83
HCD-S500/S800
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
< FILTER >
FL003 1-234-177-11 FILTER, CHIP EMI
FL004 1-234-177-11 FILTER, CHIP EMI
FL005 1-233-893-21 FILTER, CHIP EMI
FL006 1-234-177-11 FILTER, CHIP EMI
FL101 1-233-893-21 FILTER, CHIP EMI
FL102 1-233-893-21 FILTER, CHIP EMI
FL103 1-233-893-21 FILTER, CHIP EMI
FL501 1-233-893-21 FILTER, CHIP EMI
FL502 1-233-893-21 FILTER, CHIP EMI
FL505 1-234-177-11 FILTER, CHIP EMI
FL603 1-234-177-11 FILTER, CHIP EMI
FL604 1-234-177-11 FILTER, CHIP EMI
FL605 1-234-177-11 FILTER, CHIP EMI
FL606 1-234-177-11 FILTER, CHIP EMI
FL801 1-233-893-21 FILTER, CHIP EMI
FL802 1-233-893-21 FILTER, CHIP EMI
FL803 1-233-893-21 FILTER, CHIP EMI
< IC >
IC001 8-759-460-72 IC BA033FP-E2
IC002 8-759-052-52 IC NJM78M05DL1A-TE1
IC003 8-759-052-52 IC NJM78M05DL1A-TE1
IC004 8-759-533-85 IC BA05FP-E2 (S800:EA,HK,TW,AUS)
IC004 8-759-473-95 IC uPC2905T-E1 (S500/S800:AEP,CIS,UK)
IC005 8-759-460-72 IC BA033FP-E2
IC006 6-700-398-01 IC uPC2918T-E1
IC101 8-759-640-41 IC BR24C08F-E2
IC102 8-759-831-81 IC IMIC6001BTD
IC103 8-759-829-75 IC MB91307APFV-G-BND-E1
IC106 6-700-785-01 IC SN74AHCT32PWR
IC107 8-759-826-41 IC MBM29DL324BE-90PFTN
IC108 6-800-439-01 IC MR27V1602E-P1TPZ
(S500:KR/S800:EA,HK,TW,AUS)
IC302 8-759-828-01 IC CXD9635R
IC303 8-759-643-10 IC GM71V18160CT-6TR
IC304 8-759-680-48 IC TC7WH157FK(TE85R)
IC401 8-759-826-42 IC FAN8034
IC501 8-759-832-30 IC TK71518ASCL
IC503 8-752-399-55 IC CXD1932Q
IC504 8-759-663-74 IC HY57V161610DTC-7TR
IC505 8-759-663-74 IC HY57V161610DTC-7TR
IC600 8-759-052-52 IC NJM78M05DL1A-TE1
IC601 6-701-011-01 IC uPC2910T-E1
IC602 8-759-560-56 IC PCM1800E/2K
IC603 8-759-337-40 IC NJM2904V(TE2)
IC604 8-759-827-81 IC IS61LV6416-15T(T&R)
IC605 6-700-798-11 IC uPC2926T-1-E1 (S500:KR/S800)
IC605 8-759-835-63 IC NJM2391DL1-26-TE1
(EXCEPT S500:KR/S800)
IC606 8-759-825-15 IC LC89056W-E
IC607 8-759-698-76 IC CXD9617R
IC608 8-759-825-13 IC PCM1748E/2K
IC610 8-759-337-40 IC NJM2904V(TE2)
IC612 6-700-278-01 IC CXD9633Q
IC801 8-752-407-50 IC CXD2752R
IC802 8-759-585-52 IC SN74AHC1GU04DBVR
IC803 8-759-663-74 IC HY57V161610DTC-7TR
(S500:KR/S800:EA,HK,TW,AUS)
IC803 8-759-832-53 IC W981616AH-7-EL10
(EXCEPT S500:KR/S800)
IC804 8-759-637-50 IC TA48M025F(TE16L)
IC900 8-759-238-47 IC TC74HCT7007AF(EL)
IC901 6-800-464-01 IC uPD703033AYGF-M27-3BA
IC902 8-759-828-32 IC PT8300
IC903 8-759-427-92 IC PST9126NL
IC904 8-759-326-78 IC PST9140NL
< JUMPER RESISTOR >
JW900 1-218-941-11 RES-CHIP 100 5% 1/16W
JW901 1-218-941-11 RES-CHIP 100 5% 1/16W
JW902 1-218-941-11 RES-CHIP 100 5% 1/16W
JW903 1-218-990-11 SHORT 0
< COIL >
L600 1-414-754-11 INDUCTOR 10uH
L601 1-414-754-11 INDUCTOR 10uH
L602 1-414-754-11 INDUCTOR 10uH
< TRANSISTOR >
Q001 8-729-901-00 TRANSISTOR DTC124EKA-T146
Q002 8-729-209-74 TRANSISTOR 2SA1213Y-TE12L
Q900 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q901 8-729-230-63 TRANSISTOR 2SD1819A-QRS-TX
Q902 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q903 8-729-024-91 TRANSISTOR 2SC2712-GL-TE85L
Q906 8-729-024-91 TRANSISTOR 2SC2712-GL-TE85L
Q907 8-729-024-91 TRANSISTOR 2SC2712-GL-TE85L
Q908 8-729-901-00 TRANSISTOR DTC124EK
Q909 8-729-901-00 TRANSISTOR DTC124EK
Q910 8-729-901-00 TRANSISTOR DTC124EK
< RESISTOR >
R001 1-218-990-11 SHORT 0
R002 1-218-990-11 SHORT 0
R003 1-218-990-11 SHORT 0
R004 1-218-990-11 SHORT 0
R005 1-218-990-11 SHORT 0
R006 1-218-990-11 SHORT 0
R007 1-218-990-11 SHORT 0
R008 1-218-990-11 SHORT 0
R009 1-218-953-11 RES-CHIP 1K 5% 1/16W
R010 1-218-990-11 SHORT 0
R011 1-218-953-11 RES-CHIP 1K 5% 1/16W
R012 1-218-990-11 SHORT 0
R014 1-218-990-11 SHORT 0
R016 1-218-990-11 SHORT 0
R017 1-218-990-11 SHORT 0
R018 1-218-990-11 SHORT 0
R019 1-218-990-11 SHORT 0
R020 1-218-990-11 SHORT 0
R021 1-218-990-11 SHORT 0
R022 1-218-990-11 SHORT 0 (S500:AEP,UK,KR/S800)
R024 1-218-990-11 SHORT 0 (S500:AEP,UK,KR/S800)
R025 1-218-990-11 SHORT 0
R026 1-218-990-11 SHORT 0
R027 1-218-990-11 SHORT 0
R028 1-218-990-11 SHORT 0
DVD
Ver 1.4 2002.11
