Sony HCD-V808 - Circuit Board Locations Diagram

– 41 –
• Circuit Boards Location
TRANS board
ENCAPSULATED COMPONENT
(FM/AM TUNER UNIT)
KEYCON board
DJ board
MAIN board
AMP board
TC SW board
HP/MIC board
PANEL board
CD SW board
DECO board
SENSOR board
MOTOR (TURN) board
CONNECTOR board
BD board
VIDEO OUT board
MOTOR (SLIDE) board
VIDEO POWER board
AUDIO board
LEAF SWITCH board
MOTOR board
VIDEO board
