– 103 –
R105 1-216-097-00 METAL CHIP 100K 5% 1/10W
R106 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R107 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R108 1-216-073-00 METAL CHIP 10K 5% 1/10W
R109 1-216-121-00 METAL CHIP 1M 5% 1/10W
R110 1-216-025-00 METAL CHIP 100 5% 1/10W
R112 1-216-049-11 METAL CHIP 1K 5% 1/10W
R123 1-216-073-00 METAL CHIP 10K 5% 1/10W
R124 1-216-097-00 METAL CHIP 100K 5% 1/10W
R125 1-216-033-00 METAL CHIP 220 5% 1/10W
R126 1-216-033-00 METAL CHIP 220 5% 1/10W
R127 1-216-033-00 METAL CHIP 220 5% 1/10W
R131 1-216-037-00 METAL CHIP 330 5% 1/10W
R132 1-216-073-00 METAL CHIP 10K 5% 1/10W
R134 1-216-049-11 METAL CHIP 1K 5% 1/10W
R135 1-216-295-00 CONDUCTOR, CHIP (2012)
R136 1-216-295-00 CONDUCTOR, CHIP (2012)
R137 1-216-295-00 CONDUCTOR, CHIP (2012)
R138 1-216-295-00 CONDUCTOR, CHIP (2012)
R141 1-216-089-00 METAL CHIP 47K 5% 1/10W
R142 1-216-081-00 METAL CHIP 22K 5% 1/10W
R143 1-216-103-00 METAL CHIP 180K 5% 1/10W
R144 1-216-103-00 METAL CHIP 180K 5% 1/10W
R146 1-216-073-00 METAL CHIP 10K 5% 1/10W
R147 1-216-067-00 METAL CHIP 5.6K 5% 1/10W
R148 1-216-001-00 METAL CHIP 10 5% 1/10W
R149 1-216-003-11 METAL CHIP 12 5% 1/10W
R158 1-216-109-00 METAL CHIP 330K 5% 1/10W
R159 1-216-101-00 METAL CHIP 150K 5% 1/10W
R160 1-216-295-00 CONDUCTOR, CHIP (2012)
R161 1-216-308-00 METAL CHIP 4.7 5% 1/10W
R162 1-216-101-00 METAL CHIP 150K 5% 1/10W
< SWITCH >
S101 1-572-085-11 SWITCH, LEAF (LIMIT)
************************************************************
* 1-664-023-11 CD SW BOARD
************
< CONNECTOR >
* CN602 1-568-824-11 SOCKET, CONNECTOR 5P
CN606 1-568-853-11 SOCKET, CONNECTOR 10P
< DIODE >
D626 8-719-056-13 LED SML79423C-TP15 (DISC 1)
D627 8-719-056-13 LED SML79423C-TP15 (DISC 1)
D628 8-719-056-13 LED SML79423C-TP15 (DISC 2)
D629 8-719-056-13 LED SML79423C-TP15 (DISC 2)
D630 8-719-056-13 LED SML79423C-TP15 (DISC 3)
D631 8-719-056-13 LED SML79423C-TP15 (DISC 3)
D632 8-719-058-03 LED SEL5423E-TP15 (· ∏ (PLAY))
D633 8-719-063-91 LED SLR325DC-P-T32 (· ∏ (PAUSE))
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
< TRANSFORMER >
T621 1-423-980-11 TRANSFORMER, BIAS OSCILLATION
************************************************************
* A-4673-557-A BD BOARD, COMPLETE
*******************
< CAPACITOR >
C101 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C102 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C103 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C105 1-104-913-11 TANTAL. CHIP 10uF 20% 16V
C106 1-164-346-11 CERAMIC CHIP 1uF 16V
C107 1-164-346-11 CERAMIC CHIP 1uF 16V
C108 1-163-035-00 CERAMIC CHIP 0.047uF 50V
C109 1-163-145-00 CERAMIC CHIP 0.0015uF 5% 50V
C110 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C111 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C112 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C113 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C115 1-126-607-11 ELECT CHIP 47uF 20% 4V
C116 1-126-607-11 ELECT CHIP 47uF 20% 4V
C117 1-126-209-11 ELECT 100uF 20% 4V
C118 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C119 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C123 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C124 1-164-005-11 CERAMIC CHIP 0.47uF 25V
C125 1-104-913-11 TANTAL. CHIP 10uF 20% 16V
C140 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C141 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C151 1-163-237-11 CERAMIC CHIP 27PF 5% 50V
C153 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C154 1-164-336-11 CERAMIC CHIP 0.33uF 25V
C156 1-163-237-11 CERAMIC CHIP 27PF 5% 50V
C157 1-163-145-00 CERAMIC CHIP 0.0015uF 5% 50V
C159 1-163-019-00 CERAMIC CHIP 0.0068uF 10% 50V
C161 1-163-038-00 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
CN101 1-774-115-11 CONNECTOR, (FFC/FPC) 29P
CN102 1-770-014-11 CONNECTOR, FFC/FPC 16P
< IC >
IC101 8-752-369-78 IC CXD2545Q
IC102 8-759-176-09 IC BA6392FP
IC103 8-752-072-45 IC CXA1821M-T6
< TRANSISTOR >
Q101 8-729-010-08 TRANSISTOR MSB710-R
< RESISTOR/CHIP CONDUCTOR >
R101 1-216-077-00 METAL CHIP 15K 5% 1/10W
R102 1-216-097-00 METAL CHIP 100K 5% 1/10W
R103 1-216-077-00 METAL CHIP 15K 5% 1/10W
R104 1-216-085-00 METAL CHIP 33K 5% 1/10W
