HCD-S500/S800
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
D342 8-719-073-82 DIODE SFPB-76V
D343 8-719-073-82 DIODE SFPB-76V
D344 8-719-073-82 DIODE SFPB-76V
D345 8-719-073-82 DIODE SFPB-76V
D351 8-719-404-50 DIODE MA111-TX
(S500:US,CND,AEP,CIS,UK,MX,KR/S800)
D370 6-500-060-01 DIODE P6SMB36AT3 (S800)
D370 6-500-055-01 DIODE P6SMB33AT3 (S500)
D371 6-500-060-01 DIODE P6SMB36AT3 (S800)
D371 6-500-055-01 DIODE P6SMB33AT3 (S500)
D372 6-500-060-01 DIODE P6SMB36AT3 (S800)
D372 6-500-055-01 DIODE P6SMB33AT3 (S500)
D373 6-500-060-01 DIODE P6SMB36AT3 (S800)
D373 6-500-055-01 DIODE P6SMB33AT3 (S500)
D374 6-500-060-01 DIODE P6SMB36AT3 (S800)
D374 6-500-055-01 DIODE P6SMB33AT3 (S500)
D375 6-500-060-01 DIODE P6SMB36AT3 (S800)
D375 6-500-055-01 DIODE P6SMB33AT3 (S500)
D380 6-500-060-01 DIODE P6SMB36AT3 (S800)
D380 6-500-055-01 DIODE P6SMB33AT3 (S500)
D381 6-500-060-01 DIODE P6SMB36AT3 (S800)
D381 6-500-055-01 DIODE P6SMB33AT3 (S500)
D382 6-500-060-01 DIODE P6SMB36AT3 (S800)
D382 6-500-055-01 DIODE P6SMB33AT3 (S500)
D383 6-500-060-01 DIODE P6SMB36AT3 (S800)
D383 6-500-055-01 DIODE P6SMB33AT3 (S500)
D384 6-500-060-01 DIODE P6SMB36AT3 (S800)
D384 6-500-055-01 DIODE P6SMB33AT3 (S500)
D385 6-500-060-01 DIODE P6SMB36AT3 (S800)
D385 6-500-055-01 DIODE P6SMB33AT3 (S500)
< EARTH >
EB301 1-537-770-11 TERMINAL BOARD, GROUND
EB302 1-537-770-11 TERMINAL BOARD, GROUND
< FERRITE BEAD >
FB300 1-469-760-21 INDUCTOR 0uH
(S500:US,CND,AEP,CIS,UK,MX,KR/S800)
FB301 1-469-760-21 INDUCTOR 0uH
(S500:US,CND,AEP,CIS,UK,MX,KR/S800)
FB303 1-400-160-51 INDUCTOR 0uH
(S500:US,CND,AEP,CIS,UK,MX,KR/S800)
FB304 1-469-760-21 INDUCTOR 0uH
(S500:US,CND,AEP,CIS,UK,MX,KR/S800)
FB307 1-469-760-21 INDUCTOR 0uH
(S500:US,CND,AEP,CIS,UK,MX,KR/S800)
FB308 1-469-760-21 INDUCTOR 0uH
(S500:US,CND,AEP,CIS,UK,MX,KR/S800)
FB309 1-400-160-51 INDUCTOR 0uH
(S500:US,CND,AEP,CIS,UK,MX,KR/S800)
FB312 1-400-160-51 INDUCTOR 0uH
(S500:US,CND,AEP,CIS,UK,MX,KR/S800)
FB313 1-400-160-51 INDUCTOR 0uH
(S500:US,CND,AEP,CIS,UK,MX,KR/S800)
FB314 1-469-760-21 INDUCTOR 0uH
(S500:US,CND,AEP,CIS,UK,MX,KR/S800)
FB315 1-469-760-21 INDUCTOR 0uH
(S500:US,CND,AEP,CIS,UK,MX,KR/S800)
FB318 1-400-160-51 INDUCTOR 0uH
(S500:US,CND,AEP,CIS,UK,MX,KR/S800)
FB320 1-400-160-51 INDUCTOR 0uH
(S500:US,CND,AEP,CIS,UK,MX,KR/S800)
FB321 1-216-295-11 SHORT 0
FB322 1-216-295-11 SHORT 0
FB323 1-216-295-11 SHORT 0
FB324 1-216-295-11 SHORT 0
FB325 1-216-295-11 SHORT 0
FB326 1-216-295-11 SHORT 0
FB365 1-216-295-11 SHORT 0
< IC >
IC300 8-759-834-29 IC MC74VHC1G04DFT1
IC301 6-700-277-01 IC CXD9646Z
IC302 8-759-533-85 IC BA05FP-E2
IC303 8-759-583-47 IC uPC2933T-E2
IC304 6-700-277-01 IC CXD9646Z
IC305 6-700-279-01 IC CXD9634Q
IC306 6-700-277-01 IC CXD9646Z
IC307 6-700-277-01 IC CXD9646Z
IC308 6-700-279-01 IC CXD9634Q
IC309 6-700-277-01 IC CXD9646Z
IC310 6-700-279-01 IC CXD9634Q
IC311 6-700-277-01 IC CXD9646Z
IC312 8-759-834-30 IC MC74VHC1G08DFT1
< JACK >
J401 1-694-656-11 TERMINAL BOARD (6CH SPEAKER)
< COIL >
L300 1-469-525-91 INDUCTOR 10uH
L302 1-412-939-11 INDUCTOR 1uH
(S500:US,CND,AEP,CIS,UK,MX,KR/S800)
L302 1-412-940-21 INDUCTOR 1.2uH
(EXCEPT S500:US,CND,AEP,CIS,UK,MX,KR/S800)
L401 1-424-777-11 INDUCTOR 10uH
(EXCEPT S500:AEP,UK,KR)
L402 1-424-777-11 INDUCTOR 10uH
(EXCEPT S500:AEP,UK,KR)
L403 1-424-777-11 INDUCTOR 10uH
(EXCEPT S500:AEP,UK,KR)
L404 1-424-777-11 INDUCTOR 10uH
(EXCEPT S500:AEP,UK,KR)
L405 1-424-777-11 INDUCTOR 10uH
(EXCEPT S500:AEP,UK,KR)
L406 1-424-777-11 INDUCTOR 10uH
(EXCEPT S500:AEP,UK,KR)
< TRANSISTOR >
Q301 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
(S500:US,CND,AEP,CIS,UK,MX,KR/S800)
< RESISTOR >
R300 1-216-833-11 METAL CHIP 10K 5% 1/16W
R301 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R302 1-216-857-11 METAL CHIP 1M 5% 1/16W
R303 1-216-833-11 METAL CHIP 10K 5% 1/16W
R304 1-216-801-11 METAL CHIP 22 5% 1/16W
AMP
