Sony HCD-TZ200 - Board Removals

HCD-TZ100/TZ200/TZ300
9
2-5. BACK PANEL SECTION
2-6. POWER BOARD
2 wire (flat type) (9 core)
(CN4000)
3 two screws
(+BVTP 3 u8)
6 screw
(+BVTP 3 u8)
4 two screws
(+BVTP 3 u8)
7 back panel section
5 screw
(+B 3 u6)
1 CN901 (2P)
2 CN904 (4P)
1 CN906 (13P)
3 three screws
(+PWH 3 u8)
4 five screws
(+PWH 3 u8)
8 POWER board
7 POWER-RECT board
6 Remove the four solders.
5 holder PC board
