– 91 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
51 4-986-877-21 KNOB (VOL) (EXCEPT IA)
51 4-986-877-31 KNOB (VOL) (IA)
52 4-962-708-11 EMBLEM (4-A), SONY
53 4-986-859-31 WINDOW (CD)
54 X-4948-591-1 BUTTON (DJ) ASSY
(NON-STOP. WAVE. LOOP. FLASH)
55 4-986-893-21 KNOB (MICROPHONE) (EXCEPT IA)
55 4-986-893-31 KNOB (MICROPHONE) (IA)
* 56 A-4392-857-A HP/MIC BOARD, COMPLETE
57 4-951-620-01 SCREW (2.6X8), +BVTP
58 4-986-863-01 INDICATOR (CD) (EXCEPT IA)
58 4-986-863-11 INDICATOR (CD) (IA)
* 59 4-986-865-01 HOLDER (LED)
* 60 1-664-007-11 DECO BOARD
61 4-986-860-21 BUTTON (POWER)
(POWER. 0. ). DISK SKIP EX-CHANGE)
62 4-986-901-21 BUTTON (A DECK) (9. (. 0. ). p)
63 4-986-862-01 BUTTON (CD) (DISC 1. DISC 2. DISC 3)
64 1-777-869-11 WIRE (FLAT TYPE) (10 CORE)
65 1-777-936-11 WIRE (FLAT TYPE) (5 CORE)
66 1-773-051-11 WIRE (FLAT TYPE) (17 CORE)
* 67 A-4392-348-A CD SW BOARD, COMPLETE
* 68 A-4398-584-A PANEL BOARD, COMPLETE
* 69 A-4392-350-A TC SW BOARD, COMPLETE
* 70 4-986-880-01 HOLDER (JOG) (EXCEPT IA)
* 70 4-986-880-11 HOLDER (JOG) (IA)
71 4-986-881-01 JOG (PLATE) (EXCEPT IA)
71 4-986-881-11 JOG (PLATE) (IA)
72 X-4948-114-1 KNOB (JOG-T5) ASSY
73 4-986-861-21 BUTTON (PLAY)(p. § OPEN/CLOSE. (P)
74 1-769-909-11 WIRE (FLAT TYPE) (9 CORE)
75 4-986-902-21 BUTTON (B DECK) (9. (. 0. ). p)
76 X-4948-636-1 PANEL ASSY, FRONT
77 4-930-336-61 FOOT (FELT) (EXCEPT IA)
77 4-988-663-01 FOOT (FELT) (IA)
78 X-4948-107-1 BUTTON (T/B) ASSY (LOW FREQUENCY.
HIGH FREQUENCY. EFECT ON/OFF.
TUNER MEMORY. TUNER/BAND)
79 4-986-883-01 INDICATOR (JOG)
80 4-986-894-01 BUTTON (GROOVE)
81 X-4948-110-1 BUTTON (E/S) ASSY (ENTER/NEXT)
82 4-986-872-31 BUTTON (TIMER) (TIMER SELECT. P FILE
MEMORY. P FILE. MUSIC. MOVIE. GAME)
83 4-986-875-01 INDICATOR (EWS)
