– 108 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
D145 8-719-987-63 DIODE 1N4148M
D146 8-719-987-63 DIODE 1N4148M
D147 8-719-987-63 DIODE 1N4148M
D191 8-719-815-85 DIODE 1S1585
D192 8-719-815-85 DIODE 1S1585
D193 8-719-815-85 DIODE 1S1585
D194 8-719-815-85 DIODE 1S1585
D281 8-719-815-85 DIODE 1S1585
D291 8-719-987-63 DIODE 1N4148M
D301 8-719-024-99 DIODE 11ES2-NTA2B
D302 8-719-024-99 DIODE 11ES2-NTA2B
D303 8-719-987-63 DIODE 1N4148M
D304 8-719-987-63 DIODE 1N4148M
D305 8-719-987-63 DIODE 1N4148M
D306 8-719-987-63 DIODE 1N4148M
D307 8-719-987-63 DIODE 1N4148M
D902 8-719-975-85 DIODE ERB83-004
D903 8-719-975-85 DIODE ERB83-004
D904 8-719-975-85 DIODE ERB83-004
D905 8-719-975-85 DIODE ERB83-004
D906 8-719-024-99 DIODE 11ES2-NTA2B
D907 8-719-024-99 DIODE 11ES2-NTA2B
D908 8-719-024-99 DIODE 11ES2-NTA2B
D909 8-719-024-99 DIODE 11ES2-NTA2B
D910 8-719-002-60 DIODE UZL-33L
D911 8-719-010-43 DIODE UZ-5.6BSC
D912 8-719-987-63 DIODE 1N4148M
D913 8-719-024-99 DIODE 11ES2-NTA2B
D914 8-719-024-99 DIODE 11ES2-NTA2B
D915 8-719-001-42 DIODE UZL-11M1
D916 8-719-987-63 DIODE 1N4148M
D951 8-719-987-63 DIODE 1N4148M
D952 8-719-987-63 DIODE 1N4148M
< GROUND PLATE >
* ETP1 4-870-539-11 PLATE, GROUND
< FERRITE BEAD >
FB302 1-412-473-21 INDUCTOR 0UH
< IC >
IC102 8-759-000-48 IC MC14052BCP
IC201 8-759-460-02 IC M62427FP-A
IC202 8-759-634-50 IC M5218AL
IC231 8-759-634-50 IC M5218AL
IC241 8-759-634-50 IC M5218AL
IC281 8-759-111-68 IC uPC1237HA
IC301 8-759-482-00 IC uPD780016YGF-015-3BA
IC302 8-759-635-63 IC M51943BSL
IC391 8-749-923-04 IC TOTX178 (CD DIGITAL OUT OPTICAL)
IC901 8-759-288-53 IC LA5617
IC902 8-759-604-86 IC M5F7807L
IC903 8-759-231-53 IC TA7805S
IC904 8-759-231-58 IC TA7812S
IC1501 8-759-363-21 IC HA12203NT
MAIN
IC1502 8-759-822-09 IC LB1641
< PIN JACK >
J101 1-695-188-31 JACK, PIN 4P (VIDEO/MD (AUDIO) IN/OUT)
J241 1-774-785-11 JACK, PIN 1P (SUPER WOOFER)
< COIL >
L131 1-420-872-00 COIL, AIR-CORE (EXCEPT EA, MY, TH)
L181 1-420-872-00 COIL, AIR-CORE (EXCEPT EA, MY, TH)
L301 1-410-509-11 INDUCTOR 10uH
L392 1-410-521-11 INDUCTOR 100uH
< TRANSISTOR >
Q101 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q102 8-729-900-63 TRANSISTOR DTA124ES
Q103 8-729-900-36 TRANSISTOR DTC124ES
Q141 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q142 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q143 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q144 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q145 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q151 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q191 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q192 8-729-111-29 TRANSISTOR 2SD1616A-K
Q202 8-729-119-78 TRANSISTOR 2SC403SP-51
Q203 8-729-119-78 TRANSISTOR 2SC403SP-51
Q204 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q205 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q231 8-729-900-63 TRANSISTOR DTA124ES
Q232 8-729-900-63 TRANSISTOR DTA124ES
Q241 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q252 8-729-119-78 TRANSISTOR 2SC403SP-51
Q253 8-729-119-78 TRANSISTOR 2SC403SP-51
Q254 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q281 8-729-900-36 TRANSISTOR DTC124ES
Q282 8-729-900-63 TRANSISTOR DTA124ES
Q283 8-729-900-36 TRANSISTOR DTC124ES
Q301 8-729-119-78 TRANSISTOR 2SC403SP-51
Q309 8-729-900-63 TRANSISTOR DTA124ES
Q903 8-729-030-18 TRANSISTOR 2SD2525
Q904 8-729-030-19 TRANSISTOR 2SB1640
Q905 8-729-040-20 TRANSISTOR RT1P137L-TP
Q906 8-729-900-63 TRANSISTOR DTA124ES
Q907 8-729-119-78 TRANSISTOR 2SC403SP-51
Q908 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q909 8-729-119-78 TRANSISTOR 2SC403SP-51
Q1531 8-729-801-93 TRANSISTOR 2SD1387
Q1532 8-729-900-80 TRANSISTOR DTC114ES
Q1533 8-729-900-80 TRANSISTOR DTC114ES
Q1534 8-729-119-77 TRANSISTOR 2SA1175-FEK
Q1535 8-729-900-80 TRANSISTOR DTC114ES
< RESISTOR >
R121 1-249-424-11 CARBON 3.9K 5% 1/4W
R122 1-247-887-00 CARBON 220K 5% 1/4W
R123 1-249-426-11 CARBON 5.6K 5% 1/4W
