– 106 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R842 1-247-881-00 CARBON 120K 5% 1/4W
R843 1-249-421-11 CARBON 2.2K 5% 1/4W
R844 1-249-429-11 CARBON 10K 5% 1/4W
R851 1-249-417-11 CARBON 1K 5% 1/4W
R852 1-249-437-11 CARBON 47K 5% 1/4W
R853 1-249-415-11 CARBON 680 5% 1/4W
R854 1-249-437-11 CARBON 47K 5% 1/4W
R855 1-260-103-11 CARBON 2.2K 5% 1/2W
R856 1-260-103-11 CARBON 2.2K 5% 1/2W
! R857 1-212-881-11 FUSIBLE 100 5% 1/4W F
! R858 1-208-601-11 WIREWOUND 0.1 10% 2W F
R859 1-260-076-11 CARBON 10 5% 1/2W
R861 1-249-417-11 CARBON 1K 5% 1/4W
R862 1-249-433-11 CARBON 22K 5% 1/4W
R863 1-249-441-11 CARBON 100K 5% 1/4W
************************************************************
* 1-658-576-11 SENSOR BOARD
*************
< IC >
IC702 8-749-924-18 IC PHOTO INTERRUPTER RPI-1391
IC703 8-749-924-30 IC PHOTO REFLECTOR GP2S28
< RESISTOR >
R701 1-249-416-11 CARBON 820 5% 1/4W
R702 1-249-407-11 CARBON 150 5% 1/4W
************************************************************
* A-4392-350-A TC SW BOARD, COMPLETE
**********************
< CONNECTOR >
CN607 1-506-486-11 PIN, CONNECTOR 7P
< DIODE >
D634 8-719-063-92 DIODE SLR325MC-M (·: DECK B)
D635 8-719-063-92 DIODE SLR325MC-M (ª: DECK B)
D636 8-719-063-91 DIODE SLR325DC-P (P PAUSE)
D637 8-719-063-93 DIODE SLR325VC-N (r REC)
D638 8-719-063-92 DIODE SLR325MC-M (·: DECK A)
D639 8-719-063-92 DIODE SLR325MC-M (ª: DECK A)
< TRANSISTOR >
Q617 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q618 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q619 8-729-119-76 TRANSISTOR 2SA1175-HFE
< RESISTOR >
R726 1-249-401-11 CARBON 47 5% 1/4W
R727 1-249-403-11 CARBON 68 5% 1/4W
C814 1-162-306-11 CERAMIC 0.01uF 20% 16V
C841 1-126-925-11 ELECT 470uF 20% 10V
C851 1-124-720-11 ELECT 4.7uF 20% 35V
C852 1-162-286-31 CERAMIC 220PF 10% 50V
C853 1-162-282-31 CERAMIC 100PF 10% 50V
C854 1-126-967-11 ELECT 47uF 20% 50V
C856 1-126-967-11 ELECT 47uF 20% 50V
C857 1-126-965-11 ELECT 22uF 20% 50V
C861 1-130-493-00 MYLAR 0.068uF 5% 50V
C862 1-130-493-00 MYLAR 0.068uF 5% 50V
C901 1-126-974-11 ELECT 3300uF 20% 50V
C902 1-136-165-00 FILM 0.1uF 5% 50V
C951 1-126-974-11 ELECT 3300uF 20% 50V
C952 1-136-165-00 FILM 0.1uF 5% 50V
< CONNECTOR >
CN801 1-778-981-11 CONNECTOR, BOARD TO BOARD 13P
< DIODE >
D801 8-719-987-63 DIODE 1N4148M
D841 8-719-987-63 DIODE 1N4148M
D842 8-719-987-63 DIODE 1N4148M
D851 8-719-987-63 DIODE 1N4148M
D901 8-719-028-23 DIODE D3SBA20-4101
< IC >
IC801 8-749-920-09 IC STK-4152MK2K
< TRANSISTOR >
Q801 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q851 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
< RESISTOR >
R801 1-249-417-11 CARBON 1K 5% 1/4W
R802 1-249-437-11 CARBON 47K 5% 1/4W
R803 1-249-415-11 CARBON 680 5% 1/4W
R804 1-249-437-11 CARBON 47K 5% 1/4W
R805 1-260-103-11 CARBON 2.2K 5% 1/2W
R805 1-260-105-11 CARBON 3.3K 5% 1/2W
R806 1-260-103-11 CARBON 2.2K 5% 1/2W
! R807 1-212-881-11 FUSIBLE 100 5% 1/4W F
! R808 1-208-601-11 WIREWOUND 0.1 10% 2W F
R809 1-260-076-11 CARBON 10 5% 1/2W
R811 1-249-417-11 CARBON 1K 5% 1/4W
R812 1-249-433-11 CARBON 22K 5% 1/4W
R813 1-249-441-11 CARBON 100K 5% 1/4W
R814 1-260-099-11 CARBON 1K 5% 1/2W
R816 1-260-099-11 CARBON 1K 5% 1/2W
! R820 1-202-972-61 FUSIBLE 1 5% 1/4W F
R841 1-249-429-11 CARBON 10K 5% 1/4W
The components identified by mark ! or
dotted line with mark ! are critical for
safety.
Replace only with part number specified.
TC SWSENSOR
POWER AMP
