• This set can be disassembled in the order shown below.
3-1. Disassembly Flow
SECTION 3
DISASSEMBLY
FRONT PANELSECTION,
SIDE PANEL (L)/(R)
I/O BOARD
DVD BOARD
MECHANISM DECK
SECTION (CDM72B-DVBU12)
POWER S/W BOARD,
DDCON BOARD
SEL BOARD
POWER BOARD
AMP BOARD
OPTICAL PICK-UP BLOCK
(DVBU12)
BELT (L2)
BELT (CK)
PULLEY (RTR) ASSY
BELT (CK),
MOTOR (CK) ASSY (M751)
PULLEY (SPT) ASSY
HOLDER (AT) ASSY.
RETAINER (CHASSIS) BLOCK
RELAY BOARD
SET
