– 95 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
* 101 A-4403-228-A AMP BOARD, COMPLETE
* 102 1-664-026-11 TRANS BOARD
* 103 1-666-126-11 VIDEO POWER BOARD
104 1-782-654-11 WIRE (FLAT TYPE) (29 CORE)
* 105 4-991-746-31 PANEL, BACK (MY)
* 105 4-991-746-81 PANEL, BACK (EA, TH)
* 105 4-991-747-01 PANEL, BACK (SP)
* 105 4-991-747-11 PANEL, BACK (TW)
* 105 4-991-747-21 PANEL, BACK (CH)
* 105 4-991-747-31 PANEL, BACK (IA)
* 105 4-991-747-51 PANEL, BACK (HK)
106 1-233-545-11 ENCAPSULATED COMPONENT
(FM/AM TUNER UNIT) (EA)
106 1-233-546-11 ENCAPSULATED COMPONENT
(FM/AM TUNER UNIT) (EXCEPT EA)
* 107 3-703-244-00 BUSHING (2104), CORD
(EA, MY, SP, HK, TW, CH)
107 3-703-571-11 BUSHING (S) (4516), CORD (TH)
107 4-966-266-01 BUSHING (S) (FBS002), CORD (IA)
108 1-773-012-11 WIRE (FLAT TYPE) (15 CORE)
* 109 4-988-533-01 HOLDER, PCB
110 4-965-822-01 FOOT
* 111 A-4398-562-A MAIN BOARD, COMPLETE
(SP, IA, HK, TW, CH)
* 111 A-4403-223-A MAIN BOARD, COMPLETE (MY)
* 111 A-4403-269-A MAIN BOARD, COMPLETE (EA, TH)
112 4-956-370-12 BAND, PLUG FIXED (HK)
! 113 1-575-651-11 CORD, POWER (EA, MY, SP, HK, TW)
! 113 1-575-653-11 CORD, POWER (IA)
! 113 1-751-326-31 CORD, POWER (TH)
! 113 1-782-464-21 CORD, POWER (CH)
! 114 1-569-007-11 ADAPTOR, CONVERSION 2P (IA)
! 114 1-569-008-11 ADAPTOR, CONVERSION 2P (MY, SP, TW)
! 114 1-770-019-11 ADAPTOR, CONVERSION PLUG 3P (HK)
* 115 A-4398-587-A VIDEO BOARD, COMPLETE
* 116 A-4398-575-A KEYCON BOARD, COMPLETE
* 117 4-924-098-91 HOLDER, PC BOARD
* 118 1-664-088-11 DJ BOARD
119 1-782-653-11 WIRE (FLAT TYPE) (13 CORE)
* 120 1-665-406-11 VIDEO OUT BOARD
M901 1-698-792-11 FAN, DC
! T901 1-431-304-11 TRANSFORMER, POWER
The components identified by
mark ! or dotted line with
mark ! are critical for safety.
Replace only with part number
specified.
