Sony HCD-TZ200 - Network Resistors, Terminals, Vibrators, and Switches; MS-203 Board and Power Board Components

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-TZ100/TZ200/TZ300
6565
R3106 1-216-801-11 METAL CHIP 22 5% 1/10W
R3107 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R3108 1-216-809-11 METAL CHIP 100 5% 1/10W
R3109 1-216-805-11 METAL CHIP 47 5% 1/10W
R3110 1-216-805-11 METAL CHIP 47 5% 1/10W
R3111 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3112 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3113 1-216-809-11 METAL CHIP 100 5% 1/10W
R3114 1-216-864-11 SHORT CHIP 0
R3117 1-216-097-11 METAL CHIP 100K 5% 1/10W
R3119 1-216-809-11 METAL CHIP 100 5% 1/10W
R3120 1-216-864-11 SHORT CHIP 0
R3121 1-216-857-11 METAL CHIP 1M 5% 1/10W
R3122 1-216-809-11 METAL CHIP 100 5% 1/10W
R3124 1-216-864-11 SHORT CHIP 0
R3126 1-216-864-11 SHORT CHIP 0
R3128 1-216-864-11 SHORT CHIP 0
R3142 1-216-864-11 SHORT CHIP 0
R3143 1-216-864-11 SHORT CHIP 0
R3144 1-216-864-11 SHORT CHIP 0
R3145 1-216-864-11 SHORT CHIP 0
R4000 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R4001 1-216-837-11 METAL CHIP 22K 5% 1/10W
R4002 1-216-837-11 METAL CHIP 22K 5% 1/10W
R4005 1-216-841-11 METAL CHIP 47K 5% 1/10W
R4006 1-216-841-11 METAL CHIP 47K 5% 1/10W
R4007 1-216-841-11 METAL CHIP 47K 5% 1/10W
R4008 1-216-841-11 METAL CHIP 47K 5% 1/10W
R4009 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R4010 1-216-805-11 METAL CHIP 47 5% 1/10W
R4011 1-216-805-11 METAL CHIP 47 5% 1/10W
R4012 1-216-864-11 SHORT CHIP 0
R4013 1-216-809-11 METAL CHIP 100 5% 1/10W
R4014 1-216-809-11 METAL CHIP 100 5% 1/10W
R4015 1-216-809-11 METAL CHIP 100 5% 1/10W
R4016 1-216-809-11 METAL CHIP 100 5% 1/10W
R4017 1-216-809-11 METAL CHIP 100 5% 1/10W
R4019 1-216-864-11 SHORT CHIP 0
R4020 1-216-864-11 SHORT CHIP 0
R4021 1-216-845-11 METAL CHIP 100K 5% 1/10W
R4023 1-216-845-11 METAL CHIP 100K 5% 1/10W
R4026 1-216-833-11 METAL CHIP 10K 5% 1/10W
R4030 1-216-833-11 METAL CHIP 10K 5% 1/10W
R4034 1-216-809-11 METAL CHIP 100 5% 1/10W
R9918 1-216-821-11 METAL CHIP 1K 5% 1/10W
R9922 1-216-833-11 METAL CHIP 10K 5% 1/10W
R9924 1-216-821-11 METAL CHIP 1K 5% 1/10W
R9928 1-216-837-11 METAL CHIP 22K 5% 1/10W
R9929 1-216-837-11 METAL CHIP 22K 5% 1/10W
R9934 1-216-833-11 METAL CHIP 10K 5% 1/10W
R9941 1-216-838-11 METAL CHIP 27K 5% 1/10W
R9945 1-216-813-11 METAL CHIP 220 5% 1/10W
< NETWORK RESISTOR >
RB1103 1-234-944-21 RES, NETWORK 47X4 (1005)
RB1104 1-234-944-21 RES, NETWORK 47X4 (1005)
RB1105 1-234-944-21 RES, NETWORK 47X4 (1005)
RB1106 1-234-944-21 RES, NETWORK 47X4 (1005)
RB1109 1-234-944-21 RES, NETWORK 47X4 (1005)
RB1110 1-234-944-21 RES, NETWORK 47X4 (1005)
RB1111 1-234-944-21 RES, NETWORK 47X4 (1005)
RB1112 1-234-400-21 CONDUCTOR, NETWORK 0X4 (1005)
RB1113 1-234-400-21 CONDUCTOR, NETWORK 0X4 (1005)
RB1114 1-234-944-21 RES, NETWORK 47X4 (1005)
RB1115 1-234-944-21 RES, NETWORK 47X4 (1005)
< TERMINAL BOARD >
TB3001 1-780-681-11 TERMINAL BOARD (SPEAKER) 6P (SPEAKER
FRONT L/R,SUR L/R,CENTER,SUBWOOFER)
< VIBRATOR >
X501 1-795-058-21 VIBRATOR, CERAMIC (5MHz)
X1101 1-814-103-21 VIBRATOR, CRYSTAL (27MHz)
X3000 1-814-108-21 VIBRATOR, CRYSTAL (49.1MHz)
*************************************************************
MS-203 BOARD
************
< CONNECTOR >
CN001 1-815-412-11 CONNECTOR, FFC/FPC 5P
< SWITCH >
S001 1-786-693-11 SWITCH, DETECTION (CHUCK/TRAY DETECT)
*************************************************************
P-SW BOARD
***********
< CAPACITOR >
C5400 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
< SWITCH >
S5400 1-762-875-21 SWITCH, KEYBOARD ("/1)
*************************************************************
A-1650-284-A POWER BOARD, COMPLETE (EXCEPT MX,E32)
A-1650-286-A POWER BOARD, COMPLETE (MX)
A-1650-288-A POWER BOARD, COMPLETE (E32)
***********************
1-533-217-41 HOLDER, FUSE
7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
7-685-647-79 SCREW +BVTP 3X10 TYPE2 IT-3
< CAPACITOR >
0 C901 1-165-529-11 MYLAR 0.22uF 10% 275V
0 C902 1-165-529-11 MYLAR 0.22uF 10% 275V
0 C903 1-114-344-11 ELECT(BLOCK) 1000uF 20% 250V
(MX)
0 C903 1-114-347-11 ELECT(BLOCK) 330uF 20% 450V
(EXCEPT MX)
0 C905 1-136-557-11 FILM 0.0033uF 5% 630V
(EXCEPT MX)
0 C905 1-136-601-11 FILM 0.01uF 5% 630V
(MX)
0 C906 1-117-815-11 FILM 0.001uF 3% 1.5KV
(EXCEPT MX)
C907 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(EXCEPT MX)
C907 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
(MX)
C908 1-107-909-11 ELECT 47uF 20% 50V
MAIN POWERMS-203 P-SW
