– 108 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
< CONNECTOR >
* CN1 1-568-834-11 SOCKET, CONNECTOR 15P
< DIODE >
D21 8-719-976-99 DIODE UDZ-TE-17-5.1B
D41 8-719-016-74 DIODE 1SS352-TPH3
D42 8-719-016-74 DIODE 1SS352-TPH3 (EE, CIS)
D43 8-719-016-74 DIODE 1SS352-TPH3 (EE, CIS)
D1701 8-719-016-74 DIODE 1SS352-TPH3 (EE, CIS)
D1702 8-719-016-74 DIODE 1SS352-TPH3 (EE, CIS)
D1703 8-719-987-63 DIODE 1N4148M-TA (EE, CIS)
D1704 8-719-016-74 DIODE 1SS352-TPH3 (EE, CIS)
< FRONTEND >
FE1 1-693-357-11 FRONT END (4 GANG) (AEP, UK, G, AED)
FE1 1-693-335-11 FRONT END (3 GANG) (EE, CIS)
FE2 1-233-514-11 ENCAPSULATED COMPONENT
< IC >
IC21 8-759-288-54 IC LC72130
IC41 8-759-176-03 IC LA1835
IC1701 8-759-063-04 IC IR3R42 (EE, CIS)
IC1702 8-759-140-53 IC MC14053BCP (EE, CIS)
< IFT >
IFT41 1-409-636-11 TRANSFORMER, IF (CERAMIC FILTER)
< CHIP CONDUCTOR >
JR2 1-216-295-00 CONDUCTOR, CHIP (2012)
JR6 1-216-295-00 CONDUCTOR, CHIP (2012)
JR8 1-216-295-00 CONDUCTOR, CHIP (2012)
JR9 1-216-295-00 CONDUCTOR, CHIP (2012)
JR45 1-216-295-00 CONDUCTOR, CHIP (2012) (AEP, UK, G, AED)
JR46 1-216-296-00 CONDUCTOR, CHIP (3216)
JR47 1-216-295-00 CONDUCTOR, CHIP (2012)
JR48 1-216-295-00 CONDUCTOR, CHIP (2012)
JR49 1-216-296-00 CONDUCTOR, CHIP (3216)
JR51 1-216-295-00 CONDUCTOR, CHIP (2012)
JR52 1-216-295-00 CONDUCTOR, CHIP (2012)
JR53 1-216-296-00 CONDUCTOR, CHIP (3216)
JR54 1-216-295-00 CONDUCTOR, CHIP (2012)
JR1701 1-216-295-00 CONDUCTOR, CHIP (2012) (EE, CIS)
JR1702 1-216-295-00 CONDUCTOR, CHIP (2012) (EE, CIS)
JR1703 1-216-295-00 CONDUCTOR, CHIP (2012) (EE, CIS)
JR1704 1-216-295-00 CONDUCTOR, CHIP (2012) (EE, CIS)
JR1705 1-216-295-00 CONDUCTOR, CHIP (2012) (EE, CIS)
C68 1-162-306-11 CERAMIC 0.01uF 20% 16V
C71 1-162-306-11 CERAMIC 0.01uF 20% 16V
C72 1-126-967-11 ELECT 47uF 20% 16V
C120 1-163-105-00 CERAMIC CHIP 33PF 5% 50V
(AEP, UK, G, AED)
C1701 1-162-294-31 CERAMIC 0.001uF 10% 50V
(EE, CIS)
C1702 1-130-014-00 PP FILM 470PF 5% 16V
(EE, CIS)
C1703 1-126-959-11 ELECT 0.47uF 20% 50V
(EE, CIS)
C1704 1-126-959-11 ELECT 0.47uF 20% 50V
(EE, CIS)
C1705 1-163-035-00 CERAMIC CHIP 0.047uF 50V
(EE, CIS)
C1706 1-126-960-11 ELECT 1.0uF 20% 50V
(EE, CIS)
C1707 1-163-129-00 CERAMIC CHIP 330P 5% 50V
(EE, CIS)
C1710 1-163-141-00 CERAMIC CHIP 0.001uF 5% 50V
(EE, CIS)
C1711 1-163-141-00 CERAMIC CHIP 0.001uF 5% 50V
(EE, CIS)
C1712 1-130-736-11 PP FILM 0.01uF 5% 16V
(EE, CIS)
C1713 1-130-736-11 PP FILM 0.01uF 5% 16V
(EE, CIS)
C1714 1-126-960-11 ELECT 1.0uF 20% 50V
(EE, CIS)
C1715 1-126-960-11 ELECT 1.0uF 20% 50V
(EE, CIS)
C1716 1-126-960-11 ELECT 1.0uF 20% 50V
(EE, CIS)
C1719 1-126-967-11 ELECT 47uF 20% 16V
(EE, CIS)
C1720 1-163-031-11 CERAMIC CHIP 0.01uF 50V
(EE, CIS)
C1723 1-163-031-11 CERAMIC CHIP 0.01uF 50V
(EE, CIS)
C1724 1-163-031-11 CERAMIC CHIP 0.01uF 50V
(EE, CIS)
C1725 1-126-967-11 ELECT 47uF 20% 16V
(EE, CIS)
C1726 1-126-960-11 ELECT 1.0uF 20% 50V
(EE, CIS)
C1727 1-126-960-11 ELECT 1.0uF 20% 50V
(EE, CIS)
C1728 1-126-966-11 ELECT 33uF 20% 16V
(EE, CIS)
CT1701 1-141-444-11 CAP, CERAMIC TRIMMER 50PF (EE, CIS)
< CERAMIC FILTER >
CF1 1-567-389-11 FILTER, CERAMIC
CF2 1-760-393-11 FILTER, CERAMIC (AEP, UK, G, AED)
CF3 1-760-393-11 FILTER, CERAMIC
TCB
