HCD-S500/S800
US Model
Canadian Model
HCD-S500
AEP Model
UK Model
E Model
Australian Model
HCD-S500/S800
SERVICE MANUAL
COMPACT AV SYSTEM
Sony Corporation
Audio Group
Published by Sony Engineering Corporation
9-873-291-09
2004H16-1
© 2004.08
HCD-S500/S800 are the amplifier, DVD/CD and
tuner section in DAV-S500/S800.
SPECIFICATIONS
Ver 1.8 2004.08
AUDIO POWER SPECIFICATIONS
POWER OUTPUT AND TOTAL HARMONIC DISTORTION:
With 6 ohm loads, both channels driven, from 120 – 10,000 Hz; rated
40 watts per channel minimum RMS power, with no more than 10 %
total harmonic distortion from 250 milliwatts to rated output.
Amplifier section
S500 MODEL
Stereo mode 40 W + 40 W (6 ohms at 1 kHz, THD 10 %)
Surround mode Front: 40 W + 40 W
Center*: 40 W
Rear*: 40 W + 40 W (6 ohms at 1 kHz, THD 10 %)
Subwoofer*: 80 W (3 ohms at 100 Hz, THD 10 %)
S800 MODEL
Stereo mode 50 W + 50 W (6 ohms at 1 kHz, THD 10 %)
Surround mode Front: 50 W + 50 W
Center*: 50 W
Rear*: 50 W + 50 W (6 ohms at 1 kHz, THD 10 %)
Subwoofer*: 100 W (3 ohms at 100 Hz, THD 10 %)
* Depending on the sound field settings and the source, there may be no sound output.
Inputs (Analog) VIDEO 1, 2:
Sensitivity: 150 mV
Impedance: 50 kilohms
Inputs (Digital) VIDEO 2 (optical):
Sensitivity: –
Outputs (Analog) VIDEO 1 (AUDIO OUT):
Voltage: 2 V
Impedance: 1 kilohms
PHONES:
Accepts low- and high-impedance headphones
Outputs (Digital) DIGITAL OUT (CD)
Sensitivity: –
SACD/DVD system
Laser Semiconductor laser
Signal format system NTSC or NTSC/PAL
Frequency response (at 2 CH STEREO mode)
DVD (PCM): 2 Hz to 22 kHz (±1.0 dB)
CD: 2 Hz to 20 kHz (±1.0 dB)
Signal-to-noise ratio More than 80 dB (VIDEO 1 (AUDIO) connectors only)
Harmonic distortion Less than 0.03 %
FM tuner section
System PLL quartz-locked digital synthesizer system
Tuming range: US, Canadian models:
Tuming range: 87.5 – 108.0 MHz (50 kHz step)
Antenna FM wire antenna
Antenna terminals 75 ohms, unbalanced
Intermediate frequency 10.7 MHz
AM tuner section
System Tuner section:
PLL quartz-locked digital synthesizer system
Tuning range
US, Canadian models: – 1,710 kHz (with the interval set at 10 kHz)
531 – 1,710 kHz (with the interval set at 9 kHz)
AEP, UK, Saudi Arabia models:
531 – 1,602 kHz (with the interval set at 9 kHz)
Other models: 531 – 1,602 kHz (with the interval set at 9 kHz)
530 – 1,710 kHz (with the interval set at 10 kHz)
Antenna Loop antenna
Video section
Inputs Video: 1 Vp-p 75 ohms
Outputs Video: 1 Vp-p 75 ohms
S-video:
Y: 1 Vp-p 75 ohms
C: 0.286 Vp-p 75 ohms
General
Power requirements
US, Canadian models: 120 V AC, 60 Hz
AEP, UK models: 220 – 240 V AC, 50/60 Hz
Australian and E models: 220 – 240 V AC, 50/60 Hz
Mexican model: 120 V AC, 60 Hz
Other models: 110
– 240 V/220 – 240 V AC, 50/60 Hz
Power consumption 98 W (120 V AC) 98 W (230 V AC)
Dimensions (approx.) 355 × 70 × 378 mm (14 × 2
7
/
8
× 15 inches) (w/h/d) incl. projecting parts
Mass (approx.) 4.0 kg (9 lb 8 oz)
Operating temperature 5
˚
C to 35
˚
C (41
˚
F to 95
˚
F)
Operating humidity 5 % to 90 %
Supplied accessories
Design and specifications are subject to change without notice.
Check that you have the following items:
Speakers (5)
•
•
Subwoofer (1)
• AM loop antenna (1)
• FM wire antenna (1)
• Speaker cords (5m × 4, 15m × 2) (16ft. × 4, 49ft. × 2)
• Video cord (1)
• Remote commander (remote) RM-SS800 (1)
• R6 (size AA) batteries (2)
• Foot pads (15)
• Speakers-connection and Installation (card) (1)
• Quick reference for Remote commander (card) (1)
Tuming range: 87.5
Tuming range: Other
108.0 MHz (100 kHz step)–
530
Model Name Using Similar Mechanism NEW
Mechanism Type CDM-55D-DVBU8
Base Unit Name DVBU8
Optical Pick-up Name KHM-240AAA
Photo : HCD-S500
