Sony HCD-RX80 - Page 81

– 105 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
S604 1-762-196-21 SWITCH, TACT (TIMER SELECT)
S605 1-762-196-21 SWITCH, TACT (CLOCK TIMER SET)
S606 1-762-196-21 SWITCH, TACT (DISPLAY/DEMO)
S607 1-762-196-21 SWITCH, TACT (SPECTRAM ANALYZER)
S608 1-762-196-21 SWITCH, TACT (DOLBY NR)
S609 1-762-196-21 SWITCH, TACT (DIRECTION)
S610 1-762-196-21 SWITCH, TACT (EDIT)
S611 1-762-196-21 SWITCH, TACT (REPEAT)
S612 1-762-196-21 SWITCH, TACT (PLAY MODE)
S613 1-762-196-21 SWITCH, TACT (1/ALL DISCS)
S614 1-762-196-21 SWITCH, TACT (SLEEP)
S615 1-762-196-21 SWITCH, TACT (P FILE MEMORY)
S616 1-762-196-21 SWITCH, TACT (NON STOP)
S617 1-762-196-21 SWITCH, TACT (LOW FREQUENCY)
S618 1-762-196-21 SWITCH, TACT (HIGH FREQUENCY)
S620 1-762-196-21 SWITCH, TACT (ENTER/NEXT)
S621 1-762-196-21 SWITCH, TACT (GROOVE)
S622 1-762-196-21 SWITCH, TACT (GAME)
S623 1-762-196-21 SWITCH, TACT (MOVIE)
S624 1-762-196-21 SWITCH, TACT (MUSIC)
S625 1-762-196-21 SWITCH, TACT (P FILE)
S626 1-762-196-21 SWITCH, TACT (WAVE)
S631 1-762-196-21 SWITCH, TACT (SURROUND)
S632 1-762-196-21 SWITCH, TACT (DBFB)
S633 1-762-196-21 SWITCH, TACT (TUNING MODE)
S634 1-762-196-21 SWITCH, TACT (STEREO/MONO)
S635 1-762-196-21 SWITCH, TACT (EFFECT ON/OFF)
S636 1-762-196-21 SWITCH, TACT (KARAOKE PON/MPX)
S637 1-762-196-21 SWITCH, TACT (TUNER/BAND)
S638 1-762-196-21 SWITCH, TACT (LOOP)
S639 1-762-196-21 SWITCH, TACT (FLASH)
S640 1-762-196-21 SWITCH, TACT (TUNER MEMORY)
S642 1-762-196-21 SWITCH, TACT (FUNCTION)
< VIBRATOR >
X601 1-579-125-11 VIBRATOR, CERAMIC (8MHz)
************************************************************
* A-4392-331-A POWER AMP BOARD, COMPLETE
***************************
< CAPACITOR >
C801 1-124-720-11 ELECT 4.7uF 20% 35V
C802 1-162-286-31 CERAMIC 220PF 10% 50V
C803 1-162-282-31 CERAMIC 100PF 10% 50V
C804 1-126-967-11 ELECT 47uF 20% 50V
C806 1-126-967-11 ELECT 47uF 20% 50V
C807 1-126-965-11 ELECT 22uF 20% 50V
C809 1-126-965-11 ELECT 22uF 20% 50V
C810 1-164-159-11 CERAMIC 0.1uF 50V
C811 1-130-493-00 MYLAR 0.068uF 5% 50V
C812 1-130-493-00 MYLAR 0.068uF 5% 50V
R645 1-249-419-11 CARBON 1.5K 5% 1/4W
R646 1-249-401-11 CARBON 47 5% 1/4W
R647 1-249-403-11 CARBON 68 5% 1/4W
R648 1-247-807-31 CARBON 100 5% 1/4W
R649 1-249-407-11 CARBON 150 5% 1/4W
R651 1-249-407-11 CARBON 150 5% 1/4W
R652 1-249-409-11 CARBON 220 5% 1/4W
R653 1-249-411-11 CARBON 330 5% 1/4W
R654 1-249-413-11 CARBON 470 5% 1/4W
R655 1-249-415-11 CARBON 680 5% 1/4W
R656 1-249-417-11 CARBON 1K 5% 1/4W
R657 1-249-419-11 CARBON 1.5K 5% 1/4W
R658 1-249-434-11 CARBON 27K 5% 1/4W
R659 1-247-843-11 CARBON 3.3K 5% 1/4W
R661 1-249-419-11 CARBON 1.5K 5% 1/4W
R663 1-249-429-11 CARBON 10K 5% 1/4W
R664 1-249-421-11 CARBON 2.2K 5% 1/4W
R665 1-247-887-00 CARBON 220K 5% 1/4W
R666 1-249-421-11 CARBON 2.2K 5% 1/4W
R667 1-249-409-11 CARBON 220 5% 1/4W
R668 1-249-409-11 CARBON 220 5% 1/4W
R671 1-249-409-11 CARBON 220 5% 1/4W
R672 1-249-409-11 CARBON 220 5% 1/4W
R673 1-247-807-31 CARBON 100 5% 1/4W
R674 1-247-807-31 CARBON 100 5% 1/4W
R675 1-247-807-31 CARBON 100 5% 1/4W
R676 1-247-807-31 CARBON 100 5% 1/4W
R680 1-247-807-31 CARBON 100 5% 1/4W
R681 1-249-409-11 CARBON 220 5% 1/4W
R685 1-249-419-11 CARBON 1.5K 5% 1/4W
R686 1-247-897-11 CARBON 560K 5% 1/4W
R687 1-249-437-11 CARBON 47K 5% 1/4W
R688 1-247-895-00 CARBON 470K 5% 1/4W
R689 1-249-419-11 CARBON 1.5K 5% 1/4W
R690 1-247-897-11 CARBON 560K 5% 1/4W
R691 1-249-437-11 CARBON 47K 5% 1/4W
R692 1-247-895-00 CARBON 470K 5% 1/4W
R693 1-249-419-11 CARBON 1.5K 5% 1/4W
R694 1-247-897-11 CARBON 560K 5% 1/4W
R695 1-249-437-11 CARBON 47K 5% 1/4W
R696 1-247-895-00 CARBON 470K 5% 1/4W
R698 1-247-897-11 CARBON 560K 5% 1/4W
R699 1-249-437-11 CARBON 47K 5% 1/4W
R700 1-247-895-00 CARBON 470K 5% 1/4W
R748 1-249-435-11 CARBON 33K 5% 1/4W
R749 1-247-895-00 CARBON 470K 5% 1/4W
< SWITCH >
S601 1-467-968-11 ENCODER, ROTARY (JOG)
S602 1-467-869-11 ENCODER, ROTARY (VOLUME)
PANEL
POWER AMP
