Sony HCD-V707 - Circuit Boards Location

– 41 –
• Circuit Boards Location
TRANS board
KEYCON board
MAIN board
AMP board
TC SW board
HP/MIC board
PANEL board
CD SW board
DECO board
SENSOR board
MOTOR (TURN) board
CONNECTOR board
BD board
VIDEO OUT board
MOTOR (SLIDE) board
VIDEO POWER board
AUDIO board
LEAF SWITCH board
MOTOR board
VIDEO board
ENCAPSULATED COMPONENT
(FM/AM TUNER UNIT)
