Sony HCD-V808 - PANEL BOARD IC601 Functions; IC Block Diagrams - BD Section

– 27 –
• PANEL BOARD IC601 TMP87CM75-6564
(FLUORESCENT INDICATOR TUBE DRIVER, KEY CONTROL, LED DRIVER)
Pin No. Pin Name I/O Function
1 SEG-35 O
Segment drive signal output to the fluorescent indicator tube (FL601)
2 V-LOAD —
Power supply terminal (–30 V) (for fluorescent indicator tube drive)
3 LED1 O
LED drive signal output terminal (deck-A · / ª)
4 LED2 O
LED drive signal output terminal (P PAUSE, r REC)
5 LED3 O
LED drive signal output terminal (deck-B · / ª)
6 LED4 O
LED drive signal output terminal (TUNER BAND, GROOVE)
7 LED5 O
LED drive signal output terminal (SONIC FORMATION, EFFECT ON/OFF)
8 LED6 O
LED drive signal output terminal (NON-STOP)
9 LED7 O
LED drive signal output terminal (JOG, ±, ≠)
10 LED8 O
LED drive signal output terminal (+, –, ENTER/NEXT)
11 VSS —
Ground terminal
12 X-OUT O
System clock output terminal (8 MHz)
13 X-IN I
System clock input terminal (8 MHz)
14 RESET I
System reset signal input from the reset signal generator (IC302) “L”: reset For several
hundreds msec. after the power supply rises, “L” is input, then it changes to “H”
15 LED9 O
LED drive signal output terminal (BEAT ON/OFF, VCD)
16 LED10 O
LED drive signal output terminal (decoration center/right position)
17 TEST I
Connected to ground
18 LED11 O
LED drive signal output terminal (decoration left position)
19 LED12 O
LED drive signal output terminal (DISC 1)
20 LED13 O
LED drive signal output terminal (DISC 2)
21 LED14 O
LED drive signal output terminal (DISC 3)
22 LED15 O
LED drive signal output terminal (· ∏)
23 LED16 O
LED drive signal output terminal (PBC, AUTO PBC)
24 VOL-A I
Rotary encoder pulse input from the S602 (VOLUME)
25 LED17 O
LED drive signal output terminal (BPM CONTROL)
26 JOG-A I
Jog dial pulse input from the S601 (JOG)
27 CLOCK I/O
Communication data reading clock signal input or transfer clock signal output with the master
controller (IC301) and IIC interface controller (IC901)
28 DATA I/O
Communication data bus with the master controller (IC301) and IIC interface controller
(IC901)
29 LED SELECT O
LED selection signal output terminal
30 VDD —
Power supply terminal (+5V)
31 VSS —
Ground terminal
32 MODEL I
Destination setting terminal
33 KEY-1 I
34 KEY-2 I
35 KEY-3 I
Key input terminal (A/D input) (S643, 644, 655 to 668)
PAD B, CHAIN, deck-B · / ª / ) / 0 / p , P PAUSE, r REC, CD SYNCHRO,
HIGH SPEED DUBBING, deck-A ) / 0 / p / · / ª
Key input terminal (A/D input) (S627 to 640, 642)
PAD A, SONIC FORMATION, GROOVE, MEMORY, P FILE, GAME, MOVIE, MUSIC,
EFFECT ON/OFF, KARAOKE PON/MPX, TUNER/BAND, TUNER MEMORY,
TUNING MODE, STEREO/MONO, FUNCTION
Key input terminal (A/D input) (S616 to 626)
LOW/HIGH FREQUENCY, ENTER/NEXT, BPM CONTROL, NON-STOP, WAVE,
LEVEL +/–, BEAT SELECT, BEAT SPEED, FLASH
