Sony HCD-V808 - Waveforms (Continued)

– 88 –
6 IC201 `⁄⁄¤ (BCKI)
7 IC201 `⁄⁄‚ (LRCI)
8 IC201 `⁄‚fl (XTL2O)
9 IC201 `⁄‚‹ (FSXI)
0 IC201 `⁄‚¤ (BCKO)
!¡ IC201 `⁄‚⁄ (LRCO)
!™ IC201 (¢ (FID/FHREF),
IC401 ^™ (FID)
!£ IC201 (£, IC271 !ª, IC301 (¶,
IC401 %ª (VSYNC)
!¢ IC201 (™, IC271 @º, IC301 (•,
IC401 ^º (HSYNC)
!∞ IC201 *ª, IC301 `⁄‚‚ ,
IC401 %¶ (DCLK)
!§ IC271 8 (OSCIN)
!¶ IC402 6
!• IC401 @¢ (COMPO) NOTE 1
!ª IC401 @ª (YOUT) NOTE 1
@º IC401 #™ (COUT) NOTE 1
5 Vp-p
474 ns
5.1 Vp-p
22.7
µ
s
1.8 Vp-p
45 MHz
4.5 Vp-p
16.9344 MHz
3.4 Vp-p
474 ns
3.7 Vp-p
22.7 µ s
5.1 Vp-p
33.4 ms
5 Vp-p
16.7 ms
0.2 ms
5 Vp-p
64 µ s
4.8 µ s
5 Vp-p
74 ns
4.3 Vp-p
6.75 MHz
4 Vp-p
27 MHz
1.4 Vp-p
1.2 Vp-p
1 Vp-p
