-11 CARBON 15K 5% 1/4W
R259 1-249-441-11 CARBON 100K 5% 1/4W
R260 1-247-903-00 CARBON 1M 5% 1/4W
R262 1-249-419-11 CARBON 1.5K 5% 1/4W
R263 1-249-433-11 CARBON 22K 5% 1/4W
R264 1-247-887-00 CARBON 220K 5% 1/4W
R265 1-247-903-00 CARBON 1M 5% 1/4W
R266 1-249-429-11 CARBON 10K 5% 1/4W
R267 1-249-437-11 CARBON 47K 5% 1/4W
R271 1-249-425-11 CARBON 4.7K 5% 1/4W
R272 1-249-425-11 CARBON 4.7K 5% 1/4W
R276 1-249-421-11 CARBON 2.2K 5% 1/4W
R277 1-249-441-11 CARBON 100K 5% 1/4W
R278 1-249-429-11 CARBON 10K 5% 1/4W
R281 1-249-425-11 CARBON 4.7K 5% 1/4W
R282 1-249-425-11 CARBON 4.7K 5% 1/4W
R283 1-249-435-11 CARBON 33K 5% 1/4W
R284 1-249-397-11 CARBON 22 5% 1/4W
R285 1-249-441-11 CARBON 100K 5% 1/4W
R286 1-249-429-11 CARBON 10K 5% 1/4W
R287 1-249-427-11 CARBON 6.8K 5% 1/4W
R288 1-249-438-11 CARBON 56K 5% 1/4W
R289 1-249-437-11 CARBON 47K 5% 1/4W
R291 1-249-433-11 CARBON 22K 5% 1/4W
R292 1-249-433-11 CARBON 22K 5% 1/4W
R293 1-249-417-11 CARBON 1K 5% 1/4W
R294 1-249-441-11 CARBON 100K 5% 1/4W
R295 1-247-903-00 CARBON 1M 5% 1/4W
R301 1-249-413-11 CARBON 470 5% 1/4W
R302 1-249-425-11 CARBON 4.7K 5% 1/4W
R303 1-249-437-11 CARBON 47K 5% 1/4W
R304 1-249-437-11 CARBON 47K 5% 1/4W
R305 1-249-429-11 CARBON 10K 5% 1/4W
R313 1-247-807-31 CARBON 100 5% 1/4W
R316 1-249-429-11 CARBON 10K 5% 1/4W
R318 1-249-429-11 CARBON 10K 5% 1/4W
R319 1-249-429-11 CARBON 10K 5% 1/4W
R320 1-249-429-11 CARBON 10K 5% 1/4W
R322 1-249-425-11 CARBON 4.7K 5% 1/4W
R323 1-247-807-31 CARBON 100 5% 1/4W
R325 1-247-843-11 CARBON 3.3K 5% 1/4W
(AEP, UK, G, AED)
R325 1-249-427-11 CARBON 6.8K 5% 1/4W
(EE, CIS)
R326 1-249-427-11 CARBON 6.8K 5% 1/4W
(AEP, UK, G, AED)
R326 1-249-433-11 CARBON 22K 5% 1/4W
(EE, CIS)
R327 1-247-807-31 CARBON 100 5% 1/4W
R328 1-247-807-31 CARBON 100 5% 1/4W
R330 1-247-807-31 CARBON 100 5% 1/4W
The components identified by mark ! or
dotted line with mark ! are critical for
safety.
Replace only with part number specified.
MAIN
