– 102 –
Q614 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q616 8-729-119-76 TRANSISTOR 2SA1175-HFE
< RESISTOR >
R709 1-249-401-11 CARBON 47 5% 1/4W
R710 1-249-413-11 CARBON 470 5% 1/4W
R711 1-249-409-11 CARBON 220 5% 1/4W
R712 1-249-411-11 CARBON 330 5% 1/4W
R713 1-249-413-11 CARBON 470 5% 1/4W
R714 1-249-415-11 CARBON 680 5% 1/4W
R715 1-249-417-11 CARBON 1K 5% 1/4W
R716 1-249-419-11 CARBON 1.5K 5% 1/4W
R717 1-249-421-11 CARBON 2.2K 5% 1/4W
R718 1-247-804-11 CARBON 75 5% 1/4W
R719 1-247-804-11 CARBON 75 5% 1/4W
R720 1-247-804-11 CARBON 75 5% 1/4W
R721 1-247-804-11 CARBON 75 5% 1/4W
R722 1-247-804-11 CARBON 75 5% 1/4W
R723 1-247-804-11 CARBON 75 5% 1/4W
R724 1-247-807-31 CARBON 100 5% 1/4W
R725 1-247-807-31 CARBON 100 5% 1/4W
R791 1-247-804-11 CARBON 75 5% 1/4W
R792 1-247-804-11 CARBON 75 5% 1/4W
R793 1-247-804-11 CARBON 75 5% 1/4W
R794 1-247-804-11 CARBON 75 5% 1/4W
R795 1-247-804-11 CARBON 75 5% 1/4W
R796 1-247-804-11 CARBON 75 5% 1/4W
< SWITCH >
S645 1-762-196-21 SWITCH, TACT (POWER)
S646 1-762-196-21 SWITCH, TACT (0)
S647 1-762-196-21 SWITCH, TACT ())
S648 1-762-196-21 SWITCH, TACT (DISC SKIP EX-CHANGE)
S649 1-762-196-21 SWITCH, TACT (DISC 1)
S650 1-762-196-21 SWITCH, TACT (DISC 2)
S651 1-762-196-21 SWITCH, TACT (DISC 3)
S652 1-762-196-21 SWITCH, TACT (p)
S653 1-762-196-21 SWITCH, TACT (§ OPEN/CLOSE)
S654 1-762-196-21 SWITCH, TACT (· ∏)
************************************************************
* 1-658-575-11 CONNECTOR BOARD
****************
< CONNECTOR >
* CN701 1-568-946-11 PIN, CONNECTOR 8P
CN702 1-750-413-11 CONNECTOR, FFC/FPC 8P
< TRANSISTOR >
Q701 8-729-900-80 TRANSISTOR DTC114ES
< RESISTOR >
R703 1-249-435-11 CARBON 33K 5% 1/4W
R704 1-249-429-11 CARBON 10K 5% 1/4W
R705 1-249-417-11 CARBON 1K 5% 1/4W
************************************************************
* 1-664-007-11 DECO BOARD
**********
< CONNECTOR >
* CN605 1-568-848-11 SOCKET, CONNECTOR 5P
< DIODE >
D619 8-719-058-04 LED SEL5223S-TP15 (RIGHT)
D620 8-719-058-04 LED SEL5223S-TP15 (RIGHT)
D621 8-719-058-04 LED SEL5223S-TP15 (CENTER)
D622 8-719-058-03 LED SEL5423E-TP15 (CENTER)
D623 8-719-058-04 LED SEL5223S-TP15 (CENTER)
D624 8-719-058-04 LED SEL5223S-TP15 (LEFT)
D625 8-719-058-04 LED SEL5223S-TP15 (LEFT)
< TRANSISTOR >
Q610 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q611 8-729-119-76 TRANSISTOR 2SA1175-HFE
< RESISTOR >
R706 1-247-807-31 CARBON 100 5% 1/4W
R707 1-247-807-31 CARBON 100 5% 1/4W
R708 1-247-807-31 CARBON 100 5% 1/4W
R746 1-247-807-31 CARBON 100 5% 1/4W
************************************************************
* A-4392-857-A HP/MIC BOARD, COMPLETE
***********************
< CAPACITOR >
C750 1-162-294-31 CERAMIC 0.001uF 10% 50V
C751 1-162-294-31 CERAMIC 0.001uF 10% 50V
C752 1-164-159-11 CERAMIC 0.1uF 50V
C753 1-164-159-11 CERAMIC 0.1uF 50V
C754 1-162-306-11 CERAMIC 0.01uF 20% 16V
C755 1-124-257-00 ELECT 2.2uF 20% 50V
C756 1-162-294-31 CERAMIC 0.001uF 10% 50V
C757 1-162-215-31 CERAMIC 47PF 5% 50V
C758 1-124-261-00 ELECT 10uF 20% 50V
C759 1-124-465-00 ELECT 0.47uF 20% 50V
C760 1-162-215-31 CERAMIC 47PF 5% 50V
C761 1-162-282-31 CERAMIC 100PF 10% 50V
C762 1-124-257-00 ELECT 2.2uF 20% 50V
C764 1-124-261-00 ELECT 10uF 20% 50V
C765 1-126-960-11 ELECT 1uF 20% 50V
C766 1-162-305-11 CERAMIC 0.0068uF 20% 16V
C767 1-162-294-31 CERAMIC 0.001uF 10% 50V
C768 1-136-495-11 FILM 0.068uF 5% 50V
C769 1-126-957-11 ELECT 0.22uF 20% 50V
C770 1-126-957-11 ELECT 0.22uF 20% 50V
C771 1-126-967-11 ELECT 47uF 20% 10V
C772 1-164-159-11 CERAMIC 0.1uF 50V
C773 1-104-664-11 ELECT 47uF 20% 25V
C774 1-136-495-11 FILM 0.068uF 5% 50V
C775 1-162-305-11 CERAMIC 0.0068uF 20% 16V
C776 1-162-294-31 CERAMIC 0.001uF 10% 50V
