Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R21 1-249-417-11 CARBON 1K 5% 1/4W
(EE, CIS)
R22 1-216-049-91 CHIP 1K 5% 1/10W
(AEP, UK, G, AED)
R22 1-249-417-11 CARBON 1K 5% 1/4W
(EE, CIS)
R23 1-216-049-91 CHIP 1K 5% 1/10W
(AEP, UK, G, AED)
R23 1-249-417-11 CARBON 1K 5% 1/4W
(EE, CIS)
R24 1-216-025-91 CHIP 100 5% 1/10W
R25 1-249-417-11 CARBON 1K 5% 1/4W
R26 1-249-437-11 CARBON 47K 5% 1/4W
R27 1-249-417-11 CARBON 1K 5% 1/4W
(AEP, UK, G, AED)
R27 1-249-429-11 CARBON 10K 5% 1/4W
(EE, CIS)
R28 1-249-417-11 CARBON 1K 5% 1/4W
R29 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R30 1-216-186-00 CHIP 330 5% 1/8W
R31 1-216-025-91 CHIP 100 5% 1/10W
R32 1-249-425-11 CARBON 4.7K 5% 1/4W
R33 1-249-425-11 CARBON 4.7K 5% 1/4W
R34 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R35 1-216-214-00 CHIP 4.7K 5% 1/8W
R36 1-216-025-91 CHIP 100 5% 1/10W
R37 1-216-073-00 METAL CHIP 10K 5% 1/10W
R38 1-216-089-91 CHIP 47K 5% 1/10W
R39 1-249-429-11 CARBON 10K 5% 1/4W
R42 1-216-073-00 METAL CHIP 10K 5% 1/10W
R43 1-216-042-00 METAL CHIP 510 5% 1/10W
R44 1-216-013-00 METAL CHIP 33 5% 1/10W
R45 1-247-843-11 CARBON (SMALL) 3.3K 5% 1/4W
R46 1-216-073-00 METAL CHIP 10K 5% 1/10W
R47 1-216-097-91 CHIP 100K 5% 1/10W
R48 1-249-417-11 CARBON 1K 5% 1/4W
R49 1-216-049-91 CHIP 1K 5% 1/10W
R50 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R51 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R53 1-249-429-11 CARBON 10K 5% 1/4W
R54 1-249-399-11 CARBON 33 5% 1/4W
(AEP, UK, G, AED)
R55 1-216-162-00 CHIP 33 5% 1/8W
R56 1-249-393-11 CARBON 10 5% 1/4W
R91 1-216-295-00 CONDUCTOR, CHIP (2012)
R92 1-216-073-00 METAL CHIP 10K 5% 1/10W
R94 1-216-073-00 METAL CHIP 10K 5% 1/10W
(AEP, UK, G, AED)
R99 1-249-399-11 CARBON 33 5% 1/4W
R1701 1-216-081-00 METAL CHIP 22K 5% 1/10W
(EE, CIS)
R1702 1-216-085-00 METAL CHIP 33K 5% 1/10W
(EE, CIS)
< JUMPER RESISTOR >
JW4 1-249-413-11 CARBON 470 5% 1/4W
(AEP, UK, G, AED)
JW5 1-249-413-11 CARBON 470 5% 1/4W
(AEP, UK, G, AED)
< INDUCTOR >
L2 1-414-142-11 INDUCTOR, MICRO 1uH (AEP, UK, G, AED)
L3 1-410-521-11 INDUCTOR, MICRO 100uH
L4 1-410-515-11 INDUCTOR, MICRO 33uH (AEP, UK, G, AED)
L41 1-407-500-00 MICRO INDUCTOR 4.7mH
L1701 1-409-497-11 COIL (FILTER) (EE, CIS)
< LOW PASS FILTER >
LPF41 1-239-845-11 FILTER, LOW PASS
LPF42 1-239-845-11 FILTER, LOW PASS
< TRANSISTOR >
Q1 8-729-201-27 TRANSISTOR 2SC2715Y-TE85L
Q2 8-729-201-27 TRANSISTOR 2SC2715Y-TE85L
Q3 8-729-201-27 TRANSISTOR 2SC2715Y-TE85L
Q4 8-729-201-27 TRANSISTOR 2SC2715Y-TE85L
Q5 8-729-424-08 TRANSISTOR MUN2111T1
Q9 8-729-216-22 TRANSISTOR 2SA812-T1-M5M6
Q11 8-729-421-22 TRANSISTOR MUN2211T1
Q12 8-729-421-22 TRANSISTOR MUN2211T1
Q13 8-729-421-22 TRANSISTOR MUN2211T1
Q14 8-729-421-22 TRANSISTOR MUN2211T1
Q1701 8-729-424-08 TRANSISTOR MUN2111T1 (EE, CIS)
Q1702 8-729-907-00 TRANSISTOR RT1N141M-TP-1 (EE, CIS)
Q1703 8-729-421-22 TRANSISTOR MUN2211T1 (EE, CIS)
< RESISTOR >
R1 1-249-401-11 CARBON 47 5% 1/4W
R2 1-216-037-00 METAL CHIP 330 5% 1/10W
R3 1-216-037-00 METAL CHIP 330 5% 1/10W
R5 1-216-037-00 METAL CHIP 330 5% 1/10W
R6 1-216-081-00 METAL CHIP 22K 5% 1/10W
R7 1-216-037-00 METAL CHIP 330 5% 1/10W
R8 1-216-037-00 METAL CHIP 330 5% 1/10W
R9 1-216-081-00 METAL CHIP 22K 5% 1/10W
R10 1-216-037-00 METAL CHIP 330 5% 1/10W
R11 1-216-081-00 METAL CHIP 22K 5% 1/10W
R12 1-216-037-00 METAL CHIP 330 5% 1/10W
R13 1-216-037-00 METAL CHIP 330 5% 1/10W
R14 1-216-081-00 METAL CHIP 22K 5% 1/10W
R18 1-216-073-00 METAL CHIP 10K 5% 1/10W
R19 1-216-073-00 METAL CHIP 10K 5% 1/10W
R21 1-216-049-91 CHIP 1K 5% 1/10W
(AEP, UK, G, AED)
TCB
