Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
IC1502 8-759-822-09 IC LB1641
< PIN JACK >
J101 1-695-188-31 JACK, PIN 4P (VIDEO/MD (AUDIO) IN/OUT)
J241 1-774-785-11 JACK, PIN 1P (SUPER WOOFER)
< COIL >
L131 1-420-872-00 COIL, AIR-CORE (MY, SP, HK, TW, CH, JE)
L181 1-420-872-00 COIL, AIR-CORE (MY, SP, HK, TW, CH, JE)
L301 1-410-509-11 INDUCTOR 10uH
L392 1-410-521-11 INDUCTOR 100uH
< TRANSISTOR >
Q101 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q102 8-729-900-63 TRANSISTOR DTA124ES
Q103 8-729-900-36 TRANSISTOR DTC124ES
Q141 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q142 8-729-119-78 TRANSISTOR 2SC403SP-51
Q151 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q191 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q192 8-729-111-29 TRANSISTOR 2SD1616A-K
Q202 8-729-119-78 TRANSISTOR 2SC403SP-51
Q203 8-729-119-78 TRANSISTOR 2SC403SP-51
Q204 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q231 8-729-900-63 TRANSISTOR DTA124ES
Q232 8-729-900-63 TRANSISTOR DTA124ES
Q241 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q252 8-729-119-78 TRANSISTOR 2SC403SP-51
Q253 8-729-119-78 TRANSISTOR 2SC403SP-51
Q254 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q281 8-729-900-36 TRANSISTOR DTC124ES
Q282 8-729-900-63 TRANSISTOR DTA124ES
Q283 8-729-900-36 TRANSISTOR DTC124ES
Q301 8-729-119-78 TRANSISTOR 2SC403SP-51
Q903 8-729-030-18 TRANSISTOR 2SD2525
Q904 8-729-030-19 TRANSISTOR 2SB1640
Q905 8-729-040-20 TRANSISTOR RT1P137L-TP
Q906 8-729-900-63 TRANSISTOR DTA124ES
Q907 8-729-119-78 TRANSISTOR 2SC403SP-51
Q908 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q909 8-729-119-78 TRANSISTOR 2SC403SP-51
Q1531 8-729-801-93 TRANSISTOR 2SD1387
Q1532 8-729-900-80 TRANSISTOR DTC114ES
Q1533 8-729-900-80 TRANSISTOR DTC114ES
Q1534 8-729-119-77 TRANSISTOR 2SA1175-FEK
Q1535 8-729-900-80 TRANSISTOR DTC114ES
< RESISTOR >
R121 1-249-424-11 CARBON 3.9K 5% 1/4W
R122 1-247-887-00 CARBON 220K 5% 1/4W
R123 1-249-426-11 CARBON 5.6K 5% 1/4W
R124 1-249-429-11 CARBON 10K 5% 1/4W
R125 1-249-441-11 CARBON 100K 5% 1/4W
R126 1-249-417-11 CARBON 1K 5% 1/4W
R127 1-249-441-11 CARBON 100K 5% 1/4W
MAIN
R131 1-260-076-11 CARBON 10 5% 1/2W
(MY, SP, HK, TW, CH, JE)
R132 1-260-076-11 CARBON 10 5% 1/2W
(MY, SP, HK, TW, CH, JE)
R133 1-260-091-11 CARBON 220 5% 1/2W
R134 1-260-091-11 CARBON 220 5% 1/2W
R135 1-249-441-11 CARBON 100K 5% 1/4W
R140 1-249-429-11 CARBON 10K 5% 1/4W
R141 1-249-437-11 CARBON 47K 5% 1/4W
R142 1-249-429-11 CARBON 10K 5% 1/4W
! R147 1-216-456-00 METAL OXIDE 820 5% 2W F
R171 1-249-424-11 CARBON 3.9K 5% 1/4W
R172 1-247-887-00 CARBON 220K 5% 1/4W
R173 1-249-426-11 CARBON 5.6K 5% 1/4W
R174 1-249-429-11 CARBON 10K 5% 1/4W
R176 1-249-417-11 CARBON 1K 5% 1/4W
R177 1-249-441-11 CARBON 100K 5% 1/4W
R181 1-260-076-11 CARBON 10 5% 1/2W
(MY, SP, HK, TW, CH, JE)
R182 1-260-076-11 CARBON 10 5% 1/2W
(MY, SP, HK, TW, CH, JE)
R183 1-260-091-11 CARBON 220 5% 1/2W
R184 1-260-091-11 CARBON 220 5% 1/2W
R191 1-249-425-11 CARBON 4.7K 5% 1/4W
R192 1-249-441-11 CARBON 100K 5% 1/4W
R193 1-249-421-11 CARBON 2.2K 5% 1/4W
R194 1-249-437-11 CARBON 47K 5% 1/4W
R195 1-249-437-11 CARBON 47K 5% 1/4W
R201 1-249-429-11 CARBON 10K 5% 1/4W
R202 1-249-433-11 CARBON 22K 5% 1/4W
R203 1-249-441-11 CARBON 100K 5% 1/4W
R205 1-249-433-11 CARBON 22K 5% 1/4W
R206 1-249-421-11 CARBON 2.2K 5% 1/4W
R207 1-249-431-11 CARBON 15K 5% 1/4W
R208 1-249-437-11 CARBON 47K 5% 1/4W
R209 1-249-441-11 CARBON 100K 5% 1/4W
R210 1-247-903-00 CARBON 1M 5% 1/4W
R212 1-249-419-11 CARBON 1.5K 5% 1/4W
R213 1-249-433-11 CARBON 22K 5% 1/4W
R214 1-247-887-00 CARBON 220K 5% 1/4W
R215 1-247-903-00 CARBON 1M 5% 1/4W
R216 1-249-429-11 CARBON 10K 5% 1/4W
R217 1-249-437-11 CARBON 47K 5% 1/4W
R222 1-249-425-11 CARBON 4.7K 5% 1/4W
R224 1-249-425-11 CARBON 4.7K 5% 1/4W
R226 1-249-421-11 CARBON 2.2K 5% 1/4W
R227 1-249-441-11 CARBON 100K 5% 1/4W
R228 1-249-429-11 CARBON 10K 5% 1/4W
R231 1-249-437-11 CARBON 47K 5% 1/4W
R232 1-249-437-11 CARBON 47K 5% 1/4W
R234 1-247-886-11 CARBON 200K 5% 1/4W
R235 1-249-421-11 CARBON 2.2K 5% 1/4W
R236 1-249-441-11 CARBON 100K 5% 1/4W
R241 1-249-437-11 CARBON 47K 5% 1/4W
R242 1-247-843-11 CARBON 3.3K 5% 1/4W
R243 1-249-429-11 CARBON 10K 5% 1/4W
R244 1-249-417-11 CARBON 1K 5% 1/4W
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
